3300 NSv Proximity Probes
5.3 ± 0.7 3300 NSv Probe 3/8-24 UNF thread withoutarmor Maximum unthreaded length: 9.2 in Minimum unthreaded length: 0.0 in Example: 0 4 = 0.4 in 7.0 metres (23.0 feet) 0 5 Multiple Approvals
Velomitor Piezo-velocity Sensors
03 1/4 - 28 UNF 00 Not required Connector 2-pin Mil-C-5015hermetically-sealed 316Lstainless steel shell
3300 XL 8 mm Reverse Mount Probes
Total length option : 10 = 1.0 metre (3.3 feet) Connector option : 02 = Miniature ClickLocTM coaxial connector Agency approval option : 00 = Not required Probe tip material : Polyphenylene sulfide (PPS). Probe case material : AISI 303 or 304 stainless steel (SST).
Proximitor Sensor
Replaces 3300 RAM Transducer Systems and 3000-Series or 7000-Series 190 Transducer System Average Scale Factor of 7.87 V/mm (200 mV/mil)
Hydro Monitor
Powerconsumption 7.7 watts, typical Multimodepositive inputI/O 50 kΩ Direct filter0.104 Hz to 500 Hz Rotor speed is 25 to 1,500 cpm. Gap filter -3 dB at 0.05 Hz Direct filter -3dB at 1.2 Hz
Velomitor Piezo-velocity Sensor
Sensitivity3.94mV/mm/s (100 mV/in/s)±5% Velocity Range 1270 mm/s (50 in/s) peak. TransverseSensitivityLess than 5% of sensitivity AmplitudeLinearity±2% to 152 mm/s (6 in/s)peak. Output BiasVoltage-12 ±3.0 VDC overtemperature referenced toPin A DynamicOutputImpedanceLess than 2400 Ω Grounding Case isolated
