3300XL 11mm Extension Cable

080 8.0 meters (26.2 feet)
12 FluidLoc cable with connectorprotector
00 Not required
3.94 V/mm (100 mV/mil) Output
Long Linear Range
Thin Design

Digital Output Module

DO 24V Buss IOTA
Output Channels:32
Output Type:Source
Load Voltage:15 30 VDC Maximum
Galvanic Isolation:1500 VAC RMS or ±1500 VDC
On-State Voltage:24 V (typ), load current @ 0.5A
Off-State Voltage:0v VDC (max)
Off-State Leak Current:5.0 µA (max)

INVERTER MODULE

INVERTER MODULE
PCB MODULE
AMC 34

Stratix 5400 12 Port Managed Switch

Diagnose-Repeater for Profibus DP

POINT I/O 2 Point Analog Output Module

Module Type:Analog Output Module
Series:POINT I/O
Part Number/Catalog No.:1734-OE2C
No. of outputs:Two (2) Single-ended, non-isolated channels
Output signal:0-20 mA; 4-20 mA
Absolute Accuracy:0.1% Full Scale @ 25 Deg. Celsius
Step Response (63% of FS):24 µs
Converter Type:Digital to analog converter
Data Format:Signed Integer
Current Draw:75 mA @5V dc

POINT I/O Terminal Base

Part Number/Catalog No:1734-TB
Series:POINT I/O
Module Type:Terminal Base
Positions:8
Clamp Type:Cage-Clamp RTB

Current Output Module

Number of output channels 8 channels, module isolation
Rated output range 4 to 20 mA
Maximum range of guaranteed precision 1.25 to 23 mA
Output range 1.25 to 23 mA
Allowable load resistance @ rated range 230 to 600 Ω
Accuracy ±48 µA
Data update frequency 40 ms
Temperature drift ±16 µA/10 ºC

Resistance Module

Converter Type:Sigma-Delta
Product Family:MicroLogix
Inputs:4
Heat Dissipation:1.5 Watts
Product Type:RTD / Resistance Input Module
No. of Inputs:Four (4)

CU240E-2 DP Control Unit

SINAMICS G120 CONTROL UNIT
CU240E-2 DP E-TYPE SAFETY
INTEGRATED STO PROFIBUS DP 6DI,
3DO, 2AI, 2AO, MAX 1F-DI PTC/KTY
INTERFACE USB- AND SD/MMC-INTERFACE
PROTECTION IP20 AMBIENT TEMP
0 TO +50 DEG C
WITHOUT POWER MODULE AND PANEL

Inverter Memory Card

Memory Type:Flash memory
Capacity Typically 512 MB
Operating Temperature:-20°C to +70°C
Storage Temperature:-40°C to +85°C
Compliance:RoHS, CE

3300 XL 8 mm Probe

3300 XL 8 mm Probe, M10 x 1 thread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm

SERVOMOTOR 1FL6 3AC 400V

Power Module

EM231 Analog Input Module - RTD

EM231 Analog Input Module

ArmorPoint 16 Point Input Module

Machinery protection card

Measurement range: 0.001 gpm to 2.0 gpm
Resolution: 0.0001 gpm
Frequency range: 2 Hz to 10 kHz
Sensor type: piezoelectric sensor
Display mode: Color LCD display screen
Interface: RS232, USB

Video Module

Analog Module

3300 XL 8 mm Proximity

3300 XL 8 mm Probe
M10 x 1 thread,without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

Safety Stop Board

SSB module
Safety Stop Board
SIMOVERT Master drives
(only SSB module)

Digital Output Module

SIMATIC S7
digital output SM 326
F-DO10x 24 V DC/2A PP
fail-safe digitaloutput for SIMATIC S7F systems
with diagnostic alarm, LVV
up to Category 4(EN 954-1)
SIL3 (IEC61508)/PLE (ISO13849)
1x 40-pole

Weighing Module
