Current Output Module

Number of output channels 8 channels, module isolation
Rated output range 4 to 20 mA
Maximum range of guaranteed precision 1.25 to 23 mA
Output range 1.25 to 23 mA
Allowable load resistance @ rated range 230 to 600 Ω
Accuracy ±48 µA
Data update frequency 40 ms
Temperature drift ±16 µA/10 ºC
Withstand voltage 1.5 kV AC between output signal and system for 1 minute

Output Module

Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
External power supply 24 V DC +20 %/–10 %
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum

Output Module

Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
External power supply 24 V DC +20 %/–10 %
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum

Output Module

Number of outputs 4-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 10 A minimum
External power supply 24 V DC +20 %/–10 %
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 2 A/output line
Minimum load current 100 mA
Load resistance range 12 to 240 Ω)
Maximum lamp load (*1) 1 A/output line

Output Module

Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Maximum load current 0.6 A/output line
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum

Input Module

Number of inputs 16-channel, module isolation
Input current 6 mA ± 20 %
Contact rating 24 V DC +20 % / -10 %
External power supply 24 V DC +20 % / -10 %
Input response time 40 ms maximum
Withstand voltage (*1) (*2) 2 kV AC between input signal and system for 1 minute, 16-input line collectivelyconnected

Current Input Module

Number of input channels 16 channels, module isolation
Rated input range 4 to 20 mA
Permissible input range 0 to 25 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute

Current Input Module

Number of input channels 16 channels, module isolation
Rated input range 4 to 20 mA
Input impedance during Power-OFF 500 kΩ minimum
Data update frequency 40 ms
Temperature drift ±16 µA/10 °C
Withstand voltage 1.5 kV AC between input signal and system for 1 minute

Output Module

Number of outputs 8-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 5 A minimum
Maximum leak current at output offstatus 1.6 mA
Output format Current source
Minimum load current 35 mA
Load resistance range 40 to 685 Ω
Output response time 30 ms maximum

Digital Output unit

Number of outputs 4-channel, module isolation
Output voltage 24 V DC
Output voltage drop 1 V maximum
External power supply rating 24 V DC, 10 A minimum
Output format Current source
Maximum load current 2 A/output line (8 A in total output lines) (*4)
Minimum load current 100 mA
Load resistance range 12 to 240 Ω (*6)

Expansion Card

Product type:Controller
IP rating:IP20
Manufacturer:Carel
Power Supply:24Vac/Vdc
Accessory type:General Accessories
Board type:pCO expansions

Input Output Module

Analog Inputs:0-10V or 4-20m
Digital Outputs:24V DC
Analog Outputs: 0-10V or 4-20mA
Power Supply:24V DC
Digital Inputs: Typically 8 or 16 digital inputs

2-Phase Stepper Motor Driver

Operation method:Unipolar constant current drive
Applied Motor:2-phase stepper motor
Resolution:Intelligent type
Power supply:24-35VDC
Max. Run Current:2A/Phase
Max. Current Consumption:3A
Number Of Axes:1-axis
Environment_Ambient temperature:0 to 50℃, storage: -10 to 60℃
Environment_Ambient humidity:35 to 85% RH, storage: 35 to 85% RH

Dynalco Digital Indicator Panel

Dynalco Part No.: LMD-120D
Description: Current Loop-Powered Digital Indicator
Input Signal: 4–20 mA or 10–50 mA, jumper-selectable
Loop Burden: 2 volts maximum, i.e. 100 Ohms at 20 mA
Display: 3½ digits standard;
4½ digits with fixed zero at right-most digit.
Selectable decimal point.
Span and zero adjust:
25-turn potentiometers permit span adjustment from
100 up to 2000 units, and zero adjustment
from – 1000 up to +1000 units
Accuracy: 0.1% linearity,
0.5% stability over the environmental range

Control Techniques Drive

Voltage Rating:400V AC
Current Rating:45A at 400V
Frequency Range:0-500 Hz
Input Power: 3-phase 400V AC
Control Inputs/Outputs:0-10V or 4-20mA
Operating temperature range: Typically -10°C to +50°C
Storage temperature range: -40°C to +70°C

Synchronizing relay

SYNCHRONIZING RELAY
48/250 V
57-120 VAC

PULSE AMPLIFIER BOARD

Voltage Rating:24V DC
Input Signal Type:24V
Operational Temperature Range: -20°C to +70°C
Part Number:61073027C

POWER SUPPLY

AC/AC converter for wall mounting
Voltage regulatedConvection cooling
4-channel AC output, individually monitored
Robust housing
Vibration proof

GuardLogix 5580 Safety Controller

User memory:10 megabytes
Safety memory:5 megabytes
Digital I/O / Analog I/O:128,000 / 4000 max
Ethernet performance:10/100/1000 megabits per second
Current draw at 1.2 Volts DC:5.0 milli Amps
Current draw at 5.1 Volts DC:1.2 Amps

3300 XL 8 mm Proximity

3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity

3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
10 1.0 meter (3.3 feet)
12 Miniature coaxial ClickLocconnector
FluidLoc cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity

3300 XL 8 mm Probe
3/8-24 UNFthread, with armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Proximity Probes

3300 NSv Probe
3/8-24 UNF thread,without armor
05 0.5 meter (20 in)
02 Miniature coaxial ClickLoc connector,
standard cable
00 Not required

Proximity Probe

Armored and Unarmored Options
Multiple Connector Options
Complete Interchangeability of Units and Cabling
Compact Form Factor
-18 to -24VDC VT
Wide Temperature Range: -55°C to 100°C
11mm Probe Diameter

3300 XL 8mm Proximity

3300 XL 8 mm Probe
3/8-24 UNF thread,without armor
0 2 Miniature coaxial ClickLocconnector
standard cable
0 0 Not required
