SITOP PSU100L 24 V/10 A
Stabilized power supply input: 120/230 V AC,
output: DC 24 V/10 A
type of the power supply network:1-phase AC
supply voltage:120 V/230 V
input voltage:1 at AC:93 ... 132 V
input voltage 2 at AC:187 ... 264 V
line frequency:50/60 Hz
Model: DSQC509
Part Number: 3HAC5687-1
Type: Controller Panel
Input Voltage:AC 100-240V (50/60 Hz)
Output Voltage:24V DC
Output Power:Typically 100W or more (depends on load)
Current Rating:Around 4A at 24V DC
Efficiency: High efficiency for industrial use
Inputs:4 high speed sub-millisecond differential
Module Type:High Speed Analog Input / Ouptut Module
Outputs:2 high speed current-voltage
Input signals ranges:± 10V
0…10V; 0…5V; 0…20 mA
Input Resolution:14 bits across ±10.5V DC
12 bits across 21 mA
No. of Outputs 2 high speed current/ voltage
Output Resolution:13 bits across 21 mA = 2.8 µA/bit;
14 bits across 21.8V = 1.3 mV/bit
Output Signal Ranges:± 10V; 0…20 mA
SITOP PSU200M 5 A
stabilized power supply
input: 120/230-500 V
AC output: 24V DC/5 A
1-phase and 2-phase AC or DC
supply voltage at DC 110 ... 220 V
input voltage at DC 88 ... 350 V
SINAMICS S120
Single Motor Module
input: 600 V DC
output: 400 V 3 AC, 30 A
type of construction: booksize internal
air cooling optimized pulse patterns
and support of the extended
Safety Integrated functions
incl. DRIVE-CLiQ cable
Compatible Series:MICROMASTER 430 / 440
Voltage Class:400 V / 480 V
Power Rating Supported:7.5 kW – 55 kW
Control Voltage:15 – 24 VDC
Operating Temperature:0°C to +50°C
Storage Temperature:-25°C to +70°C
