SIMATIC S7-400H
CPU 414H central processing unit
for S7-400H and S7-400F/FH
4 interfaces: 1 MPI/DP
1 DP and 2 for sync modules
1.4 MB memory
(700 KB data/700 KB program)
Input Type:Voltage, current
Input Channels:16 Channels
Common Mode Voltage, dc to 60 Hz:-6 to +5 V peak
A/D Converter Resolution:16 bits
Input Range:1 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA
Normal Mode Rejection Ratio, at 60 Hz:19 dB
Normal Mode Filter Response:Single-pole RC, -3 dB @ 6.5 Hz
Maximum Normal Mode Input:± 30 Volts
Crosstalk, dc to 60 Hz:-60 dB
Input Impedance (voltage inputs):> 10 M Ω powered
Input Scan Rate:50 ms
Hardware Accuracy (@ CMV = 0 V)
± 0.075% of full-scale (23.5°± 2°C)
± 0.15% of full-scale (0 to 60°C)
SITOP PSU100L 24 V/10 A
Stabilized power supply input: 120/230 V AC,
output: DC 24 V/10 A
type of the power supply network:1-phase AC
supply voltage:120 V/230 V
input voltage:1 at AC:93 ... 132 V
input voltage 2 at AC:187 ... 264 V
line frequency:50/60 Hz
Model: DSQC509
Part Number: 3HAC5687-1
Type: Controller Panel
Input Voltage:AC 100-240V (50/60 Hz)
Output Voltage:24V DC
Output Power:Typically 100W or more (depends on load)
Current Rating:Around 4A at 24V DC
Efficiency: High efficiency for industrial use
Series:Versamax
Manufacturer:Emerson Automation / GE Fanuc (former)
Part Number:IC200PNS001
Series:VersaMax
Part Number:IC200PNS001
Power Consumption:0.60 Amperes at 5 Volts DC
Product type:Remote I/O Profinet Network Interface Unit
Supported protocol:PROFINET version Version 2.2 Class A IO-Device
Proficy Machine Edition Version Required:Version 7.0 or later
Supported topologies:Linear, Star, Ring (redundant)
No. of Ports:Two (2) RJ45ports
Mounting:DIN Rail
Blocking Voltage : 4500V
Maximum Repetitive Off-State Voltage:4500V
Gate Trigger Voltage (VGT): 1.5V–2.5V
Peak Surge Current (ITSM): 25–30kA
Critical Rate of Current Rise (di/dt): 1kA/µs
Turn-On Time (ton): <5µs
Turn-Off Time (toff): <10µs
Switching Frequency: Up to 500Hz
Inputs:4 high speed sub-millisecond differential
Module Type:High Speed Analog Input / Ouptut Module
Outputs:2 high speed current-voltage
Input signals ranges:± 10V
0…10V; 0…5V; 0…20 mA
Input Resolution:14 bits across ±10.5V DC
12 bits across 21 mA
No. of Outputs 2 high speed current/ voltage
Output Resolution:13 bits across 21 mA = 2.8 µA/bit;
14 bits across 21.8V = 1.3 mV/bit
Output Signal Ranges:± 10V; 0…20 mA
SITOP PSU200M 5 A
stabilized power supply
input: 120/230-500 V
AC output: 24V DC/5 A
1-phase and 2-phase AC or DC
supply voltage at DC 110 ... 220 V
input voltage at DC 88 ... 350 V
