330400 Series

Interconnect Cable

Conductors: 20 AWG shielded twisted pairs
Voltage Rating: 60V DC max
Current Capacity: 2A per conductor
Impedance: 100Ω ±15%
Shielding: Foil + braid
Bend Radius: ≥5x cable diameter
Jacket Material: PVC (oil-resistant)

Interconnect Cable

Rack End: 16-pin male connector
Field End: Typically M12 connectors
Number: 16 individual shielded twisted pairs
Gauge: 22 AWG stranded copper

Interconnect Cable

Part Number: 16925-50
Description: Interconnect Cable Assembly
Conductor:Typically 22 AWG
Temperature Range:  -40°C to +105°C (-40°F to +221°F)

Extension Cable

Description:Shielded Extension Cable
Length:40 feet (12.2 meters)
Temperature Range:-40°C to +150°C (-40°F to +302°F)
Voltage Rating:300 V AC/DC
Bend Radius:Minimum 25 mm (1 in) during installation
Shielding Effectiveness:>90% noise rejection

Interconnect Cable

Description:Interconnect Cable (Extension Cable)
Length:30 feet (9.14 meters)
Conductor:Gauge 20 AWG stranded copper
Jacket Material:PVC (standard)
Voltage Rating:300 V AC/DC

Accessories

Individual M8 x 1 mountingadapter
Adapter Length:25.4 mm (1.0 inch)
Outer Diameter:16 mm (0.63 in)
Probe Thread: M8 x 1

Interconnect Cable

Length: 15 feet
Impedance: 95 ohms nominal
Cable Jacket: Shielded
Outer Sheath Material: PVC or Teflon

Interconnect Cable

Conductors:2 twisted pairs
Wire Gauge:24 AWG stranded copper
Shielding:Dual-layer:
Foil per pair
Overall braid (90% coverage)
Impedance:100 Ω ±15% (1 kHz)
Capacitance:≤35 pF/ft (pair-to-pair)
Max Voltage:300 V AC/DC
Resistance:≤28 Ω/1000 ft

10 meter Velomitor Interconnect Cable

Impedance:50 Ω ±10%
Capacitance:≤100 pF/m
Max Voltage:60 V DC
Current Capacity:4–20 mA
Outer Diameter:4.8 ±0.2 mm
Bend Radius:≥50 mm (static)

Interconnect Cable

Conductors:3 twisted pairs (6 conductors)
Wire Gauge:24 AWG stranded copper
Shielding:Dual-layer:
Individual foil per pair
Overall tinned copper braid (95% coverage)
Impedance:100 Ω ±10% (1 kHz)
Capacitance:≤30 pF/ft (pair-to-pair)
Max Voltage:300 V AC/DC (continuous)
Resistance:≤25 Ω/1000 ft (per conductor)

Interconnect Cable

3 twisted pairs (6 conductors total)
Wire Gauge: 24 AWG
Impedance: 100 Ω ±10%
Capacitance: ≤30 pF/ft (pair-to-pair)
Max Voltage Rating: 300 V AC/DC
Operating: -40°C to +120°C (-40°F to +248°F)

Interconnect Cable

Cable Length: 20 feet
Conductors: Coaxial design
Jacket: Oil-resistant PVC
Temperature Range: -40°C to +100°C
Voltage Rating:60V AC/DC
Capacitance:≤ 110 pF/meter
Resistance:≤ 0.1 Ω/meter

Interconnect Cable

Length:45 feet
3300 XL system impedance
Coaxial Center Conductor
Coaxial Shield (Common Ground/Return)
Separate Conductor (+VDC Excitation).

Interconnect Cable

Length:27 feet
Conductors:4 conductors (2 twisted pairs)
Wire Gauge:22 AWG stranded copper
Voltage Rating:300V AC/DC
Impedance:100 Ω ±15% (1 MHz)

Interconnect Cable

Length:32 feet (9.75 meters)
Conductors:4 conductors (2 twisted pairs)
Wire Gauge:22 AWG stranded copper
Insulation:Fluorinated Ethylene Propylene

Interconnect Cable

Model: 16925 - Interconnect Cables
Cable Length Option in feet: -35 - 33 ft
Capacitance: 50–60 pF/m
Impedance: 50 Ω
Voltage Rating: Operates within -24V DC
Signal Type: Supports low-voltage AC/DC
Temperature Range: -40°C to +150°C

Interconnect Cable

Sensor Proximity Probe Cable
Capacitance: 50–60 pF/m
Characteristic Impedance: 50 Ω or 93 Ω
Voltage Rating: Rated for -24 V DC
Temperature Range: -40°C to +150°C
Humidity: Resistant up to 95% non-condensing

Interconnect Cable

CABLE EXTENSION 26FEET
Cable Length:26 feet (7.92 meters)
Cable Type:Shielded Foil-Braid Coaxial
Center Conductor: Tinned Copper (20 AWG)
Insulation:High-grade PFAS
Dual-Layer: Aluminum Foil + 85% Braided Copper

Ingersoll Rand Proximity Probe

3300 NSv · 25" Length
Power Supply:-18 to -24 V DC
Output Signal: -2 to -18 V DC
Sensitivity: 200 mV/mil (7.87 V/mm)
Measurement Range: 0–80 mils (0–2.0 mm)
Frequency Response: 0 to 10 kHz
Probe: -30°C to +150°C (-22°F to +302°F)
Cable: Up to +125°C (°C short-term)

interconnect cable

Typically 50 Ohms
Operating Voltage:≤30 V DC
Proximity Probe End: BNC connector
Bend Radius: ≥10x cable
Operating: -40°C to +85°C
Storage: -50°C to +105°C

Interconnect Cable

Product Type : Interconnect Cable
16710 - Model: 3-conductor shielded 22 AWG (0.5 mm2)
armored cable with 3-socket plug at one end,
terminal lugs at the other end.
Minimum length of 3.0 ft (0.9 m)
maximum length of 99 ft (30m)

Interconnect Cable with Armor

3-conductor shielded 22 AWG(0.5 mm2)
armored cable with3-socket plug at one end
terminal lugs at the other end.
Minimum length of 3.0 ft (0.9 m)
maximum length of 99 ft (30 m)

Interconnect Cable

Conductors:2 twisted pairs
Wire Gauge:24 AWG stranded copper
Shielding:Individual foil + overall braid
Impedance:100 Ω ±10%
Capacitance:≤30 pF/ft
Max Voltage:300 V AC/DC
Resistance:≤25 Ω/1000 ft

Accelerometers

0 1 ¼-28 UNF integral stud
0 0 None
InputVoltage -24 ± 0.5 Vdc.
Bias Current 2 mA nominal.
Output BiasVoltage: -8.5 ± 0.5 Vdc.

Interconnect Cable

Product Type : Interconnect Cable
Model : 16710 - TEIP11-PS I/P Converter, signal converter for standard signals, with power stage
Cable Length Option : 20 - 20 ft
