COBUX-HW INTERFACE CARD

Type: COBUX-HW Interface Card
Operating Voltage:24V DC
Operating Temperature Range:-20°C to +70°C
Storage Temperature Range:
-40°C to +85°C.
Analog inputs: 0–10 V, ±10 V, 4–20 mA
Analog outputs: 0–10 V, 4–20 mA

SOE Time Keeper Master

Analog inputs: 0–10 V, 4–20 mA
Analog outputs: 0–10 V, 4–20 mA
Power Supply:24 V DC (±10%)
Supply Voltage：24V DC (19.2–28.8V) via backplane
Power Consumption：1.8W (typical), 2.5W (max)
Isolation 1500V AC (channel-to-logic)

Control Board

Power Supply:24 V DC
Differential: ±12 V.
Power consumption: < 5 W
Single-ended: 0–24 V
Output Voltage:
TTL: 0–5 V.
HTL: 0–24 V

Pulse Input Module

8 pulse input channels
Voltage Range: 5–30 V DC
Standard: 0–10 kHz
Frequency Measurement: ±0.01% of reading
Channel-to-Channel Isolation: ≥ 1500 V AC/DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)
Humidity:
0–95% non-condensing

Pulse Input Baseplate

Frequency/Rate: Up to 10 kHz
Voltage Range: 5–30 V DC
Counting Resolution: 24-bit
Frequency Accuracy: ±0.01%
Channel-to-channel isolation: ≥ 1500 V AC/DC
Field-side Power: 24 V DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)

DIGITAL MONITORING MODULE

Analog inputs:4–20 mA, 0–10 VDC
Power Supply: 24 VDC or 110–240 VAC
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Humidity: 5–95% RH (non-condensing)

DRIVE CONTROL UNI

DRIVE CONTROL UNIT
Input Voltage: 24 VDC
Analog inputs (0–10 VDC, 4–20 mA)
Operating Temperature:
0°C to +40°C (+32°F to +104°F)
Storage Temperature:
-40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% RH (non-condensing)

CIRCUIT BOARD

Voltage: 24 V DC (±10%)
Power Consumption: ≤4 W
Digital I/O: 24 V DC
Analog I/O: 4–20 mA, 0–10 V
Field-to-System: 1500 V AC reinforced isolation.
Channel-to-Channel: 250 V AC
Operating Temperature: -25°C to +70°C (-13°F to +158°F).
Storage Temperature: -40°C to +85°C (-40°F to +185°F).
Humidity: 5–95% (non-condensing)

Signal Processing Module

Voltage: 24 V DC (±10%)
Power Consumption: ≤5 W
Input Channels: 16 channels
Types: 4–20 mA, 0–10 V, RTD
Resolution: 16-bit ADC
Digital Inputs: 24 V DC
Field-to-System: 1500 V AC reinforced isolation.
Channel-to-Channel: 250 V AC
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5–95% (non-condensing)

Server motherboard

Slots: 4x DDR4 DIMM slots
Capacity: Up to 128 GB ECC RAM
Operating Temperature: 0°C to +60°C (32°F to +140°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 10–90% (non-condensing)
Vibration Resistance: 5–500 Hz
Ethernet Ports: 4x 10/100/1000 Mbps (RJ45)
with optional 1 Gbps/10 Gbps SFP+ fiber ports
Protocols: PROFINET, EtherNet/IP, OPC UA, Modbus TCP

Signal concentrator board

Voltage: 24 V DC (±10%)
Power Consumption: ≤6 W
Input Channels: 32 channels
Digital Inputs: 24 V DCc
Analog Inputs: 4–20 mA, 0–10 V, RTD
Channel-to-Channel: 250 V AC
Field-to-System: 1500 V AC reinforced isolation
Ethernet Port: 10/100 Mbps (RJ45) for integration with PLC networks
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)

Control board

Voltage: 24 V DC (±10%)
Power Consumption: ≤10 W
Processor: 32-bit ARM Cortex-R5F
Clock Speed: 500 MHz
Channels: 32 channels
Voltage: 24 V DC
Field-to-System: 1500 V AC reinforced isolation
Channel-to-Channel: 250 V AC
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5–95% (non-condensing)
Vibration Resistance: 5–100 Hz

Control Board

Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
RAM: 1–2 GB DDR3
Storage: 4–8 GB Flash
Video Input: VGA/HDMI for external display connectivity.
USB Ports: 2x USB 2.0/3.0 for peripherals

VDU Board

Voltage: 24 V DC (±10%)
Power Consumption: ≤15 W
RAM: 1–2 GB DDR3
Storage: 4–8 GB Flash
Video Input: VGA/HDMI for external display connectivity.
USB Ports: 2x USB 2.0/3.0 for peripherals (e.g., keyboard, mouse).
Ethernet: 10/100/1000 Mbps (RJ45) for network integration

Channel Control Unit

Voltage: 24 V DC (±10%)
Power Consumption: ≤4 W
Digital: 24 V DC (sink/source).
Analog: 4–20 mA, 0–10 V
Analog inputs: ±0.05% of full scale (at 25°C).
Digital response time: ≤1 ms
Overvoltage Protection: ±30 V

Channel Control Unit

Voltage: 24 V DC (±10%)
Power Consumption: ≤4 W
Digital: 24 V DC (sink/source).
Analog: 4–20 mA, 0–10 V
Analog inputs: ±0.05% of full scale (at 25°C).
Digital response time: ≤1 ms
Overvoltage Protection: ±30 V
Removable screw terminals (0.2–2.5 mm² / AWG 24–12)

CONNECTION UNIT

Model: PFSK108
Part Number: YM322001-EH
Voltage: 24 V DC
Wire Gauge Support: 0.2–2.5 mm²
Max Current: 10 A
Digital I/O (24 V DC).
Analog signals (0–10 V, 4–20 mA).

Analog Input Module

Model: PFSK110
Part Number: YM322001-EP
Voltage: 24 V DC (±10%)
Power Consumption: ≤3 W
Voltage: 0–10 V, ±10 V
Current: 0–20 mA, 4–20 mA
Accuracy: ±0.1% of full scale (25°C)
Sampling Rate: 100 samples/sec per channel
Operating Temperature: -20°C to +60°C (-4°F to +140°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5–95% (non-condensing)
Vibration Resistance: 5–100 Hz

Signal Processing Control PLC Circuit Board

Model Number: PFSK106
Part Number: YM322001-EC
Voltage: 24 V DC (±10%)
Power Consumption: ≤5 W
Digital Inputs: 16 channels
Flash: 512 KB
Analog Inputs: 8 channels

Power Factor Controller

Sensitivity: ≥ 20 mA.
Frequency range: 50 or 60 Hz +/- 5%
Input current impedance: < 0.1 Ohm
Controller energy consumption: ≤ 15VA
Maximum inductive load AC 250V/2.0A
Voltage: ±1%
Current: ±1%
Power factor: ±1.5%
Active power: ±2.5%
Reactive power: ±2.5%

OUTPUT MODULE

OUTPUT MODULE
SYMPHONY PLUS
DIGITAL
16 CHANNEL
OPEN COLLECTOR

Digital Input Module

DIGITAL INPUT MODULE
SYMPHONY PLUS
INFI 90
DI Module. 16 CH
Universal, 32 Jumpers

Universal Signal Converter

Brand:ABB
Input Range:0 → 10 V, 0 → 20mA
Mounting Type:DIN Rail
Operating Temperature Range:-20 → +60°C
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:+60°C

Quad Processor Pack

Two -synchronous- processors
Flash memory for system and applicationprogram
RAM with battery backup (battery located inBKM-0001)
Data comparators for the processors and theirmemory
Minimum and maximum execution timemonitor
Memory error handler
1oo2D functionality
24V and 5V monitoring
Emergency Shut Down Input (24V)
Two outputs (for non-redundant resp.redundant IO)

ACTUATOR

MODUTROL IV MOTOR
NON-SPRING RETURN
FOOT MOUNTED
4-20 MA MODULATING CONTROL SIGNAL
160 DEGREE STROKE
15-30 SECONDS TIMING
8.5 NM / 75 LB-IN TORQUE RATING
15 VA
120 VAC
50/60 HZ
