330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum case length: 50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
1394CSJT10TRL
DISCONTINUED BY MANUFACTURER 07/31/2013
SERVO AXIS DRIVE
GMC TURBO SYSTEM MOD
360/480 V AC
50/60 HZ
3 PHASE INPUT VOLTAGE
8/10 KW CONT POWER OUT (360/480V NOM.)
64K MEMORY AND 32-BIT CPU
WITH REMOTE I/O AND AXISLINK
6ES73146BG030AB0
DISCONTINUED BY MANUFACTURER
COMPACT CPU
24VDC
24 DIGITAL INPUTS
16 DIGITAL OUTPUTS
4 ANALOG INPUTS
2 ANALOG OUTPUTS
96KB INTEGRATED MEMORY
Space requirements: 4 TE, 3 HE (= 4 HP, 3U)
Power requirements: 5 V DC, 35 mA/24 V DC, 35 mA
Number of input channels: 16
Input range: 0-4.1 V
Input resistance: > 1 MΩ
Maximum load capacitance: 100 nF
A/D converter: 12-bit
A/D converter inaccuracy: ± 1 LSB
Module inaccuracy: < 0.25%
Absolute max. input signal: ± 36 V DC
Range 0-4.1 V
SIMATIC HMI
KTP700 Basic, Basic Panel
Key/touch operation
7" TFT display,65536 colors
PROFINET interface,
Type of supply voltage DC
Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Active power input, typ. 5.5 W
Processor type ARM
Memory available 10 Mbyte
Extensive self diagnostics
Optional redundancy
Fast loop scan
Internal or external field power selection
On board excitation power
(no need for marshalling power)
Galvanic Isolation
