Siemens Simatic S7

CPU 414-1 Processor Module

6ES74141XG020AB0
DISCONTINUED BY MANUFACTURER
DISCONTINUED SINCE: 01/10/12
SIMATIC S7-400
CPU 414-1 CENTRAL PROCESSING UNIT WITH: MULTI-POINT MPI INTERFACE
128 KB WORKING MEMORY

Analog Input Module

ANALOG INPUT MODULE
SM 331
SIMATIC S7-300
ISOLATED
2 AI
RESOLUTION 9/12/14 BITS
U/I/THERMOCOUPLE/RESISTOR
ALARM
1 X 20-POLE

Simatic S7-300 CPU 315

6ES73151AF030AB0
DISCONTINUED BY MANUFACTURER
CPU SIMATIC S7
48KBYTE
W/ INTEGRATED 24VDC POWER SUPPLY
Tariff Code: 8538903000
Country of Origin: Germany

PS307 Power Supply - 10A

6ES73071KA000AA0
DISCONTINUED BY MANUFACTURER 01/01/2019
POWER SUPPLY
SIMATIC S7-300
REGULATED
INPUT 120/230
10 AMP
24 VDC
Tariff Code: 8504409530
Country of Origin: Austria

TP170 Micro Touch Panel

6AV66400CA010AX0
DISCONTINUED BY MANUFACTURER
END OF PRODUCT LIFECYCLE SINCE: 01/10/18
TOUCH PANEL TP170 MICRO
SIMATIC TOUCH PANEL TP170 MICRO FOR SIMATIC S7-200 5.7" BLUE MODE STN DISPLAY CONFIGURABLE WITH WINCC FLEXIBLE 2004 MICRO
Tariff Code: 8528510000
Country of Origin: Germany

CPU 226 Compact Unit

EM223 Digital I/O Module

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
SIMATIC S7-400H
FOR S7-400H/ S7-400F/FH
3 INTERFACES
1 MPI/DP
768 KB
(256 KB DATA/512 KB PROGRAM)

Analog Input Module

SIMATIC S7-300
Analog input SM 331
isolated, 8 AI; +/-5/10V
1-5 V, +/-20 mA
0/4 to 20 mA
16 bit (55ms)
Single rooting (50 V COM.)
1x 40-pole

FM458-1 DP Application Module

SIMATIC S7-400
FM458-1 DP APPLICATION MODULE
FORSIMATIC S7-400
Number of digital inputs 8; Connector X2
Rated value (DC) 24 V
for signal "0" -1 to +6V
for signal "1" 13.5 to 33V
Resolution 500 ms

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
SIMATIC S7-400H
CPU 417H
FOR S7-400H
4 INTERFACES: 1 MPI/DP / 1 DP / 2 FOR SYNC MODULES
30 MB MEMORY (15 MB DATA/15 MB PROGRAM)

Digital output module

SIMATIC S7-300
Digital output SM 322
isolated, 8 DO, 24 V DC
0.5A (1x 8 DO)
Short-circuit protection diagnostics
1x 20-pole

Analog Input Module - RTD

Analog Input Module

SIMATIC S7-300
Analog input SM 331
isolated, 8 AI; +/-5/10V, 1-5 V, +/-20 mA
0/4 to 20 mA, 16 bit
Single rooting (60 V COM.)
4-channel operation: 10 ms
8-channel operation: 23-95ms, 1x 40-pole

Patch Cable - 1M

SIMATIC S7-400H
PATCH CABLE FO
1M FOR
SYNC-MODULE

DP/DP Coupler

SIMATIC DP
DP/DP coupler
Coupling module for connecting of two
PROFIBUSDP networks
redundant current infeed

FM350-1 Counter Module

6ES73501AH030AE0
COUNTER MODULE
SIMATIC S7-300
FM 350-1 FOR S7-300
500 KHZ
1 CHANNEL FOR CONNECTION
5V-24V INCREMENTAL ENCODERS
ISOCHRONOUS MODE

CPU 313C-2 DP Processor Module

CPU MODULE
SIMATIC S7-300
CPU 313C-2 DP
16 DIGITAL INPUT/16 DIGITAL OUTPUT
3 HIGH-SPEED COUNTERS (30 KHZ)
POWER SUPPLY 24 VDC
MEMORY 128 KB

PS-307 Power Supply Module

Analog Input Module - Failsafe

ANALOG INPUT MODULE
SIMATIC 57
6 INPUTS
24 VDC
150 MA POWER SUPPLY
90 MA BACKPLANE
WITH HART SUPPORT
1X 20-POLE

CR3 Central Rack - 4 Slots

SM 332 Analog Output Module

SIMATIC S7-300
Analog output SM 332
isolated by channel, 4 AI
Resolution 16 bit, 0-10 V
1-5 V, +/-10 V, +/-20 mA
0/4-20mA, 20-pole
suitable for isochronous mode

SYNC SUBMODULE

SIMATIC S7-400H
synchronizationmodule V4
for patch cable to 10 m
from CPU, max. 210 mA
Power loss, typ. 1.1 mW

CP243-1 Communications Processor

Analog Input Module - 2AI High Feature

SIMATIC DP
Electronics module
2 AI I High Feature for ET 200S
15 mm width
Cycle time per module: 0.5 ms, +/-20mA
15 bit+sign, 4.. 20mA
15 bit, Operationallimit
+/-0.1% with SF LED
