Siemens

CPU 313C-2 DP Compact CPU with MPI

SIMATIC S7-300
CPU 313C-2DP COMPACT CPU WITH MPI
16 DI/16 DO, 3 FAST COUNTERS (30 KHZ)
INTEGRATED DP INTERFACE
INTEGRATED 24V DC POWER SUPPLY
64 KBYTE WORKING MEMORY
FRONT CONNECTOR (1 X 40PIN)
AND MICRO MEMORYCARD REQUIRED

DPU
TEST/METER
DEVICE PROGRAMMER UNIT
LOOP TESTER
LCD
12 BUTTON KEYPAD

CUX-Module

Servo Controller

6SC61100GA01
DISCONTINUED BY MANUFACTURER
DRIVE MODULE
600VAC
MICRO SIM
Tariff Code: 8504409570
Country of Origin: Germany

TD200 Text Display

SINAMICS V20. 1AC230V 0.55KW UNFILTERED

SIMATIC HMI KTP900 BASIC

SIMATIC HMI
KTP900 Basic
Basic Panel
Key/touch operation
9"TFT display, 65536 colors
PROFINET interface
configurable fromWinCC Basic V13/ STEP 7 Basic V13

CP340 Communications Processor Module

SM 1232 Analog Output Module

TP177A Touch Panel

TD 200 Display Panel

SM321 Digital Input Module

DIGITAL INPUT MODULE
SIMATIC S7-300
ISOLATED
16-DIGITAL INPUTS
24VDC
1 X 20 POLE
SUCCESSOR FOR 6ES7321-1BH01-0AA0

Central processing unit

SIMATIC S7-300
CPU 317-2 PN/DP
Central processing unit
with 1 MB workmemory
1st interface MPI/DP 12 Mbit/s
2nd interface Ethernet PROFINET
with2-port switch
Micro Memory Card required

Simatic S7-200 CPU 224

SIMATIC S7-200
CPU 224
COMPACT UNIT
AC POWER SUPPLY14 DI DC/10 DO
RELAY
8/12 KB CODE/8 KB DATA
PROFIBUSDP EXTENDABLE

DP/PA Coupler Module

Simatic Smart 700 Panel

CPU 314C-2PN/DP Compact CPU

CPU MODULE
SIMATIC S7-300
W/ 192 KB WORK MEMORY
24 DI/16 DO
4 HIGH-SPEED COUNTERS (60 KHZ)
1ST INTERFACE MPI/DP 12 MBIT/S
2ND INTERFACE ETHERNET PROFINET WITH 2-PORT SWITCH
24 VDC POWER SUPPLY

PN/PN Coupler

Double Motor Module

SINAMICS S120 Double Motor Module
input: 600 V DC
output: 400 V 3 AC, 18 A/18 A
type of construction: booksize internal
air cooling optimized pulse patterns
and support of the extended
Safety Integrated functions
incl. DRIVE-CLiQ cable

PM1507 Power Supply

DI/DQ 16X24CDV/16X24VDC/0.5A BA

Comfort CE6.0 9" TFT 16:9

SIMATIC HMI TP900 Comfort
Comfort Panel
touch operation
9" widescreen TFTdisplay
16 million colors
PROFINET interface, MPI/PROFIBUS DP interface
12MB configuration memory
Windows CE 6.0, configurable
from WinCC ComfortV11

CUSA Module

SIMOVERT Master
drives Module
CUSA AFE-infeed
backfeed unit Control module
Firmware version: V2.XX

SIMATIC HMI MEMORY CARD 2 G COMFORT PANEL

SIMATIC SD memory card
2 GB Secure Digital Card
for For devices withcorresponding

COMMUNICATION MODULE

COMMUNICATION MODULE
SIMOVERT MASTER DRIVES
MOTION CONTROL
CBP2 PROFIBUS
