We offer a comprehensive range of Invensys automation solutions, focusing on core systems from its flagship brands:
Foxboro（I/A Series Distributed Control System）
Triconex（Tricon CX and Trident (Emergency Stop System)）
Whether you need components for a specific platform (such as the Foxboro I/A Series or Triconex safety system) or need to source replacement/discontinued parts based on device functionality, inquiry us now
We are committed to sourcing the mission-critical Invensys products you need.
We offer a comprehensive range of Invensys automation solutions, focusing on core systems from its flagship brands:
Foxboro（I/A Series Distributed Control System）
Triconex（Tricon CX and Trident (Emergency Stop System)）
Whether you need components for a specific platform (such as the Foxboro I/A Series or Triconex safety system) or need to source replacement/discontinued parts based on device functionality, inquiry us now
We are committed to sourcing the mission-critical Invensys products you need.
Current Output: 4–20 mA
Voltage Output: Optional 0–10 V DC
Typically ±0.1% of full scale
Current Output: 750 Ω (4–20 mA)
Voltage Output: ≥ 1 kΩ (0–10 V)
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Nominal input voltage:24 V D
Operational voltage range:
24 V DC –15%/+20% + 5% AC ripple
Logic power:8 W maximum
input voltage:33 V DC
reverse input voltage:–0.6 V DC
Short circuit current limit per input:2.4 A maximum
Fault current130 mA,
typical200 mA, maximum
Voltage Range: Typically 24 V DC
High (ON): 15–30 V DC
Low (OFF): 0–5 V DC
Channel-to-channel isolation: ≥ 1500 V AC/DC
Typical: < 10 ms
Voltage Range: 24 V DC
Max Continuous Current: 2 A per channel
Inrush Current: Supports up to 5 A for 100 ms
Channel-to-channel isolation: ≥ 1500 V AC/DC
Turn-On Delay: < 1 ms
Operating Temperature:
-40°C to +70°C (-40°F to +158°F)
Nominal input voltage : 24 V DC
Repetition rate : 1 sec minimum
Specified operational voltage range :
24 V DC –15% or +20% + 5%
AC ripple (19.2 to 30 V DC)
Voltage Rating: Up to 300V AC/DC
Current Rating: Up to 10A per channel
Isolation Voltage: 1500V AC between field and system
Contact Resistance: <50mΩ
Wire Size: Accepts 12-24 AWG
Material: Flame-retardant plastic housing
Dielectric Strength: 2000V AC for 1 minute
Points:32, commoned
Nominal input voltage:24 V DC
Operational voltage range:15–30 V DC
Absolute maximum input voltage:33 V DC
Absolute maximum reverse input voltage:–0.6 V DC
Input delay:<10 ms, On to Off or Off to On
ADC scan time:<1 ms for all 32 points
