Triconex

Digital Output Baseplate

I/O Baseplate
I/O Interconnect Assembly
Slot Cover
Terminal Cover
Muber of Chanels: 24
Output Current: 2A
Output Voltage: 24VE
CA per channel
Power Consumption:20w

Digital Input Module

Points:4, commoned-return, DC-coupled
Output current range:
4–20 mA output, controlled
0–22 mA over-range
0 mA output capability (step function <2 mA)
Type:TMR
Resolution:12 bits
Diagnostic:Forced-switch diagnostic (FSD)
Over-range protection:36 V DC, continuous

Digital Input Module

Points:32, commoned
Nominal input voltage:24 V DC
Operational voltage range:15–30 V DC
Absolute maximum input voltage:33 V DC
Absolute maximum reverse input voltage:–0.6 V DC
Input delay:<10 ms, On to Off or Off to On
ADC scan time:<1 ms for all 32 points

Digital Output Module

Points:16, commoned
Nominal output voltage:24 V DC
Operational voltage range:15–30 V DC
Absolute maximum output voltage:33 V DC
Absolute maximum reverse input voltage:–0.6 V DC
Leakage to load (Off-state):<1 mA
On-state voltage drop:<1 V DC @ 1.5 A
Loop-back scan time:<1 ms for all 16 points

ANALOG INPUT MODULE

Points:32, commoned
Nominal input current:4–20 mA DC
Operational current range:2–22 mA DC
Absolute maximum field voltage:33 V DC
Absolute maximum input current:50 mA DC
Input bandwidth (3dB):16 Hz
Source impedance:180 Ω
Resolution:12 bits
Absolute error:0.15% of full scale (20 mA)
Diagnostic:Force-to-value diagnostic (FVD)
Scan time:<1 ms for all 32 points

Analog Input Module

Points:32, commoned
Nominal input current:4–20 mA DC
Operational current range:2–22 mA DC
Absolute maximum field voltage:33 V DC
Absolute maximum reverse field voltage:– 0.6 V DC
Absolute maximum input current:50 mA DC
Input bandwidth (3dB):16 Hz
Source impedance:180 Ω
Resolution:12 bits
Absolute error:0.15% of full scale (20 mA)
Diagnostic:Force-to-value diagnostic (FVD)

Analog Output Module

Type:TMR
Resolution:12 bits
Diagnostic:Forced-switch diagnostic (FSD)
Points:4, commoned-return
Output current range:4–20 mA output, controlled
External loop power:32 V DC, maximum24 V DC, nominal

Digital Output Module

Points:16, commoned
Nominal output voltage:24 VDC
Specified operational voltage range:15 to 30 VDC
Absolute maximum output voltage:33 VDC
Absolute maximum reverse input voltage:– 0.6 VDC
Leakage to load (Off state):<1 mA
Diagnostic glitch duration <2 ms, maximum:500 Ps, typical
On state voltage drop:<1.0 VDC @ 1.5 A

BASEPLATE

BASEPLATE
ANALOG I/0 MODULE
W/HEAT SINK
Supports 8/16-channel analog I/O modules

Communication Module

Communication Protocol:Modbus TCP/IP, DeviceNet
Data Rate:Up to 1 Mbps
Power Consumption:L ess than 4W
Operating Temperature:-40C to +70°C
Mounting Type:Panel Mount

COMMUNICATION MODULE

Input Voltage: 24 V DC
Range: 18–32 V DC
Power Consumption: Typically ≤ 10 W
Isolation Voltage: 1500 V AC
Serial Ports: RS-232/RS-485 (configurable).
Ethernet: 10/100 Mbps RJ45 (TCP/IP)
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -50°C to +85°C (-58°F to +185°F)

Digital input module

Input Type:24V DC
Number of Channels:16 channels per module
Input Voltage Range:ON State: 15–35V DC
OFF State: 0–5V DC
Input Current: Typical: 3–7 mA
Update Rate: ≤ 10 ms
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)

Pulse Input Module

8 pulse input channels
Voltage Range: 5–30 V DC
Standard: 0–10 kHz
Frequency Measurement: ±0.01% of reading
Channel-to-Channel Isolation: ≥ 1500 V AC/DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)
Humidity:
0–95% non-condensing

Pulse Input Baseplate

Frequency/Rate: Up to 10 kHz
Voltage Range: 5–30 V DC
Counting Resolution: 24-bit
Frequency Accuracy: ±0.01%
Channel-to-channel isolation: ≥ 1500 V AC/DC
Field-side Power: 24 V DC
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Storage Temperature:
-40°C to +85°C (-40°F to +185°F)

Communication module

Serial ports : 4
Network ports : 2
Port isolation : 500 VDC
Copper Ethernet ports : 10/100 Mbps
(Model 4353 supports only 100 Mbps)
Fiber Ethernet ports : 100 Mbps
Serial ports : up to 115.2 Kbps per port

I/O Bus Cable

4000056002
I/O Bus Cable
Operating Temperature Range:  -40°C to +70°C
Insulation Material: PVC
CABLE ASSEMBLY 6FEET

I/O ALARM MODULE

I/O ALARM MODULE
TRISEN TURBOSENTRY
16 DIGITAL OUTPUTS
OPERATING VOLTAGE: 24V DC
OPERATING TEMPERATURE RANGE: -40C TO 70C
DIMENSIONS: 12.5 X 4.5 X 5.5 INCHES

Remote Expansion Chassis

Power Supply:18 to 32 VDC
Operating Temperature: -20°C to +70°C (-4°F to +158°F)
Humidity: 5% to 95%, non-condensing
Output Channels: 16 or 32
Output Voltage: 32 VDC
Certifications: IEC 61508 SIL3

Communication Module

Input Voltage: Usually 24 VDC.
Operating Temperature: -20°C to 60°C.
Storage Temperature: -40°C to 85°C.
Humidity: 10% to 95% RH, non-condensing.
Ingress Protection (IP): Typically IP20

Communication Module

Tricon
TCM SERIES
2 X NET LINK PORTS
4 X 9 PIN SERIAL PORTS
1 X 9 PIN DEBUG PORT

Control Module

Nominal Voltage 24 VDC
Type Control Module
Output Signals  32, commoned
Voltage Range 16-32 VDC
Maximum Voltage 36 VDC
Voltage Drop < 2.8 VDC @ 1.7A, typical
Power Module Load < 13 watts

MAIN PROCESSOR MODULE

MAIN PROCESSOR MODULE
ENHANCED EMP II
24 VDC
LED INDICATORS

TRICON MAIN CHASSIS

81008
TRICON MAIN CHASSIS VERSION-8

CABLE ASSEMBLY 10FEET

4000098516
CABLE ASSEMBLY 10FEET

I/O cable

Part Number: 4000094-316
Type: I/O Cable
Compatibility: Compatible with TRICONEX safety systems, typically used with I/O modules and other system components for data transmission.
High-quality insulation for protection against environmental factors.
Designed to withstand high temperatures, vibration, and harsh industrial environments.
Reliable performance for continuous monitoring and control in critical processes.
