Technical specifications for 6ES7151-8AB01-0AB0
-
Product Model6ES7151-8AB01-0AB0
-
Spare ModelIM151-8 PN/DP
-
Product ParametersI/O MODULE
-
Tariff Code8537101190
-
Country of originGERMANY
-
Place of shipmentXiamen, China
-
Estimated Shipping Size12x7.5x12cm
-
ManufacturerSiemens
-
Weight0.3 kg
-
HW-Funktionsstand01
-
Firmware-VersionV3.2
-
Rated value (DC)24 V
-
permissible range, lower limit (DC)20.4 V
-
permissible range, upper limit (DC)28.8 V
-
Inrush current, typ.1.8 A
-
for backplane bus (5 V DC), max.700 mA
-
Power loss, typ.5.5 W
-
Isolation tested with500 V DC
Description
I/O MODULE
24 VDC
192 KB WORK MEMORY
PROFINET INTERFACE AS I/O CONTROLLER
THREE RJ45 PORTS
WITHOUT BATTERY
MMC REQUIRED
ET200S
IM151-8 PN/DP CPU
SIMATIC DP
DIN RAIL MOUNT
24 VDC
192 KB WORK MEMORY
PROFINET INTERFACE AS I/O CONTROLLER
THREE RJ45 PORTS
WITHOUT BATTERY
MMC REQUIRED
ET200S
IM151-8 PN/DP CPU
SIMATIC DP
DIN RAIL MOUNT
Information
Overview
Manuals
Technical notes
Product Applications
Hardware Installation
Features:
- Integrated S7-314 Class CPU with 192 KB Work Memory
- Maintenance-Free Operation with Micro Memory Card (MMC)
- Triple-Port PROFINET Interface (100 Mbps) with Switch Functionality
- Expandable PROFIBUS DP Master via Optional Module
- High-Speed Processing & Extensive I/O Capacity
- Isochronous Mode, Real-Time Clock & NTP Synchronization
The 6ES7151-8AB01-0AB0 Siemens SIMATIC DP interface module may still be available for purchase and support from Amikon Limited beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7151-8AB01-0AB0 SIMATIC DP interface module Manuals, Datasheets, Drivers, Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Communication flexibility is a defining strength of this module. Its integrated PROFINET interface includes three RJ45 ports operating at 100 Mbit/s full duplex, effectively functioning as a 3-port Ethernet switch. The module can be configured as a PROFINET IO Controller to manage distributed I/O devices, or as a PROFINET IO Device (I-Device) to act as an intelligent slave within a larger controller network. For environments requiring PROFIBUS DP connectivity, the module can be expanded with an optional DP master module (6ES7138-4HA00-0AB0), transforming it into a DP master capable of controlling up to 32 DP slaves while simultaneously supporting PROFIBUS proxy functionality for up to 16 linked PROFIBUS devices on the PROFINET network. This dual-protocol capability makes it ideal for hybrid legacy-modernization projects.
- Water and Wastewater Treatment:Pump pressure & chemical dosing levels
- Chemical and Petrochemical Processing:Remote input tracking in certified enclosures
- Marine & Maritime Equipment:ClassNK certified auxiliary monitoring
- Pressure Monitoring:Hydrostatic, differential & pipeline load cells
- Level Measurement:Ultrasonic/radar/guided-wave for chemical/water tanks
- Flow Tracking:Electromagnetic/vortex flow meters
This content has been produced using multiple sources.Amikon takes no responsibility for the accuracy of this information. Always consult the original equipment manufacturer for the most up to date instructions and information.
Mounting Rail: Secure the DIN rail.Terminal Module (TM-P): Install the terminal module for the power module first, as the CPU must be connected to this to ensure proper pin alignment.
Mounting CPU: Insert the 6ES7151-8AB01-0AB0 CPU onto the terminal module until it clicks.
I/O Modules: Install additional ET 200S I/O modules on their respective terminal modules, starting from left to right.
End Plate: Place the end plate (6ES7193-4CA40-0AA0) at the end of the module chain to ensure proper operation
FAQs
-
What is the 6ES7151-8AB01-0AB0？+The Siemens 6ES7151-8AB01-0AB0 is a SIMATIC DP IM151-8 PN/DP CPU, for the ET 200S distributed I/O system, featuring 192 KB of work memory and integrated PROFINET interfaces.
-
Is a Micro Memory Card required?+Yes, a SIMATIC Micro Memory Card (MMC) is strictly required for operation and data storage.
-
Can it act as a PROFIBUS master?+Not natively. An external master module (6ES7138-4HA00-0AB0) must be added to support PROFIBUS DP master functionality.
-
What are the integrated network ports?+It features an integrated PROFINET switch with 3 RJ45 ports.
