ALL MANUFACTURERS

Gate Unit Power

Power Supply Input 110/220V AC, 24V DC
Output Power 24V DC, 5V DC
Operating Temperature -20°C to 60°C
Storage Temperature -40°C to 85°C
Humidity 5% to 95% (non-condensing)

INTERFACE BOARD

Series: UFC Series
Voltage Rating: Typically operates at 24V DC
Current Rating: 1A to 5A
Operating Temperature Range: Typically -20°C to 60°C
Storage Temperature Range: Ranges from -40°C to 85°C
Humidity: 5% to 95% relative humidity

Analog Input Module

Series: UDC920 Series
Input Voltage Range:0-10V, 4-20mA
Input Current: 4-20mA, 0-20mA, or 0-24mA.
Input Resistance:250Ω to 500Ω for 4-20mA
Resolution: 12 to 16 bits
Signal Types:4-20mA
Operating Temperature Range:-20°C to +60°C
Storage Temperature Range: -40°C to +85°C
Humidity Range: 5% to 95% relative humidity

HVD Board

Series: XV Series
Voltage Rating: 380V to 690V AC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range:-40°C to +85°C
Humidity Range: Generally supports 5% to 95%

3300 XL 8 mm Probe

3300 XL 8 mm Probe
M10 x 1 thread
with armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector, standard cable
00 Not required
Order in increments of 10 mm
Length configurations:
Maximum unthreaded length: 230 mm
Minimum unthreaded length: 0 mm
Example: 0 6 = 60 mm

Transient Data Interface Module

Input Signal: -10 Vdc to +10 Vdc
Power Consumption: 10.5 watts
Front Panel: USB-B
Ethernet: 100Base-FX Fiber-Optic
Operating Temperature: -30°C to +65°C

Control board

Voltage Rating: 24 V DV
Operating Temperature: -10°C to +50°C
Storage Temperature: -25°C to +70°C.
Humidity Tolerance: 5% to 95%

SMC PLUS 135 A Smart Motor Controller

3300 XL 8 mm Proximity Transducer

330103-00-07-05-02-CN
DISCONTINUED BY MANUFACTURER
PROXIMITY PROBE
3300 XL 8 MM
5.0 INCH OVERALL CASE LENGTH
1.0 M (3.3 FT) TOTAL LENGTH
3/8-24 UNF THREAD
WITH ARMOR

MicroLogix 1100 Battery

Micro Memory Card - 512 KB

VGA Display Unit

Powerconsumption:4.6 watts max
High-speednetwork:Monitor status, data andvalues
RS232 port:Touch controller data
Front Port:24 Vdc Power
Power +24Vdc ± 6%:4.7 watts max
Input range :22.5 to 25.5 Vdc input
VGA inputs:Video image
RS232 inputs:Touch screen control data

3300 XL 8 mm Proximity Probes

3300 XL 8 mm Probe
M10 x 1 thread, withoutarmor
1 0 1.0 metre (3.3 feet)
0 2 Miniature coaxial ClickLo connector
standard cable
CN Multiple Approvals

8 channel Current Output Module

Part Number : 2MLF-DC8A
Analog Output Modules
2MLF-DC8A – 8 channel Current Output Module
2MLF -DC8A (Current Output Type)
DC 4 ~ 20mA / DC 0 ~ 20mA

Vibration Transmitter

0 5 0-5 mils pp (0-125 μm pp)
0 1 35 mm DIN rail clips
C N CSA Division 2, ATEX Zone 0,
ATEXZone 2 and includes ABS maritimeapproval
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.

OP170B Panel
