OP1500
DISCONTINUED BY MANUFACTURER
OPTIMATE OPERATOR PANEL
WITH 5 FUNCTION KEYS
NUMERIC KEYPAD
AND 2 LINE X 20 CHARACTER LCD DISPLAY
WORKS WITH DL05/DL06/DL105/DL205/DL305/DL405
A-B SLC 5/03
SLC 5/04
MICROLOGIX
GE FANUC SERIES 90 MICRO
Input Voltage: 24V DC.
Rated Voltage Range: 20.4V DC to 28.8V DC.
Max Current Consumption: Typically 50 mA.
Relay Contacts Ratings: 250VAC, 3A, 30VDC.
Operating Temperature Range: Typically -20°C to +55°C
PC BOARD
SIGNAL CONDITIONING BOARD
INVERTER
Signal Compatibility:0–10 V DC, 4–20 mA
Power Supply:24 V DC ±10%
Operating Temp:0–60°C (32–140°F)
Isolation Voltage:≥1 kV
179116BC
DISCONTINUED BY MANUFACTURER 06/30/2015
I/O BLOCK MODULE
16 INPUT
16 OUTPUT
10-30 VDC
BLOCK I/O MODULE
24V DC
Tariff Code: 8538903000
Country of Origin: United States
ProcessLogix CPU Controller Module
Can be installed into any
two consecutive slots of the chassis
(default location is slots 1 and 2)
Operating Temperature Range: 0°C to 60°C
Storage Temperature Range: -40°C to 85°C
Relative Humidity: 5% to 95% non-condensing
Highly Intuitive Design Environment
Graphical Configuration
Live Updating Loop Drawings
One-Spot Engineering Environment
Common Database Integrating System
Control, Display
Field Device Configuration in One Tool
