Bently Nevada

991 Thrust Transmitter

25 25-0-25 mils
70 7.0 meters (23.0 feet)
03 DIN clips and screws
05CSA Division 2, ATEX Zone 0
ATEXZone 2 and includes
ABSmaritime approval

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
Minimum unthreaded length: 0.0 in
Minimum case length:  0.9 in
70 7.0 meters (23.0 feet)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probe

330103    3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL Proximitor Sensor

3300 XL Proximitor Sensor
12 1.0 meter (3.3 feet) system length
nomounting hardware
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Reverse Mount Probes

3300 XL 8 mm Reverse Mount Probes
330106-05-30-CC-DD-EE M10 x 1 threads
05 0.5 meter (1.6 feet)
12 Miniature ClickLoc coaxialconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 2.3 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Low Voltage DC Power Supply

Power Supply Type (Top Slot)
04 Legacy Low Voltage DC (20 to 30 Vdc)
Power Supply Type (Bottom Slot)
04 Legacy Low Voltage DC (20 to 30 Vdc)
114M5330:Low Voltage DC Power Supply

3300 XL NSv Proximitor Sensor

3300 NSv Probe
3/8-24 UNF thread
withoutarmor
5 1 5.0 metre (16.4 feet) systemlength
DIN mount
05 Multiple approvals

3300 XL 11 mm Proximity Probes

330704   3300 XL 11 mm Probe
M14 x 1.5 thread,with armor
Minimum length:100 mm
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 Multiple Approvals

INTERCONNECT CABLE

Impedance:50Ω ±10%
Capacitance:30pF/ft max
Voltage Rating:300V RMS
Shielding:100% coverage
Conductor Gauge:22 AWG
Outer Diameter:6.0mm ±0.2mm
Max signal frequency: 50kHz

3300 XL 8 mm Proximity Probes

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 40 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 NSv Proximity Probes

330902 3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length: 1.5 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

Proximity Probe HousingAssemblies

28 3300 XL 8 mm probe, multiple approvals
05 0.5 m (20 in)
3.5 in (88.9 mm) = 35
3.2 in (81.28 mm) = 032
03 Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for the
following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

3300 XL 11 mm Proximity Probes

330707  3300 XL 11 mm Probe
5/8-18 UNFthread, without armor
Minimum case length: 2.5 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 8 mm Proximity Probes

330102  3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
Minimum case length: 3.6 in
05 0.5 meter (1.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
030 3.0 meters (9.8 feet)
00 Standard cable
05 CSA, ATEX, IECEx  Approvals

Proximity ProbeHousing Assemblies

21000 aluminum probe housing assembly
27 3300 XL NSv probe, selectablehazardous area approvals
05 0.5 m (20 in)
Maximum length 4.0 in (101.6 mm)
2.6 in (25.4 mm) = 026
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Proximity Probe HousingAssemblies

27 3300 XL NSv probe, multiple approvals
05 0.5 m (20 in)
No standoff adapter = 00
3.5 in (88.9 mm) = 035
03Two plugs, one 3/4-14 NPT fitting
One 3/4-14 to 1/2-14 NPT SST reducer
One cable seal grip with grommets for the
following cable sizes
• 1/8 to 3/16 inches
• 1/4 to 5/16 inches
• 5/16 to 3/8 inches
02 3/4-14 NPT

3300 NSv Proximity Probes

330901  3300 NSv Probe
1/4-28 UNF thread,without armor
Minimum unthreaded length: 2.0 in
Minimum case length: 3.2 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330103  3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 100 mm
Minimum case length: 120 mm
05 0.5 meter (1.6 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

Standard Interconnect Cable

Conductors: 3 × 22 AWG (0.5 mm²)
Capacitance: ≤100 pF/m
Length Range:25ft
Shielding: Braided copper shield (≥85% coverage)

3300 NSv Proximity Probes

330905 3300 NSv Probe
M10X1 thread,without armor
Minimum unthreaded length:0 mm
Minimum length: 90 mm
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Extended TemperatureRange (ETR) Reverse Mount Probes

3300 XL 8 mm
Extended TemperatureRange (ETR)
Reverse Mount Probes
330196-05-30-CC-DD M10 x 1 threads
10 1.0 meter (3.3 feet)

3300 XL 8 mm Proximity Probes

330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 50 mm
Minimum case length: 180 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable

3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
045 4.5 meters (14.8 feet)
02 Standard cable with connectorprotector
