System Supply Voltage Range : 20 to 32V dc
Number of Inputs : 40 Channels
User Defined Thresholds : 4-off
Input Current Range : 0-22mA
Input Voltage Range : 0-6 Vdc
Resolution : 3.9uA (1/256mA)
Safety Accuracy : +/- 1% of full scale
Time-stamp Accuracy : ±0.5 ms
Sustained Working : ±250V dc
Maximum Withstanding : ±2.5kV dc
Channel to Channel Crosstalk : -40 to –60 dB
Power Consumption : 15 – 18W
SHIELD FOR I/O AND
COMMUNICATION MODULE 1SLOT
Trusted Shield Single Slot Width
Input Voltage:24V DC
Power Consumption: 8W
Digital Inputs: 16–32 channels
Full Trusted Controller Capability
100-240 Vac Input
Portable wheeled flight case
Simulation of 60 Field Signals
Pre-wired Dual Ethernet (point to point and hub)
Serial Comms wired to terminals
Configured for Companion Slot DI, AI and DO Modules
Model Number: TC-501-02-6M5
Type: I/O SmartSlot Cable
Configuration: Typically used for internal connections
Channels: Supports 40 channels
Termination: Connects Trusted® I/O modules
to FTAs or VFTAs
Occupies one slot in the I/O chassis
Two isolated RS-422 serial
ports for remote multiplexed I/O
Analog Input: 4–20 mA, 0–10 V DC, RTD (Pt100)
Analog Output: 4–20 mA, 0–10 V DC
Channels: 16–32 multiplexed channels
Scan Rate: <10 ms per channel
Analog: 16-bit ADC/DAC
Channel-to-channel: 250 V AC
Input Voltage: 24 V DC ±10%
Sixteen input points
Hot-replaceable
Complete, automatic testing of all input circuits
Automatic line monitoring detects
open and short field wiringfaults
2500 volt minimum electrical
isolation between field and logiccircuits
Voltage Range: 18 Vdc to 32 Vdc
Power Consumption: Maximum 1.7 W
Transmitter Power: Minimum -15 dBm
Receiver Sensitivity: -28 dBm
Maximum Propagation Time Difference: 80 ns
Maximum Fiber Length Difference: 15 m
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Non-Operating Temperature: -25°C to 70°C (-13°F to 158°F)
Relative Humidity: 10% to 95% non-condensing
Voltage Range: 18 Vdc to 32 Vdc
Power Consumption: Maximum 1.7 W
Transmitter Power: Minimum -15 dBm
Receiver Sensitivity: -28 dBm
Maximum Propagation Time Difference: 80 ns
Maximum Fiber Length Difference: 15 m
Supply Ratings:20 - 32 Vdc, 45 W
Backplane (IMB) Supply:20 Vdc to 32 Vdc
Power Dissipation:45 W Backplane Supply
Module Location:T8300 Expander Processor Slot
Fusing Not User Serviceable
Operating Temperature :0 °C to +60 °C (+32 °F to +140 °F)
Storage Temperature: -25 °C to +70 °C (-13 °F to +158 °F)
Relative Humidity :10 % – 95 %, non-condensing
Visual indications of input power supply status.
Visual indication of individual fuse status.
Common alarm of fuse status via volt-free contact.
Link selectable supply voltage options
Voltage Range 22 Vdc to 28 Vdc
Input Current 60 A max
Conductor Clamping Range (LU10.16) 0.5 mm2 to 16 mm2
Max Switching Voltage 60 Vdc or 125 Vac
Operating Temperature 0 °C to +60 °C (+32 °F to +140 °F)
Non-operating Temperature -25 °C to +70 °C (-13 °F to +158 °F)
Supports up to three Trusted Sourcing Output Modules.
Dual stud power connection for either single or dual feed.
0 V module reference via BLZ 2-part connectors.
POWER SHELF 4U MOUNTING KIT POWER PORT MAINS PLUGS
19 inch x 1U chassis
for up to 3 Power Packs.
Includes 4U fixing kit,
Power Port (with push fit BLZF3.5/10 connector),
mains plugs and retaining clips
Cable Type: Multi-core shielded cable
Length: 2 meters
Voltage Rating: Typically rated for 300 V AC/DC
Current Capacity:4–20 mA analog
Operating Temperature: -40°C to +85°C
Cable Type: Multi-core shielded cable
Length: 2 meters
Voltage Rating: Typically rated for 300 V AC/DC
Current Capacity:4–20 mA analog
Operating Temperature: -40°C to +85°C
Communications Cable Assembly
From Communication Interface (T8151) to flying leads
Impedance: 100–120 Ω (for twisted-pair cables).
Voltage Rating: 300 V AC/DC (typical).
Data Rate: Up to 1 Gbps
Operating Temperature: -40°C to +85°C
2 x 30 mm (1.2 in) Trusted Expander Processor Slots
12 x 30 mm (1.2 in) single width Trusted I/O Module Slots.
No user-serviceable parts inside.
Fast assembly.
Minimum tooling/parts.
32, 48, 64 and 96-way
DIN 41612 I/O port connector capability
Cable entry options.
Convection cooling of modules through the Chassis
Safetybus Power 0.85 load units
Number of Inputs 16, common power return
Vibration10 to 55 Hz: ±0.15mm
Turn-On Voltage (default) > 12 Vdc
Voltage: 15 to 80 VDC
Current:450 mA, maximum
