ABB Advant OCS and Advant-800xA

PM856AK01 Processor Unit

3BSE066490R1
PROCESSOR UNIT PACKAGE
CPU (PM856A)
BASEPLATE (TP830)
CEX-BUS TERMINATOR (TB850)
MODULEBUS TERMINATOR (TB807)
BATTERY FOR MEMORY BACKUP (4943013-6)
Tariff Code: 85389091
Country of Origin: China

Digital Input Module

3BSE022362R1
I/O MODULE
DIGITAL
8 CHANNEL
230 V
DI803
Tariff Code: 85389091
Country of Origin: Sweden

Analog Input/Output Module

analog input/output module
8 AI,8 AO
U/I/Pt100
12 bits including sign
2-wires

DC551-CS31 Digital I/O Bus Module

1SAP220500R3001
DISCONTINUED BY MANUFACTURER
DC532 DIG IN/OUT MODULE

High Integrity Analog Input

3BSE039293R1
ANALOG INPUT MODULE AI880 8CH 0-20MA

EI 803F Ethernet Module 10BaseT

EI803F
DISCONTINUED BY MANUFACTURER
ETHERNET MODULE
10BASE-T
TWISTED PAIR
PRODUCT ID: 3BDH000017R1
Country of Origin: Germany

ANALOG OUTPUT MODULE

ANALOG OUTPUT MODULE
(AO820)
4 CHANNELS
+/-20 MA
0(4)-20MA
+/-10V
12 BIT + SIGN
INDIVIDUALLY ISOLATED
RL MAX 500 OHMS

Analog Input Module

Analog Input Module

Analog Input Module - TC/MV

3BSE008520R1
ANALOG INPUT
8CHANNEL
THERMOCOUPLE/MV
Tariff Code: 8538907080
Country of Origin: Sweden

TU515 I/O Terminal Unit

Function:
For analog and 24 VDC digital modules.
Screw terminals
Degree of Protection:IP20
Supply Voltage:24 V DC
Ambient Air Temperature:
Operation 0 ... +60 °C
Storage -40 ... +70 °C

DC523 Digital I/O Module

Number of Digital Configurable I/Os: 24
Input Voltage Type:DC
Input Current:5 mA
Maximum Input Voltage:0 ... 30 V
Delay Time (τ):0.1 … 32 ms
Output:Transistor
Output Voltage Type:DC
Output Voltage (Uout):24 V DC
Output Current:0.5 A
Output Voltage Maximum:20.4 … 28.8 V

Modulebus Optical Modem

3BSE013208R1
DISCONTINUED BY MANUFACTURER
ADAPTER MODULE
BUS CLUSTER
TB820V2
Tariff Code: 85389091
Country of Origin: China

AO810 Analog Output Module

Article number:3BSE038415R1
Type:Analog Output
Signal specification:0..20 mA, 4..20 mA
ZP or +24 V

FI 820F Fieldbus Module Serial

Model: FI820F
Product Line: AC800F
Supports DP-V0 and DP-V1
Voltage: 24 V DC (±20%)
Current Consumption: 100–150 mA
Operating Temperature:
-25°C to +60°C (-13°F to +140°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)
Relative Humidity: 5–95% (non-condensing)

Central Processing Unit

Central Processing Unit

ICMK14F1 Input/Output Module

Extensible remote
unitwith 8 isolated
inputs 24 V d.c.
and 6 relay
outputs 250 V a.c. / 2 A
24 V d.c.
power supply

Processor Unit Kit

3BSE050198R1
(PM866K01)
PROCESSOR UNIT
4 AMP
24 VDC
4 POSITION

Digital Output Module

32 channels for 24 V d.c
2 isolated groups (RIV50V)
with 16 channels and one process
voltage supervision input in each group
The process voltage range is 12-32V dc
(nominally 24V dc) and the maximum continuous
output current is 0.5A per channel

Digital Input Module

32 channels for 24 V d.c
inputs with current sinking
Two Isolated groups of 16 channels
with voltage supervision
Voltage Supervision
Signal Filtering

Bus Extender Board

3BSE019216R1
BUS EXTENDER BOARD
COMMUNICATION MODULE
DSBC 176

07KT98 Advant Controller 31 Basic Unit

Connection type: RJ45
Data rate: 100 Mbps
Duplex mode: Half duplex or full duplex
Auto-negotiation: Yes
LED indicators: Link, activity, and collision
Diagnostics: Link loss detection and cable fault detection
Compliance: IEEE 802.3
Operating temperature: -20 to +60 degrees Celsius
Storage temperature: -40 to +85 degrees Celsius
Humidity: 5 to 95% RH (non-condensing)
Vibration: 2g (10-500 Hz)

LD 800HSE Linking Device

Number of channels :4
Transfer rate:31.25 kbit/s
Port :9-pole SubD male RS-232, 115.2 kbit/s
Port :Ethernet 10BASE-T/100BASE-TX, TJ45
Transfer rates:10 Mbit/s or 100 Mbit/s (autosensing)
Storage temperature: −20° C ... +70° C
Operating temperature:0° C ... +55° C
Relative humidity :0% ... 95%, non-condensing

TU810V1 Compact Module Termination Unit MTU

3BSE013230R1
COMPACT MODULE
TERMINATION
2X8 SIGNAL
50V
TU810V1
MTU
I/O MODULE
Tariff Code: 8537.10.9060
Country of Origin: Sweden, Bulgaria

Advant Controller 31 Basic Unit - 07KT94

07KT94
I/O MODULE

Digital Input Module

3BSE008508R1
I/O INPUT MODULE
DIGITAL
16 CHANNEL
24 VDC
DI810
Tariff Code: 8538.90.7080
Country of Origin: Sweden
