Communications processor CP 443-1
2x 10/100 Mbit/s (IE switch)
RJ45 ports; ISO; TCP; UDP
PROFINET IO controller
S7communication
Open communication (SEND/ RECEIVE)
S7routing; IP configuration via DHCP/ Block
IP Access Control List;Time synchronization
extended web diagnostics
Fast Startup
Support for PROFIenergy
Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695ALG600
Module Type:Universal Analog
No of Channels:Eight (8)
Number of Inputs:8 general purpose
No. of groups:Two (2)
Cold Junction Compensation:2 channels
No. of channels per group:Four (4)
Power Dissapation:5.4W max
Humidity:5 to 95%, non-condensing
Module conversion method:Sigma-delta
Module resolution:11-16 Bits
Internal Power:3.3V: 350mA; 5V: 400 mA
Input Signal andRaw Signal Voltage Range-1 V to -22 V
Frequency Range 0 to 18750 Hz
Supply Voltage -23.25 V / -26.0 V DC
Maximum Supply Load 35 mA
Supply Gain Accuracy ±3.5%
Supply Offset Accuracy +100 µA / -0 µA
Supply Voltage Reserve + 25 V
Supply Temperature Drift ±50 µA
Supply voltage:24 V DC
permissible range:+18 V to +30 V DC
Type of voltage:DC
Rated current:0.24 A
Operation (vertical installation):
0 °C to +50 °C
Transport, storage:-20 °C to +60 °C
Series: UFC Series
Voltage Rating: Typically 24V DC
Operating Temperature Range: Typically -20°C to 60°C
Storage Temperature Range: Typically -40°C to 85°C
Humidity: 5% to 95% RH (non-condensing)
SIMATIC S7-300
Front connector
with screw contacts
40-pole
Connection method Screw terminals
Number of lines per connection 1;
Or 2 cables up to 0.75 mm² (total)
in a shared end sleeve
Tool Screwdriver, conical design, 3 mm to 3.5 mm
Nominal Voltage: 24 V DC
Operating Temperature: 0°C to +70°C (32°F to 158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5% to 95% non-condensing
