Technical specifications for 330851-02-000-060-10-01-05
-
Product Model330851-02-000-060-10-01-05
-
Product Parameters3300 XL 25 mm Proximity Probe
-
Tariff Code8537101190
-
Country of originUSA
-
Place of shipmentXiamen, China
-
Estimated Shipping Size2.8x2.8x115cm
-
ManufacturerBently Nevada
-
Weight0.34 kg
-
Probe Case Type OptionM30x2 thread
-
Unthreaded Length Option0 mm
-
Overall Case Length Option0.6 in
-
Total Length Option1.0 metre (3.3 feet)
-
Armor Optionwith SST Armor
-
Agency Approval OptionMultiple Approvals
Description
02 M30x2 thread
MinimumUnthreadedLength 0 mm
MinimumUnthreadedLength 0.6 in
10 1.0 metre (3.3 feet)
01 with SST Armor
05 Multiple Approvals
MinimumUnthreadedLength 0 mm
MinimumUnthreadedLength 0.6 in
10 1.0 metre (3.3 feet)
01 with SST Armor
05 Multiple Approvals
Information
Overview
Manuals
Technical notes
Product Applications
Mechanical Mounting & Target Considerations
Features:
- Two transducers observing the same side of a collar
- Two complementary input transducers observingopposite sides of a collar, effectively doubling themeasurable DE range
- Extreme High-Temperature Capability
- Dual-Seal Moisture Protection Design
- High Electromagnetic Compatibility & Certifications
Two transducers with at least one transducer viewing a rampon a rotor and the second transducer viewing either a separateramp or a different location on the rotor to compensate forradial movement. This arrangement adds some error to themeasurement, but can measure a longer total DE distance thanthe complementary measurement.
The 330851-02-000-060-10-01-05 Bently Nevada 3300 XL 25 mm Proximity Probe may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Bently Nevada 330851-02-000-060-10-01-05 3300 XL 25 mm Proximity Probe Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
The 3300 XL 25 mm probe is designed formaximum survivability in the harshest steamturbine DE environments. It can continuallyoperate and maintain its accuracy in hightemperatures up to 200 °C (392 °F), and canwithstand intermittent high temperatures up to250 °C (482 °F). The 25 mm probe has both afront and rear seal which, combined with theFluidLoc* cable (standard on all 25 mm probes),prevents moisture from entering the probe tip. Special high-temperature ClickLoc connectorsare also standard on the probe and extensioncable. Each probe and cable are provided withconnector protectors and a disposableconnector protector installation tool to ensurethat the connectors remain free ofcontamination. The ClickLoc connector on theprobe lead has a removable collar thatfacilitates routing the cable through tightclearances.
- Large Gas Turbines:Thrust position & mode shape analysis monitoring
- Mid-to-Large Steam Turbine Generators:Measures differential expansion to maintain internal clearances
- Mining and Minerals:Large-scale lifting & ventilation for deep mine operations
- Pulp and Paper Mills:Drying cylinders & power boilers: vibration/thermal expansion critical
- Steel and Metal Mills:Monitors large rolling mill drives & critical rotating equipment
- Petrochemical & Refining Facilities:Manages high-temp/pressure in large process compressors & turbines
- Power Generation Plants:Monitors steam turbine rotor axial movement in coal/hydro/combined-cycle
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Target Size: For maximum accuracy, use a flat AISI 4140 steel target with a minimum diameter of 61 mm (2.4 in).
Sliding Brackets: It is highly recommended to use the 3300 XL Sliding Bracket for differential expansion (DE) applications. This allows you to physically move the probe to simulate shaft motion and verify the system during commissioning.
Locking: The M30x2 threaded case comes with a locknut that includes pre-drilled safety wire holes to ensure the probe does not loosen under machine vibration
FAQs
-
What is the 330851-02-000-060-10-01-05 used for?
+It is a 3300 XL 25 mm proximity probe used for machinery condition monitoring, specifically for measuring differential expansion (DE) on mid-size to large steam turbine generators due to differences in growth rates between the machine stator and the rotor. -
What is the temperature range for this probe?
+The probe is rated for operation and storage between -35°C to +200°C (-31°F to +392°F). It can handle short-term temperatures up to +250°C (+482°F) for less than 24 hours -
What is the length of the 330851-02-000-060-10-01-05 system?
+The probe is part of a system with a total length of 1.0 meter. -
What is the 330851-02-000-060-10-01-05 output voltage?
+The system operates at 0.787 V/mm (20 mV/mil) with a linear range of 12.7 mm (500 mils)
