Connector Board
Control electronics Advanced incl.
terminals 32 MB
C98043-A7100-L4
Control Electronics Advanced
Operating Temperature:
Ambient Operating Temperature: 0°C to +55°C
Storage Temperature: -25°C to +70°C
MOUNTING RAIL 482MM (19")
SIMATIC S7-1500
mounting rail 482.6 mm (approx. 19 inch)
incl. groundingscrew,
integrated DIN rail for mounting of
incidentals such as terminals
automaticcircuit breakers and relays
SIMATIC S7 MEMORY CARD. 24 MB
SIMATIC S7
MEMORY CARD FOR
S7-1X00 CPU/SINAMICS
3,3 V FLASH
24MBYTE
Digital Input Module
SIMATIC S7-300
Digital input SM 321
isolated, 16 DI
24 V DC,
1x 20-pole
CP 341 Serial Communications Module
S7-300
CP 341 COMMUNICATIONS PROCESSOR
WITH RS232C INTERFACE (RS-232-C)
INCL. CONFIGURATION PACKAGE ON CD
Analog output module
SIMATIC S7-200 SMART
Analog output SM AQ04
4 AO, +/-10 V, 11 bitresolution
or 4-20 mA, 11 bit resolution
Rated value (DC) 24 V
permissible range, lower limit (DC) 20.4 V
permissible range, upper limit (DC) 28.8 V
Current consumption, max. 103 mA
from backplane bus 5 V DC, max. 61 mA
Power loss, typ. 2.7 W
OP177B Operator Panel
6AV66420DA011AX1
OPERATOR INTERFACE
OP177B
PN/DP
256 COLORS
6 INCH SCREEN
SIEMENS | SIMATIC OP1777B 6" PN/DP 256 COLOR
Field Device Coupler
Field Device Coupler
FDC 157 physical interface
for PROFIBUS PA or Foundatio
Fieldbus H1 integrated bus supply up to 1000 mA
with redundancy capabilityintegrated
diagnostics Degree of protection
IP20 for extended temperature range
Digital Input Module
SIMATIC DP
1 ELECTR
MODULE FOR ET 200S
8 DI DC 24V 15MM WIDTH
1 PIECE PER PACKAGING UNIT
