Technical specifications for 9465-ET-S-SC
-
Product Model9465-ET-S-SC
-
Product ParametersCopper to Fibre Intrinsically Safe Converter
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size5.5x12.6x7.5cm
-
ManufacturerMTL Insturments Group
-
Weight0.65 kg
-
Input voltage12V DC (10–15.4V)
-
Input current160mA
-
Input protectionFuse + supply reversal diode
-
PoExPowered Device
-
FIBRE PORT10/100 base FX
-
Multi mode distance2km @100Mbps / 5km@10Mbps typ
-
Operating–40°C to +70°C
-
Storage–40°C to +70°C
-
Relative Humidity5 to 95% RH (non-condensing)
Description
Copper to Fibre Optic Converter
10/100Mbps wire speed
Extend up to 5km (10Mbs)
Zone 1, Division 1 mountable in suitableenclosure
Transparent operation
Choice of fibre optic connection styles
ATEX / IECEx certified
FM / FMC approved
Wide temp. range –40°C to +70°C
PoEx™ Power over IS Ethernet option
10/100Mbps wire speed
Extend up to 5km (10Mbs)
Zone 1, Division 1 mountable in suitableenclosure
Transparent operation
Choice of fibre optic connection styles
ATEX / IECEx certified
FM / FMC approved
Wide temp. range –40°C to +70°C
PoEx™ Power over IS Ethernet option
Information
Overview
Manuals
Technical notes
Product Applications
Wiring & Connections
Features:
- Copper to Fibre Optic Converter
- 10/100Mbps wire speed
- Extend up to 5km (10Mbs)
- Zone 1, Division 1 mountable in suitableenclosure
- Transparent operation
- Choice of fibre optic connection styles
- ATEX / IECEx certified
- FM / FMC approved
- Wide temp. range –40°C to +70°C
- PoEx™ Power over IS Ethernet option
Longer distances are achievable withsingle mode fibre.Longer distances are obtained by simply connecting a 9466 (10/100MbpsEthernet Switch) between two 9465 media converters, effectively givinga 'repeater' function (This also provides 3 x UTP ports available for localnetwork connectivity), this can be repeated as required.
The use of fibre optics gives exceptional immunity to noise and electricalinterference, it is also used when connecting a Hazardous Area networkto a Zone 2 / Safe Area network or device.
The 9465-ET-S-SC MTL SC style 9µm Single-mode may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
MTL 9465-ET-S-SC SC style 9µm Single-mode Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
When installed in a Zone 1 or Division 1 hazardous area the convertermay be powered by an intrinsically safe power supply or by Powerover IS Ethernet (PoEx) providing intrinsically safe power and Ethernetcommunications over a single Cat5e cable.When mounted in a safe area the converter may be powered by a12V dc general-purpose power supply and the 'IS op' approval allowsconnection of the fibre optic cable into the hazardous area.
- Petrochemical & Oil Refineries:Zone 1 networking for distillation, tanks & cracking plants
- Underground & Surface Mines:Group I M1 for coal/metal mine ventilation & heavy machinery
- Chemical Processing Plants:Connects sensors in volatile vapor environments
- Pharmaceutical Manufacturing:Hazardous clean rooms with solvents for drug synthesis
- Food & Beverage Facilities:Combustible dust areas: grain elevators, flour mills, sugar refineries
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Copper (RJ45): Connects via standard Cat5e or Cat6 cable. The maximum segment length is 100 meters.Fibre (SC): Use 9µm single-mode fibre. The top port is for Transmit (TX) and the bottom port is for Receive (RX).
Direct IS Power: Connect a 12V DC (10–15.4V) intrinsically safe supply to the front screw terminals.
PoEx (Power over IS Ethernet): If using a PoEx-compatible source (like the MTL 9466-ET), no separate power wiring is needed on the screw terminals.
FAQs
-
What is 9465-ET-S-SC?
+The MTL 9465-ET-S-SC is an intrinsically safe (IS) 10/100Mbps copper-to-fibre optic media converter. It securely extends Ethernet networks into hazardous areas (such as Zone 1 or Division 1) by converting standard Cat5e Ethernet into a single-mode fibre optic signal. -
How is this device powered in hazardous areas?
+It can be powered either by an intrinsically safe power supply or via Power over IS Ethernet (PoEx™). PoEx allows both intrinsically safe power and Ethernet communications to be delivered over a single Cat5e cable, allowing for safe live connection and disconnection. -
What is the maximum length for the copper (UTP) cable?
+The 10/100Mb Ethernet twisted pair (Cat5e) RJ45 copper connection supports a maximum length of 100 meters. -
What are the key certifications?
+The unit is certified under IECEx (IECExSIR07.0042X) and ATEX for both surface industry and mining applications
