Analog I/O Module

ANALOG I/O
MODULE 8AI
24 VDC
U/I/RTD
8/12BIT+SIGN 1/3-WIRE
CS31

OEI-BOARD

Power Supply:24V DC (-15%/+20%)
Power Consumption:6W typical
Optical Interfaces:2× 100BASE-FX (1300nm)
Electrical Interface:1× 10/100BASE-TX
Isolation:1500V AC
Data Rate:100Mbps full-duplex

AC centrifugal fan

FAN
CENTRIFUGAL
230 VAC
290WATT
50 HZ
0,88 A
2050 RPM
DRIVE MOUNT

Communication Gateway

MLink Hardware Version 2
Internal: Modbus TCP
Fieldbus: Profibus
Modbus RTU/TCP, PROFINET IO

REMOTE I/O NODE CONTROLLER

Network Protocol:Ovation High-Speed Bus (HSB)
Data Rate:100 Mbps (Full Duplex)
Node Capacity:Up to 64 I/O modules
Maximum Distance:2 km
Processor:32-bit RISC @ 400MHz
Memory:128MB SDRAM, 64MB Flash
Scan Time:10ms (typical for 64 modules)
I/O Capacity:2048 points (mixed I/O)

POWER SUPPLY

POWER SUPPLY
100-240 VAC INPUT
24VDC 10 AMP OUTPUT
SDN10-24-100C-EPM

Analog Input Module

SPARE PART
INPUT MODULE
PMOD ASSEMBLY
ANALOG INPUT
8 CHANNEL
VOLTGAGE W/ TEMPERATURE SENSOR

FIELD EXCITER

SDCSFEX425INT
FIELD EXCITER
3ADT209022R0001
16/25SMPS
1-3 PHASE SUPPLY
600VAC
USES .54M FEX-4-DSL CABLE

CONTROL BOARD

Input Voltage:24V DC (±10%)
Power Consumption:≤50W (max)
Relay Outputs:2x SPDT (5A @ 230V AC)
Digital Inputs:2x (24V DC)

Profibus‑DP master module

Protocol: Profibus-DP
Data Transfer Rate: 9.6 kbps to 12 Mbps
Max. Number of Slaves: Up to 125 devices
Cable Length:Up to 1200 m
Connector Type: 9-pin D-sub
Bus Voltage: 5V logic
