S7-400

SM431 Analog Input Module

6ES74310HH000AB0
SIMATIC S7-400
ANALOG INPUT SM 431
NON-ISOLATED 16 ANALOG INPUT
RESOLUTION 13 BIT
+/-10 V
+/-20 MA
4-20MA
20MS CONVERSION TIME
Tariff Code: 8538903000

SM431 Analog Input Module

6ES74311KF000AB0
ANALOG INPUT MODULE
SM 431
SIMATIC S7-400
ISOLATED 8 ANALOG INPUT
RESOLUTION 13 BIT
U/IRESISTOR
Tariff Code: 8538908180
Country of Origin: Germany

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
SIMATIC S7-400H
FOR S7-400H/ S7-400F/FH
3 INTERFACES
1 MPI/DP
768 KB
(256 KB DATA/512 KB PROGRAM)

FM458-1 DP Application Module

SIMATIC S7-400
FM458-1 DP APPLICATION MODULE
FORSIMATIC S7-400
Number of digital inputs 8; Connector X2
Rated value (DC) 24 V
for signal "0" -1 to +6V
for signal "1" 13.5 to 33V
Resolution 500 ms

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
SIMATIC S7-400H
CPU 417H
FOR S7-400H
4 INTERFACES: 1 MPI/DP / 1 DP / 2 FOR SYNC MODULES
30 MB MEMORY (15 MB DATA/15 MB PROGRAM)

Patch Cable - 1M

SIMATIC S7-400H
PATCH CABLE FO
1M FOR
SYNC-MODULE

CR3 Central Rack - 4 Slots

SYNC SUBMODULE

SIMATIC S7-400H
synchronizationmodule V4
for patch cable to 10 m
from CPU, max. 210 mA
Power loss, typ. 1.1 mW

CPU416-2 Processor Module

CENTRAL PROCESSING UNIT
SIMATIC S7-400
CPU 416-2
WITH WORK MEMORY 5.6 MB
(2.8 MB CODE / 2.8 MB DATA)
1ST INTERFACE MPI/DP 12MBIT/S
2ND INTERFACE PROFIBUS DP
SUCCESSOR 6ES7416-2XP07-0AB0

CPU 414-5H Processor Module

CENTRAL PROCESSING UNIT
FOR S7-400H AND S7-400F/FH
5 INTERFACES
4 MB MEMORY (2 MB DATA/2 MB PROGRAM)

CPU 414-2 Central processing unit

SIMATIC S7-400
CPU 414-2 Central processing unit
with: Workmemory 512 KB,
(256 KB code, 256 KB data)
1st interface MPI/DP12 Mbit/s
2nd interface PROFIBUS DP

CPU 414-2 Central processing unit

SIMATIC S7-400
CPU 414-2 central processing unit
with: work memory 1 MB
(0.5 MB code, 0.5 MB data)
1st interface MPI/DP 12 Mbps
2nd interface PROFIBUS DP

IM 460-1 Transmitter Interface Module

IM461-1 Transmitter Module

SM422 Digital Output Module

DIGITAL OUTPUT MODULE
SIMATIC S7-400
SM 422
ISOLATED
16 DIGITAL OUTPUTS
5-230 VAC
5 AMP RELAY

Analog Input Module

6ES74317QH000AB0
SIMATIC S7-400
SM 431 ANALOG INPUT MODULE OPTIC. ISOLATED
16 AI
16 BIT RESOLUTION
U/I/RESIST./ THERMOEL./PT100
ALARM
DIAGNOST

Flash Memory Card - 2MB

SIMATIC S7
MEMORY CARD FOR S7-400
LONG VERSION
5VFLASH-EPROM
2 MBYTES

CPU 414-2 Processor Module

CPU412-5H PN/DP Processor Module

SIMATIC S7-400H
CPU 412-5H
central processing unit
for S7-400H and S7-400F/FH
5 interfaces: 1x MPI/DP, 1x DP
1x PN and 2 for sync modules
1 MBmemory
(512 KB data/512 KB program)

SM422 Digital Output Module

PS 407 Power Supply

SIPLUS S7-400
PS 407 10 A
based on 6ES7407-0KA02-0AA0
with conformalcoating
-25…+70 °C, 10 A
wide range
120/230 V UC
5 V DC/10 A

SM 422 Digital Output Module

OUTPUT MODULE
SIMATIC S7-400
SM 422
DIGITAL
0.5 AMP
24 VDC
ISOLATED 32 DO

SM 421 Digital Input Module

SIMATIC S7-400
digital input SM 421
isolated 32 DI; 24 V DC
Type of input voltage DC
Rated value (DC) 24 V
for signal "0" -30 V DC to +5 V DC
for signal "1" 13 V DC to 30 V DC

CPU412-2 Processor Module

SIMATIC S7-400
CPU 412-2 144 KB
WORKING MEMORY
(72 KBCODE, 72 KB DATA)
INTERFACE MPI/DP 12 MBIT/S
2.INTERFACE DP

UR2 Rack - 9 Slots
