Robicon G4 Power CELL

Robicon G4 Power CELL, 140A, 750V
Perfect Harmony Medium voltage drive
LDZ10500424.140
Voltage (DC Link): 750 V DC ±10%
Rated Current (Continuous): 140 A
Power Rating: 105 kW
Operating Temp.: Max cell temperature ≤85°C
Capacitors: 12,000 µF ±20% 900 V DC

CPU BOARD

CPU BOARD ELECTRONIC MODULE
FOR CONVERTER
RAM ≤ 256 MB
Flash ≤ 512 MB
Digital I/O:24 VDC, ±10%
Analog Inputs: 0–10 V/4–20 mA
Input Voltage: 24 VDC ±10%
Isolation: Reinforced (3000 VAC)
Max Power Draw: 20–50 W

REPLACEMENT IPD CARD

SINAMICS S120
Replacement IPD card
for air-cooled Basic Line Module
710kW 380-480V 3AC/1500A

FREQUENCY DRIVE POWER BOARD

Range: 320–1244 VDC
Current: 0.2–0.7 A
DC Input: 24 VDC
Output Power: 180 W
Efficiency: Likely ≥85%
Operating Ambient: 0°C to +50°C
Isolation: Input-to-output ≥2500–3000 VAC
Voltage Matching: 24 VDC

GEN5 VFD Power Cell

GEN5 VFD Power Cell
GH180 Medium Voltage Drives
Voltage Class:3.3 kV
DC Link Voltage: Standard 750 V DC
L-L Nominal:3.3 kV–6.9 kV
Continuous Output Current: 240–300 A

Pressure Transmitter

SITRANS P320 Pressure transmitter
7Mf0300-1Qf01-5Sf2-z
Pressure Range: Adjustable span
Accuracy: ±0.075% to ±0.25%
Response Time: ≤30 ms
Output Signal: 4–20 mA HART
Supply Voltage: 10.5–45 V DC

CPU Module

Processor Type: 32-bit or 64-bit RISC-based
Program Memory: 512 KB–8 MB
Data Memory: 64 KB–2 MB
Execution Speed: ~0.1–0.3 μs
Analog I/O:4–20 mA or ±10 V inputs
Voltage Rating: 24 VDC (±15%)
Power Consumption: 10–30 W
Operating Temperature: 0°C to 55°C (32°F to 131°F)
Storage Temperature: -25°C to 75°C (-13°F to 167°F)

Perfect Harmony Medium voltage drive

Voltage Class: Medium Voltage
Series: Perfect Harmony GH/VFD 180
Power Range: Up to 50–100 MW
Input Voltage 50/60 Hz, 3-phase
Output Voltage:0–60 Hz variable
Output Current (max):150–3500 A

Control panel

SINAMICS PERFECT HARMONY GH180 Drives CCB
Communication Interfaces:Fiber-optic loops
Input/Output:24-bit I/O
Power Supply:24 V DC (±20%)
Ambient Temp.:0°C – +50°C

Power unit fuses

DC link/integrated power module
Input rectifiers
Output IGBTs in drives
Voltage Rating:690–1000 VDC
Current Rating (Cont.):450–700 A
Interrupting Capacity:≥100–150 kA

CELL WITH SUBMODULE

Series: Innomotics G5 Drive
Function: Power Submodule for MV Drive Systems
Current Rating (Cont.):45 A
Voltage Rating:750 V DC
Overload Capacity:Up to 150% current for 60 s
Switching Frequency:Optimized ≤20 kHz
Topology:IGBT Half-Bridge Module

Air Filter Assembly

Airflow Capacity:≥15–40 m³/h
Filter Class:G4/F9 grade
Temp. Rating:−20°C to +70°C.
Pressure Drop:10–20 Pa
Material Standards UL94-V0
Housing Material:Galvanized steel or high-density plastic

Robicon MV Drive

Input Voltage:3-phase AC 6.6 kV
Output Frequency Range:0.0–120 Hz
Rated Power:5–40 MW
Output Voltage (Motor):3 kV to 6.6 kV
Overload Capacity:120% of rated current
Efficiency:>97%
Operating Temperature:0°C to +40°C
Ambient Humidity:Up to 95% non-condensing

DC Power Supply

Series: NXGPRO Plus NCP
Input Voltage:90 – 290 V AC ³ph
Output Voltage (DC):±24 V/48 V DC
Rated Current Per:Cell ≥200 A
Power Rating:6 kW per cell
Efficiency:≥95%
Resilient Networks: -48 V/24 V

POWER SUPPLY I/O BOARD

GH180 NXGpro USER I/O board
Voltage Input:24 V DC (±10%)
Mounting: Secured within GM150 Cabinet
Operating Temperature: 0°C – 55°C
RUN/STOP: Operational mode of the board

Robicon Power Module

Voltage: 380–690V AC (±10%), 3-phase
Frequency: 50/60 Hz.
Nominal: 930V DC
Control Circuit Voltage: 24V DC (±15%)
Analog inputs :0–10V, 4–20mA
Temperature: -10°C to +50°C (derate 2% per °C above 40°C)
Humidity: <95% non-condensing

GH180 POWER CELL

Series: SINAMICS Perfect Harmony GH180
Type: Medium Voltage (MV) Power Cell
Phase Voltage:230/690 VAC input
Cell Output DC Link Voltage:750–950 VDC
Rated Current (Continuous):200–300 A
Switching Frequency:≤250 Hz
Efficiency:≥97%

Interface Module

SIMATIC ET 200SP
PROFIBUS bundle IM
IM 155-6DP HF, max
32 I/O modules and 16 ET 200AL modules
Multi-hotswap
bundle consists of: Interface module (6ES7155-6BU01-0CN0)
Server module (6ES7193-6PA00-0AA0)
PROFIBUS connector (6ES7972-0BB70-0XA0)

SINAMICS S120 CONTROL UNIT

SINAMICS S120
CONTROL UNIT CU310-2 PN
WITH PROFINET INTERFACE
WITHOUT COMPACTFLASH CARD

Variable Speed Drives

SINAMICS G120C
rated power: 45.0 kW with 150%
overload for 3 s.
380-480 V 3AC +10/-20% 47-63 Hz
unfiltered I/O interface: 6 DI, 2 DO, 1 AI, 1 AO
Safe Torque Off integrated fieldbus
integrated: PROFINET-PN degree of protection IP20/UL
external 24 V

CompactFlash card

SINAMICS S120
CompactFlash card
incl. performance expansion
V4.8

Adapter Cable

SINAMICS S120
C/D Type Adapter Cable
FOR MOTOR CONNECTION
2,5MM2 FOR MOTOR MODULES 3-18A

GH180 Power cell

SINAMICS PERFECT HARMONY
GH180 Power cell 200 A GenIV
Power supply unit SL10 230 V
AC/48V DC Pulse

Smart Line Module

SINAMICS S120
Smart Line Module
380-480V 3AC, 50/60 Hz
Output: 510-650 V DC, 1300 A
Rated power: 630kW Built-in unit
IP00 Internal air cooling
incl. Drive-CLiQ cable

CompactFlash card

SINAMICS S120
CompactFlash card
incl. performance expansion
V5.2 Service Pack 3
