Vibro-Meter

Signal Conditioner

Configurable high-pass and low-pass filters
Frequency range: 0.5 Hz to 20 kHz
Optional integrator to produce a velocity output
Optional 2-wire current or 3-wire voltage transmission
Certified for use in potentially explosive atmospheres
A range of installation options are available

Circuit Board

Measurement range: 0.001 gpm to 2.0 gpm
Resolution: 0.0001 gpm
Frequency range: 2 Hz to 10 kHz
Sensor type: piezoelectric sensor
Display mode: Color LCD display screen
Interface: RS232, USB

Circuit Board

Measurement range: 0.001 gpm to 2.0 gpm
Resolution: 0.0001 gpm
Frequency range: 2 Hz to 10 kHz
Sensor type: piezoelectric sensor
Display mode: Color LCD display screen
Interface: RS232, USB

Machinery protection card

Number of inputs : 4 per MPC4 card
DC range : 0 to +20 V or 0 to −20 V
AC range : ±10 V max.
Common mode voltage range : −50 to +50 V
CMRR : >60 dB at 50 Hz
Crosstalk : −72 dB
Input impedance : 200 kΩ
Current input range
DC signals : 0 to 25 mA
AC signals : ±8 mA max.
Analog frequency range : DC to 60 kHz (−3 dB)

Mechanical protection card

Accuracy: ≤±1.5%
Linear error: ≤±0.5%
Output allowable load: >100 kΩ voltage output.< 325Ω current output.
Characteristics of relay
Trunk name: RL1 to RL4
Rated voltage: 250 VAC
Rated current: 5 AAC
Maximum breaking capacity (no contact protection) : 1250 VA

Machinery protection card

Measurement range: 0.001 gpm to 2.0 gpm
Resolution: 0.0001 gpm
Frequency range: 2 Hz to 10 kHz
Sensor type: piezoelectric sensor
Display mode: Color LCD display screen
Interface: RS232, USB

ABB007
DISCONTINUED BY MANUFACTURER
U/I MODULE

UVC 752 Vibration Processor Module

UVC752
DISCONTINUED BY MANUFACTURER
ABSOLUTE VIBRATION PROCESSOR DUAL CHANNEL 101+102
Tariff Code: 8538907080
Country of Origin: Switzerland

UVL682
ABSOLUTE VIBRATION PROCESSOR
DUAL CHANNEL

RPS6U
RACK POWER SUPPLY
18-32 VDC
25A MAX.
OUTPUT 275 WATTS
(200-582-200-013)

UVC 691 Vibration Processor Module
