ALL MANUFACTURERS

TZIDC ELECTRO-PNEUMATIC POSITIONER

Power Supply: 10.5–30V DC
Analog: 4–20mA
Digital: PROFIBUS DP/PA
Position Feedback: 4–20mA
Control Accuracy: ±0.5% of span
Supply Pressure: 1.4–7 bar (20–100 psi)
Output Pressure: 0–100% of supply pressure
Air Consumption: < 0.12 Nm³/h
Response Time: < 1 sec

TERMINAL BLOCK

TERMINAL BLOCK
FUSED 8CHANNEL
250VAC 2AMP

Digital Output Module

OUTPUT MODULE
S-SERIES
DIGITAL
8-CHANNEL
24 VDC

Remote Terminal Unit

Input Voltage: 12–24V DC
Power Consumption: 5–15W (typical)
CPU: 32-bit industrial
RAM: 8–16 MB
Flash Memory: 16–32 MB
Digital Inputs (DI): 8–16 channels
Analog Inputs (AI): 4–8 channels

IGCT Module

Nominal On-State Current (ITAV):2000A*
Maximum Surge Current (ITSM):20kA (1ms)
Critical di/dt:500A/μs
Maximum Blocking Voltage (VDRM):1700V
Repetitive Peak Reverse Voltage (VRRM):1700V
Gate Trigger Voltage (VGT):1.5-2.5V
Recommended Switching Frequency:≤500Hz

IGCT Module

Nominal On-State Current (ITAV):2500A
Peak Surge Current (ITSM):25kA (1ms)
Critical di/dt:800A/μs
Maximum Blocking Voltage (VDRM):4500V
Repetitive Peak Reverse Voltage (VRRM):4500V
Gate Trigger Voltage (VGT):1.5-2.5V

IGCT Module

Repetitive Blocking Voltage:4500V
Non-Repetitive Blocking Voltage (VDSM):4500V
Gate Trigger Voltage (VGT):1.5-2.5V
Average On-State Current (ITAV):3500A
Peak Surge Current (ITSM):30kA (1ms)
Critical di/dt:1000A/μs
Peak Gate Current (IG):50A
Gate Power Dissipation:20W

IGCT Module

Blocking Voltage : 4500V
Maximum Repetitive Off-State Voltage: 4500V
Gate Trigger Voltage (VGT): 1.5-2.5V
Average On-State Current : 3500A
Turn-On Time (ton): <5μs
Turn-Off Time (toff): <10μs
Switching Frequency: Up to 500Hz

IGCT Module

Blocking Voltage:4500V
Gate Trigger Voltage (VGT): 1.5V to 2.5V
Peak Surge Current (ITSM):30kA
Turn-On Time (ton): <5µs
Turn-Off Time (toff): <10µs
Switching Frequency: Up to 500H
Gate Current (IG): 50A

CORDSET

CORDSET
40-WAY TERMINAL
TWO ENDS FLYING LEADS
FOR M340 I/O
3 M CABLE LENGTH

RACK

RACK
12 SLOTS
ETHERNET BACKPLANE
0 TO +60 DEGREES C
IP20 ENCLOSURE PROTECTION
RECOMMENDED REPLACEMENT FOR 140XBP01600

PROCESSOR MODULE

PROCESSOR MODULE
MODICON M580
24 VDC
295 MA
NUMBER OF RACKS: 8
768 I/O PROCESSOR CAPACITY
LED INDICATORS
-40 TO +85 DEGREES C
IP20

REV H DIODE SUPPLY CONNECTOR BOARD

Input Voltage: 24V DC
Output Voltage: ±15V DC
Current Rating: ≤ 2A per
Isolation Voltage: ≥ 2500V AC
Input: 6–10-pin terminal

Discrete Input Card

S-Series DI 32-Channel 24 VDC
Dry Contact Card
Input Voltage Range:5–60V DC (24V DC nominal)
On-State Threshold:≤ 5V DC (logic "1")
Off-State Threshold:≥ 15V DC (logic "0")
Input Impedance:3.3 kΩ (typical)
Input Current:≤ 8 mA @ 24V DC (per channel)
Max Continuous Voltage:60V DC
Isolation:Group-to-Group: 300V AC RMS

Analog Input Module

Channels: 8
Signal Type: 4–20 mA DC
nput Range:4–20 mA DC (configurable for 0–20 mA)
Overrange Capability: -1 mA to +25 mA
Input Impedance:≤ 250 Ω (typical)
Accuracy:±0.05% of span (at 25°C)
Temperature Drift:±0.005% of span/°C (-40°C to +70°C)
Resolution:24-bit

AO 8-Channel 4-20 mA HART Card

AO 8-CHANNEL 4-20MA HART CARD
12P4704X032
Channels: 8
Signal Type: 4–20 mA DC
Output Range:4–20 mA DC
Load Resistance:300–1100 Ω
Accuracy:±0.1% of span (25°C)
Temperature Drift:±0.02% of span/°C (-40°C to +70°C)
Resolution:15 bits (including sign)

Redundant AI 8-Channel TerminalBlock

Signal Type: 4–20 mA DC
Standard: 4–20 mA DC
Overrange: -5 mA to +25 mA
Input Impedance: ≤ 250 Ω (typical)
Field Power 30 VDC at 200 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec

8-Channel Terminal Block

TERMINAL BLOCK REDUNDANT INTERFACE
Field Power   30 VDC at 100 mA
AmbientTemperature-40°C to +70°C
Shock 10g ½ Sinewave for 11msec

DIGITAL INPUT MODULE

DIGITAL INPUT MODULE
NAMUR CARD
8-CHANNEL
LOCALBUS POWER 12 VDC AT 150 MA
(12P4692X042)

PANEL INTERFACE

64532588
Interface  Board
ADPI-01 PANEL INTERFACE
Power Supply:24V DC
Consumption: 15W (typical)
Operating Voltage:18–30V DC (±10%)
Isolation :500V AC between ports and power

MQ Controller

CONTROLLER
MQ SERIES
5VDC@1.4A LOCALBUS POWER
13P0072X062-233C

Operation Keyboard

Interface Connector: USB A type x 2
Operation Keyboard Function : USB 2.0
Sound Function : USB 1.1
Input Voltage: 5 V±5 %
Maximum Consumption Current: 1 A
Chassis Color: Black

Control board

Processor:Dual-core CPU
Memory:512 MB RAM
Flash Storage:1 GB internal
Power Supply:24 V DC
Communication Ports
2x Ethernet (RJ45): 10/100/1000 Mbps
1x Serial (RS-232/485): For legacy devices (MODBUS RTU).
1x USB 2.0: For engineering access.

POWER SUPPLY BOARD

POWER SUPPLY BOARD
WITH JUMPER WIRE
Primary Input: 18–32 V DC
Backup Input: 24 V DC
Output Voltage: 24 V DC
Output Current: 6 A
Holdup Time: ≥48 hours
Efficiency: >85% (typical).
Ripple & Noise: <100 mV peak-to-peak

CONTROL BOARD

Ethernet (2 ports):10/100 Mbps
Voltage: 24 V DC
Power Consumption: 5-7 W (typical)
I/O Handling:up to 64 I/O channels
