Technical specifications for TC-505-01-6M0
-
Product ModelTC-505-01-6M0
-
Product ParametersI/O Companion Slot Cable
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size35x35x10cm
-
ManufacturerICS Triplex
-
Weight1.14 kg
-
Channel Capacity40 channels
-
Maximum Working Voltage60 V
-
Maximum Current2 A per channel
-
Module CompatibilityDigital 24 V
-
Operating Temperature Range-40°C to +85°C
Description
TC-505-01-6M0
I/O Companion Slot
I/O Companion Slot Cable
Internal, 40 Channel Output to FTA
I/O Companion Slot
I/O Companion Slot Cable
Internal, 40 Channel Output to FTA
Information
Overview
Manuals
Technical notes
Product Applications
General Installation Procedure
Features:
- Smart Slot Redundancy Enablement
- High-Current Signal Integrity
- 4.5-Meter Extended Length
- Triple Modular Redundant (TMR) Compatibility
- Robust Industrial Shielding
The TC-505-01-6M0 ICS Triplex I/O Smart Slot Cable may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
ICS Triplex TC-505-01-6M0 I/O Smart Slot Cable Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 0 V connection at the chassis end allows a module reference so that it can measure itsoutput voltage, this must be connected to the field 0 Volts.The FTA contains isolated power group field 0 Volts which connect to field 0 V supply.Commoning of the reference is obtained by a connection between this field supply and theT8290 Output power distribution unit (TB1 pins 1 and 2).
- Rotating Machinery & Turbines:Turbine control for plants & industrial generators
- Emergency Shutdown (ESD) Systems:Controls safety valves & hazardous process actuators
- Fire & Gas (F&G) Detection Systems:Powers suppression fans & fire pumps
- Boiler & Burner Management:Manages ignition & fuel flow for industrial boilers/furnaces
- Subsea & Extraction Equipment:Offshore oil/gas control cabinets requiring remote reliability.
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Preparation: Ensure the Trusted TMR system is powered down if required by site safety protocols.
Chassis End Connection: Plug the 96-way 'C' connector into the designated Trusted TMR I/O SmartSlot.
Earth Connection: Connect the sheathed braid at the chassis end to the safety earth.
Field Side Termination: Terminate the flying leads on field terminals using the identification ferrules.
FAQs
-
What is the TC-505-01-6M0?
+The ICS Triplex TC-505-01-6M0 is a Trusted I/O Companion Slot Cable. It is part of the Trusted TMR Processor System, designed for use within safety-critical industrial applications, such as in Trusted Input/Output (I/O) modules -
What is the length of the cable?
+The model number "6M0" typically indicates a 6-meter length in ICS Triplex cabling conventions. -
What is the primary function of this cable?
+It serves as a communication link between Trusted I/O modules and companion slots or FTAs, ensuring deterministic and redundant signal routing. It is specifically engineered to maintain fault tolerance and signal integrity in systems like emergency shutdowns or fire and gas monitoring.
