Siemens Simatic S7

CP443-1 Communications Processor

Communications processor
CP 443-1
2x 10/100 Mbit/s (IE switch)
RJ45 ports; ISO
TCP; UDP
PROFINET IO controller;
S7communication
Open communication (SEND/ RECEIVE)
S7routing; IP configuration via DHCP/ Block
IP Access Control List;Time synchronization
extended web diagnostics
Fast Startup
Support for PROFIenergy

Interface Module

SIMATIC DP
INTERFACE IM 153-1
FOR ET 200M
FOR MAX. 8 S7-300 MODULES

Analog Input Module

SIMATIC S7-300
ANALOG INPUT SM 331
GALVANICALLY ISOLATED
8 AI, 14 BIT,0.052MS/CHANNEL
CURRENT, VOLTAGE,INTERRUPTS
DIAGNOSTICS,1 X 20 PIN,FIT
FOR ISOCHRONE MODE IMPROVED DP-CYCLE
TIMEFOR ISOCHRONE MODE

CP340 Serial Communication Module

CPU 1214C DC/DC/RELAY 14DI/10DO/2AI

DIGITAL OUTPUT SM 1222 8 DO RELAY

SCALANCE Switch Module

Profibus Connector

SIMATIC DP
Connection plug for PROFIBUS up to
12 Mbit/s 90° cable outlet
Insulation displacement method FastConnect
without PG socket 15.8x 59x 35.6mm (BxHxD)

Repeater Module RS485

Communication Module CP 443-5 Extended

COMMUNICATION PROCESSOR
CP443-5
EXTENDED FORCONNECT.
OF SIMATIC S7-400 TO PROFIBUS DP
S5-COMPATIBLE PG/OP- AND
S7-COMMUNICATION

Temperatur Controller FM355-2 S

EM 235 Analog I/O Module

IM151-7 Interface Module

ET200SP. IM155-6PN HF incl. servermodule

Busadapter

SIMATIC ET 200SP
BusAdapter BA 2xRJ45
2 RJ45 sockets

CPU317-2 DP Central Processing Unit

Digital Input Module - Profisafe

SIMATIC DP
Electronics module f
ET200S, 4/8 FDI PROFIsafe
24 V DC, 30 mm overall width
up to Category 4 (EN954-1)/
SIL3 (IEC61508)/PLE (ISO13849)
can also be used inPROFINET
configuration with IM 151-3 HF

PS407 Power Supply

C7-623/P Compact Unit

Westfalia Separator C7-635 KEYS Panel

C7-613 Compact Unit

CP243-1 Communications Processor

EM223 Digital I/O Module

CPU417H Central Processor for S7-400H

CPU MODULE
SIMATIC S7-400H
417H CENTRAL UNIT FOR S7-400H
4 INTERFACES: 1 MPI/DP
1 DP A. 2 FOR SYNC MODULES
4MB MEMORY (2MB CODE/2MB DATA)

CPU314 Processor Module
