General Electric

VME VIBRATION CARD

IS200VVIBH1C
DISCONTINUED BY MANUFACTURER
PC BOARD
VME VIBRATION CARD

MK6 GAS TMR PK TURBINE CARD

MARK VI THERMOCOUPLE

IS200VTCCH1
DISCONTINUED BY MANUFACTURER
THERMOCOUPLE CARD
MARK VI

GAS TMR PK,MK6 Servo card

IS200VSVOH1B
DISCONTINUED BY MANUFACTURER
PC BOARD
VME SERVO CARD
W/J55 TERMINAL PORT

DIGITAL CARD

IS200VCRCH1B
DISCONTINUED BY MANUFACTURER
CIRCUIT BOARD
SPEEDTRONIC
TURBINE CONTROL

VME Analog Input Board

Mark VI
Contact Input Group
Isolation terminal board
24 channels per VAIC board
16-bit A/D converter
with 14-bit resolution

TERMINATION BD., VIBRATION

Series: Mark VI
Product Type: Vibration Terminal Board
Trip Solenoids: 3
Solenoid Rated Voltage/Current: 125 V dc
Temperature rating: 0 to 60 oC
Number of Channels: 13

RELAY TERM BOARD

Power Distribution
6 Fused Branches
1 Special Unfused
Relays
12 Form C Relays, 24 DC 3A
125 DC .6A, 120/240 AC 3A

Contact Input Terminal Board

16 digital contact input channels
24 VDC (nominal)
Input Type: Dry contact inputs
4-8 mA per channel when active
Nominal Supply Voltage: 24 VDC
Current Consumption: Typically 150 mA
Maximum Supply Voltage: 30 VDC

POWER SUPPLY/MARK VI/WITH-335V

IS2020RKPSG3A
DISCONTINUED BY MANUFACTURER
POWER SUPPLY
MARC VI
SPEEDTRONIC SERIES
VME RACK
FOR USE WITH GE STEAM / GAS TURBINE MANAGEMENT SYSTEMS

GE BACKPLANE ASM BOARD

CONTROLLER, VME, EMI

IS415UCVHH1A
CONTROLLER

Profibus Master Module

Brand:GE Intelligent Platforms/GE Fanuc
Series:PACSystem RX3i
Manufacturer:GE Fanuc
Part Number:IC695PNC001
Profinet Controller Module:CPU Compatibility Requires
Product Line:RX3i
Catalog:IC695
One (1):Mounting location
Product Type:PROFINET Controller
Main rack only:Protocol Support
Number of Slots:1 (single slot)
PROFINET Version 2.2 General Class A:Communication Ports
Backplane Support:Universal Only
Internal Power at 3.3 V DC:0.5 A
Four (4):IO-Devices per IO-Controller
CPU Status Bits:32
Internal Power at 5 V DC:1.5 A
Port Connectors:Two RJ-45 and two SFP Cage

VME CONTROLLER CARD

High-speed PowerPC processor
≥1.2 GHz
 2–4 GB DDR3/DDR4
8–16 GB Flash memory
Backplane integration with I/O modules
Dual 1 Gbps ports for PROFINET

POWER SUPPLY/MARK VI/WITH-335V

Functional Description:VME Power Supply Module
Product Series:SPEEDTRONIC Mark VI Turbine Control
Manufacturer:GE General Electric
Functional Acronym:RKPS
Instruction Manual:GEI-100567
Input Voltage:125VDC
Output Rating:400W
PCB Coating:Normal Coating

TERMINATION BD., TURBINE

IS200TTURH1B
DISCONTINUED BY MANUFACTURER
PC BOARD
TERMINATION BOARD
TURBINE DEVICES
MARK VI

TERMINATION BD., SERVO

IS200TSVOH1B
TERMINAL BOARD

Primary Trip Terminal Board

Series: Mark VI
Product Type: Terminal Board
Trip Solenoids: 3
Solenoid Rated Voltage/Current: 125 V dc
Solenoid Response Time: L/R time constant is 0.1 sec
Current Suppression: Metal oxide varistor
Control Relay Coil Voltage Supply: 28 V
Flame Detector Supply Voltage/Current: 335 V dc
Flame Detectors: 8

Turbine Emergency Terminal Board

Series: Mark VI
Number of Channels: 6
Power Supplies: 200-250Vac
Operating Temperature: 0°C to 70°C
Operating System: QNX
Number of trip solenoids: 3
Bus voltage: 70 to 145 V d

Bus Interface Unit (BUI)

Series:Field Control
Manufacturer:GE Fanuc
Part Number:IC670GBI102
Product Type:Profibus Bus Interface
Type:Bus interface unit
Product Family:Field Control
Current output to modules:2:00 AM
Power Supply Output:6.5 Volts DC
Holdup time:10 ms
Power supply:24 VDC

Ethernet Interface Module

Manufacturer:GE Fanuc
Series:Series 90-30
Part Number:IC693CMM321
Module Width:Single Slot
Number of Ports:Three (3)
Number of LED Indicators:Four (4)

Standard Power Supply module

Part Number:IC693PWR321
Series:90-30 PLC
Brand:GE Fanuc
Product Type:Standard Power Supply
Protocol Support:RS485
No. of Outputs:Three (3)
Input Voltage Range, AC:85 to 264 VAC
Input Voltage Range, DC:100 to 300 VDC
Description:Power supply
Voltage:85-264 Volts AC / 100-300 Volts DC
Voltage output:5/24 Volts DC
Communication:RS 485
Power:30 watts
Installation:Leftmost slot of the baseplate

relay output module

Series:Series 90-30
Part Number:IC693MDL940
Minimum Load:10 mA
On Response Time:15 ms maximum
No of Channels:Sixteen (16)
Contact Form:Normally Open (N.O.)
No. of groups:Four (4) groups
Inrush Current:5 Amperes
Outputs per Module:16
Maximum Inrush:5 Amps
Product Lifecycle Status:Discontinued/Obsolete

positive logic output module

Series:Series 90-30
Part Number:IC693MDL740
Product Description:Positive Logic output module
Module Circuit type:Sourcing
No of Channels:Sixteen (16)
Nominal Voltage output:12/24 volts DC
No. of groups:Two (2) groups
Inrush Current:4.78 Amperes for 10 ms
Output Voltage Drop:1 volt maximum
ON Response time:2 ms maximum
Product type:Digital I/O
Compatibility:GE Fanuc 90-30 PLCs
Output points:16
Module peak current draw:110 milliamps
Module input voltge 5 Volts DC
Relative humidity:5 to 95%

Discrete input module

Series:Series 90-30
Manufacturer:GE Fanuc
Part Number:IC693MDL340
No of Channels:Sixteen (16)
No. of groups:Two (2)
Product Type:Output Module
No. of channels per group:Eight (8)
Rated Voltage:120 V AC
Nominal output voltage:120 VAC
Frequency:50 to 60 Hz
Output current per point:0.5 A
Outputs:16
Output current per group:3:00 AM
Min. Output Leakage Current:1 ms
Minimum Load Current:50 mA
Inrush current:20 A for one cycle
