Local Bus Power:12 VDC at 150 mA
Bussed Field Power:24 VDC at 300 mA
Field Circuit: 24 VDC at 30 mA/Ch.
Ambient Temperature -40 °C to +70 °C
Shock 10 g half-sine wave for 11 ms
Vibration 1 mm peak to peak from 2 to 13.2Hz
0.7 g from 13.2 to 150 Hz
AirborneContaminantsISA-S71.04 –1985
AirborneContaminants Class G3
Relative Humidity:5 to 95% Non-Condensing
3300 XL 8 mm Probe, M10 x 1 thread
without armor
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
Order in increments of 10 mm
Metric thread configurations:
Maximum case length: 250 mm
Minimum case length: 20 mm
Example: 0 6 = 60 mm
0 4 0-4 mils pp (0-100 μm pp)
5 0 5.0 metres (16.4 feet)
0 1 35 mm DIN rail clips
0 0 Not required
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.
71 = 7.0 metres (23.0 feet) system length, DIN mount
CN = Approvals country specific
(CN Approvals Option Quick Reference Guide and
Field Notification Letter are in the download section)
Operating Temperature: -35°C to +85°C (-31°F to +185°F)
Storage Temperature: -51°C to +105°C (-60°F to +221°F)
Proximitor Sensor Material: A380 aluminum
Proximitor Sensor Input : Accepts one non-contacting 3300 RAM or 3300 NSv Proximity Probe and Extension Cable.
Power : Requires -17.5 Vdc to -26 Vdc
without barriers at 12 mA
maximum consumption, -23 Vdc to -26 Vdc
voltage than -23.5 Vdc
7 0 7.0 metres (23.0 feet)
0 1 35 mm DIN rail clips
0 0 Not required
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.
330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum case length: 50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum case length: 50 mm
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
00 Not required
330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 60 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
330104 3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum case length: 40 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
330704 3300 XL 11 mm Probe
M14 x 1.5 thread,with armor
Minimum unthreaded length:0 mm
Minimum length: 50 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length:0.0 in
Minimum case length: 0.8 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required
0 2 M8 X 1 integral stud
0 5Multiple approvals (CSA, ATEX, IECEx,)
Sensitivity 10.2 mV/m/s2 (100 mV/g) ±5%.
AmplitudeLinearity±1% to 490 m/ s2 (50 g) peak
FrequencyResponse10 Hz to 15 kHz
TransverseSensitivity Less than 5% of axial.
Amplitude ofResonantPeak20 dB maximum
MountedResonantFrequencyGreater than 30 kHz
Linear Measurement Range 2 mm (80 mils)
Initial Air Gap 0.5 mm (20 mils)
Incremental Scale Factor (ISF) ISO:
8 V/mm (203.2 mV/mil) ± 5%@
temperature range 0 to 45°C(+32 to +113°F)
Deviation from best fit straight line(DSL)
± 0.025 mm (± 1 mil)@ temperature rang
Minimum Shaft Diameter 25 mm (0.79”)
