ALL MANUFACTURERS

IQT Proportional board

Supply Voltage:24V DC
Control Signal Input:4-20mA
Dry contact or voltage-sourced
3-phase or single-phase PWM control

MOTHERBOARD

Actuator Input: 24V DC
Logic Circuit Voltage: 5V DC
Output Type: PWM-driven for 3-phase
Current Handling: Up to 10A
Analog Input (Optional): 4-20mA

Analogue isolating amplifier

Impulse withstand voltage:5 kV (1.2/50 µs)
Rated voltage:600 V
Accuracy:<0.05 % of measuring range
Nominal power consumption:2  VA
Operating altitude:≤ 2000 m
Power consumption:≤2.3 W
Rail:TS 35
Step response time:≤50 µs

VEHICLE CONTROL UNIT

Supply Voltage: 24V DC
Power Consumption: Typically < 50W
Isolation: 1500V AC
Digital I/O: ≥ 24 channels
Analog I/O: ≥ 8 channels
Relay Outputs: ≥ 8

Galvanic separation unit

Input voltage range : 18 to 30 VDC
No load on sensor side : ≤80 mA
20 mA load on sensor side : ≤120 mA
Output voltage dynamic range: 2 to 20 VDC
Output impedance : 20 Ω, protected against short-circuits
Power supply voltage rejection ratio
10 Hz to 400 Hz : ≥60 dB
 400 Hz to 100 kHz : ≥30 dB
Output signal offset drift with temperature: ≤2 mV/°C

8 PORT CARRIER CARD MODULE

Type:8-Port DS1/E1 Carrier Card
Port Density 8x DS1/E1 ports
Form Factor OMS 1600/OMS 2400
Line Rate DS1: 1.544 Mbps (T1)
Line Rate E1: 2.048 Mbps
Timing:Network-synchronized

Smart Gateway/Controller

Secure M2M communication
Local logic execution
Memory:1 GB RAM + 8 GB Flash
USB:1x USB 2.0 host port
Power Supply:12-24V DC
Processor:ARM Cortex-A9 dual-core @ 1.0 GHz

Bus interface module

PROFIBUS BIM
BUS INTERFACE MODULE
LAN TO RAILBUS TO POWER SUPPY: 500 V
244 BYTES MAX
RAILBUS 12 V CURRENT 420 MA

POWER SUPPLY

POWER SUPPLY
2.9 TO 4.9 AMP
18-36 VDC
-40 TO +70 DEGREES C
Product type : System power supply

signal conditioner

Input Range: Typically ±10 V peak.
Input Range: Typically -2 V to -18 V DC
Acceleration/Velocity: DC to 10 kHz
Displacement (Eddy Current): 0 to 10 kHz
Dynamic Range: Typically > 80 dB
Voltage: Typically +15V DC

E3845 1.91GHz processor

Compact with fanless design
Dual power input for avoiding power down time
Exchangeable RTC battery with easy access on the top
Digital I/O with isolation protection for sensing and controlling
Diverse system IO and supports fieldbus protocol
by idoor technology as aprotocol gateway
3G/GPS/GPRS/Wi-Fi communication by idoor technology as acommunication gateway
Supports MRAM by iDoor technology
LAN redundancy (teaming)

Rev.1 Module Board

Voltage Range: 12–30V DC.
Logic Threshold: ≥8V
Isolation: 500V AC
Contact Rating: 5A @ 230V AC
Supply Voltage: 24V DC (±15%).
Power Consumption: ≤3W
Channel-to-Bus Isolation: 1500V AC.
Surge Immunity: 1kV

VME Processor Module

MPC60x 32-Bit Microprocessors
Two 32/64-Bit PMC Expansion Slots with Front-Panel and P2 I/O
64-bit PCI Expansion Mezzanine Connector
Asynchronous Serial Debug Port
Four 32-Bit Timers, One 16-Bit Timer, One Watchdog Timer
10/100Mb/s Ethernet Transceiver Interface

ICC Industrial Control FZE

Modular Slots: Supports 8–16 I/O module
Ethernet: 4+ ports (RJ45/FO)
Analog Inputs: 16+ channels
Digital I/O: 32+ channels

Logic Analog I/O Card

Channels: 8 analog inputs
Voltage: ±10 V DC
Current: ±20 mA DC
Resolution: 16-bit ADC.
Accuracy: ±0.1% of full scale
Channels: 4 opto-isolated

Control Panel

Display:5.7" Color TFT LCD (320 × 240 pixels)
Processor:32-bit RISC microcontroller
Power Supply:24V DC
Power Consumption:≤50W
I/O Capabilities:16–24 Digital Inputs

ANALOG I/O BOARD ASSY

Miscellaneous VME / VXI Cards
Wide Range of Equipment
Analog Inputs:16–32 channels
Isolation :1500V AC
Sampling Rate:10–100 SPS
Power Supply:+24V DC (±10%)
Power Consumption:≤25W

Digital I/O Analog Board

Digital Inputs:24V DC
Digital Outputs:250V AC
Analog Inputs:4–20mA/0–10V
Isolation:1500V A
Power Supply:24V DC (±20%)
Power Consumption:≤8W (24V DC)

Temp Sending Unit

Input Channels:8 independent
Analog Outputs:8 × 4–20mA
Output Accuracy:±0.1% FS
Isolation:1500V AC
Power Supply:24V DC (±10%),
Power Consumption:≤5W (24V DC)

FPGA Adapter Board

Clock Circuitry: 50–200 MHz
Input Voltage: +12V
Power Consumption: 10–25W
Memory: 256–576 KB

Vac Control Board

Input Voltage: +24V DC
Digital Inputs: 8–16 channels
Digital Outputs: 8–12 channels
Analog Inputs: 4–8 channels
Isolation: 1500V
Primary: RS-232/485

PLC MODULE

Clock Speed: 66 MHz
RAM Type: 72-pin SIMM
Voltage: Single +5V DC
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C.
Relative Humidity: 5% to 95% non-condensing

Control board

Processor:32/64-bit RISC CPU
RAM: 512 MB DDR3
Flash: 1 GB
Motion:Axes Controls 4–16 servo axes
Supply Voltage:24V DC (±10%), 2A max
Power Consumption:≤25 W (peak)
Isolation:1500V AC (I/O to logic)

Processor Module

Power Supply:24 V DC (±15%)
CPU:32-bit RISC processor
Clock Speed:80–100 MHz
I/O Capacity:Supports up to 64 I/O modules
Optional Protocols:Modbus RTU/TCP, PROFIBUS DP

DPU Distributed Processing Unit

Input Voltage: 20–30 VDC
Power Consumption: 18W
Isolation:1500 VAC
RAM: 1 GB DDR3
Flash Storage: 4 GB eMMC
Ethernet 2x 10/100/1000 Mbps
