Power supply module

Power supply module
(220-240 V AC input)
Standard type with no explosionprotection
Basic type
With ISA Standard G3 option

Central Braking Module

SINAMICS S120
Central Braking Module
Input: 1070-1115 V
1200 kW

PROFINET Controller Gateway Module

Series:Mark VIe/Mark VIeS
Product Type:PROFINET Gateway Module
Processor Type:1066 MHz EP80579 Intel
Operating Temperature:22 to 149°F
Manufacturer:General Electric

op Box A Module Board

Series: Mark VIe
Channels: Configurable for 16–32 analog/digital channels
Analog: 4–20 mA, 0–10 V, RTD
Digital: 24 VDC dry/wet contacts
Supply Voltage: 24 VDC nominal
Power Consumption: Typically ≤ 8 W
Operating Temperature: -40°C to +70°C (-40°F to +158°F)

Top Box B Module

Series: Mark VI
Supply Voltage: Typically 24 VDC
Power Consumption: Varies by load
Operating Temperature: -40°C to +70°C
Humidity: 0–95% non-condensing

Measurement and counter module

Measurement and counter module
Modicon Premum
2 channels modularity
thermal tripping protection
7 to 10W
10kHz

Power supply module

Power supply module
Modicon Premium
input current of 300mA
secondary power of 26W
85 to 264VAC

TSXDEY16A5

Modicon Premium
16 inputs
compatible with
2/3 wires proximity sensors
0.83W, 15mA

USB annunciator/numeric keyboard

Power Requirements 5 VDC, ± 5% a
USB Annunciator Keyboard: 300 mA (max)
Output Impedance: 1200 Ohms Nominal
Nominal Level: 0.437 to 0.133
Peak to Peak Amplitude, Vpp: 0.872
Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -40 to +70°C (-40 to 158°F)
Humidity range, storageand operating:
20% to 80%, non-condensing

HMS Networks

Product:X-Gateways
Data Rate:100 Mb/s
Number of Ports:2 x RJ45
Interface Type:Ethernet, USB
Supply Voltage - Min:24 V
Supply Voltage - Max:24 V
Packaging:Bulk
Brand:HMS Networks

SLC 500 Memory Module

Module Type:Memory Module Adapter
Memory:8 kilobytes, 1,000 instructions
Memory Type:EEPROM
User Memory:64,000 Words
Program Scan Time:0.9 milliseconds
I/O Scan Time:0.225 milliseconds
I/O Chassis:3
Chassis Module Slots:30
Communication:Ethernet, RS-232

Monitored Digital Input Module

Safetybus Power 0.85 load units
Number of Inputs 16, common power return
Vibration10 to 55 Hz: ±0.15mm
Turn-On Voltage (default) > 12 Vdc
Voltage: 15 to 80 VDC
Current:450 mA, maximum

Recorder External Termination Block

Recorder External Termination Block
(Terminal Stripconnectors)
Analog Outputs:4–20 mA, 0–10V DC
Max Voltage Rating: 250V AC/DC
Current Rating: 5A per terminal

DIGITAL MONITORING MODULE

Analog inputs:4–20 mA, 0–10 VDC
Power Supply: 24 VDC or 110–240 VAC
Operating Temperature: -25°C to +70°C (-13°F to +158°F)
Humidity: 5–95% RH (non-condensing)

DRIVE CONTROL UNI

DRIVE CONTROL UNIT
Input Voltage: 24 VDC
Analog inputs (0–10 VDC, 4–20 mA)
Operating Temperature:
0°C to +40°C (+32°F to +104°F)
Storage Temperature:
-40°C to +70°C (-40°F to +158°F).
Humidity: 5–95% RH (non-condensing)

Controller Circuit Board

CONTROL BOARD
Controller Circuit Board
FOR POWERFLEX 7000
FOR AC DRIVE
PWM ONLY
PCB BOARD
Analog Control Board for 18 Pulse Drive

Proximity ProbeHousing Assemblies

28 3300 XL 8mm probe
selectablehazardous area approvals
05 0.5 m (20 in)
No standoff adapter = 00
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
02 3/4-14 NPT

3300 NSv Probe

330902    3300 NSv Probe
1/4-28 UNF thread,with armor
Minimum unthreaded length: 0.0 in
Minimum case length:  2.5 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

PROBE PROXIMITY VIBRATION 8MM

Frequency Response: 0 Hz (DC) to 10 kHz
Noncontacting
Gap-to-Voltage Transducer Systems
Measures Static and Dynamic Distances

3300 XL 8 mm Proximity Probes

330103    3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length:30 mm
Minimum case length: 100 mm
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connectorprotector, FluidLoc cable
 00 Not required

Proximity ProbeHousing Assemblies

16 3300 XL 8mm probe
05 0.5 m (20 in)
No standoff adapter = 00
019 1.9 in (48.26 mm)
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Proximity ProbeHousing Assemblies

16 3300 XL 8mm probe
05 0.5 m (20 in)
No standoff adapter = 00
135 13.5 in (342.9 mm)
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

Proximity ProbeHousing Assemblies

16 3300 XL 8mm probe
05 0.5 m (20 in)
115 11.5 in (292.1 mm)
03 One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
1/8 to 3/16 inches
1/4 to 5/16 inches
5/16 to 3/8 inches
023/4-14 NPT

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 1.1 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Reverse Mount Probe

330907-05-30- CC-DD-EE M10X1 threads
05 0.5 meter (20 in)
02 Miniature coaxial ClickLocconnector
standard cable
05Multiple Approvals
