ABB

Control board

Processor:Dual-core CPU
Memory:512 MB RAM
Flash Storage:1 GB internal
Power Supply:24 V DC
Communication Ports
2x Ethernet (RJ45): 10/100/1000 Mbps
1x Serial (RS-232/485): For legacy devices (MODBUS RTU).
1x USB 2.0: For engineering access.

POWER SUPPLY BOARD

POWER SUPPLY BOARD
WITH JUMPER WIRE
Primary Input: 18–32 V DC
Backup Input: 24 V DC
Output Voltage: 24 V DC
Output Current: 6 A
Holdup Time: ≥48 hours
Efficiency: >85% (typical).
Ripple & Noise: <100 mV peak-to-peak

CONTROL BOARD

Ethernet (2 ports):10/100 Mbps
Voltage: 24 V DC
Power Consumption: 5-7 W (typical)
I/O Handling:up to 64 I/O channels

IGCT Module

Turn-off Time: ≤ 8 µs.
dv/dt: 1,000 V/µs (min)
Supply Voltage: +15V
Gate Current: 60 A
Capacitance: 5 µF (±10%)
Voltage: 2,000 V DC
Thermal Resistance: 0.008 K/W
Mounting Pressure: 12–15 kN

VOICE FREQUENCY TELEGRAPHY DEVICE

Carrier Frequencies: 300–3400 Hz
Channel Spacing: 120 Hz or 240 Hz
Shift Range: ±30 Hz, ±60 Hz, or ±120 Hz
Baud Rate: 50 Bd or 200 Bd
Voltage: 48/60 VDC
Power Consumption: <15 W
Operating Threshold: -30 dBm
Voltage: 48/60 VDC nominal
Operating Temperature: -20°C to +65°C.

PLC BOARD

Power Supply:24V DC (±10%)
Power Consumption:≤ 5W
Isolation:1500V AC
 Digital: 16–32 channels
Analog: 4–8 ch

USB-Hardlock Key for ECT

USB-Hardlock Key for ECT with 1 licence
Encryption:AES-128/256-bit
Hardware ID:Unique 64-bit serial number
Operating Voltage:5V DC
Power Consumption:≤ 100 mA

PCB Board

Fiber Optic Ports: 6–12 channels
Power supply pins:+24V DC, +5V DC
Operating Voltage: 24V DC
Power Consumption: ≤ 15W
Reinforced isolation:2.5kV

CONTROL UNIT

CPU: 32-bit RISC processor.
Clock Speed: 120 MHz.
Work Memory (RAM): 2 MB
Retentive Memory: 1 MB
Program Memory: 8 MB Flash

Earth-fault relay

Rated Current:1 A or 5 A
Rated Voltage:48–250 V AC/DC
Burden:< 0.5 VA
Contact Rating:5 A @ 250 V AC
Mounting:Panel-mounted
Operating Temperature:-25°C to +55°C

BASIC CONTROLLER

Power Supply Voltage:24 V DC ±10%
Power Consumption:4.5 W
Program Memory 32 kBytes
RAM (Data Memory):16 kBytes
Digital I/O Capacity:128 I/O max
Operating Temperature:0°C to +60°C
Storage Temperature:-25°C to +70°C
Humidity:5% to 95% (non-condensing)

Drive Digital Processor Module

Power Supply Voltage:24 VDC
Power Consumption:< 5 Watts
Operating Temperature:-10°C to +55°C (14°F to 131°F)
Storage Temperature:-40°C to +70°C (-40°F to 158°F)
Humidity:5% to 95% non-condensing

CURRENT TRANSFORMER

CURRENT TRANSFORMER
2000A
24V
NP/NS: 1/4000

SENSOR FLAME SCANNER MODULE

SENSOR FLAME SCANNER MODULE
ASSEMBLY
PCBA
TUV

Power Supply Module

Input Voltage:48–800 VDC
Max Rated Output Power:2.8–11 kVA
Output Current (Peak):4–50 Amps
Over-Temperature: ≥120°C
Main Component:IGBT module

Driver Board

Input Voltage (Logic):24V DC (±10%)
Output Drive Voltage:15V–20V
Max. Switching Frequency:20 kHz
Isolation Voltage:2500V AC
Propagation Delay: <500 ns
Operating Temperature:-20°C to +70°C
Storage Temperature:-40°C to +85°C

APPLICATION BOARD

Supply Voltage:24V DC
Power Consumption:< 2W
Isolation:500V AC
Operating Temp:-25°C to +70°C
Storage Temp:-40°C to +85°C
Humidity:5–95% (non-condensing)

Compact module

Compact installation of I/O modules
Up to 16 channels of field signals
and process power connections
Connections to ModuleBus and I/O modules
Mechanical keying prevents
insertion of the wrong I/O module
Latching device to DIN rail for grounding
DIN rail mounting

IGCT Module

Voltage Class:6.5kV AC/DC
Continuous Anode Current:5,150 A RMS
Surge Current (10ms pulse):45 kA peak
Switching Speed:Turn-off <4.5 μs
Gate Drive:-18V ~ +22V w/±200A
Storage temp. Limit:-40℃ to +100℃

MEASUREMENT BOARD

Input Types: 4–20 mA
Resolution: 16-bit ADC
Power Supply: 24 V DC ±10%
Voltage/Current: ±0.05%
RTD/Thermocouple: ±0.1°C
Operating Temperature: -25°C to +70°C
Vibration: 2 g @ 10–150 Hz
Relative Humidity: ≤95% RH (non-condensing)

Circuit Board

Input Voltage: 24 VDC
Power Tolerance: Operates within ±10%
Analog Signals: 4–20 mA or 0–10 V
Operating Temperature: -25°C to +70°C
Humidity: ≤95% non-condensing

Control board

Voltage: Typically 24 VDC (±10%)
Power Consumption: <5–10 W
Digital Inputs:  8–16 channels
Analog Inputs: 4-20 mA/0-10 V
Temperature Range: -20°C to +70°C

Speed ​​Control Board

Operating Voltage: 24 VDC
Power Tolerance: ±10-15%
Output Type: 0–10 V, 4–20 mA
Speed Range: 0–100%
Temperature Range: -10°C to +55°C (14°F to 131°F)

Speed ​​Control Board

Rated Voltage: 24 VDC
Operating Range: ±10%
Output Type: PWM
Speed Range: 0–100%
Operating Temperature: -10°C to +50°C (14°F to 122°F)
Humidity: ≤95% non-condensing

CONTROL BOARD

Input Voltage:24V DC (±10%, isolated)
Internal Logic:3.3V/5V TTL
Protections:Short-circuit
PCB: 6-layer design
Thermal Rating: 0°C to +55°C
