3500 System

Aero GT Vibration I/O Module

12659901
VIBR I/O MODULE
Aero GT I/O Module Internal Terminations

Proximitor ET BlockEuro Style Connectors

125808-01 Proximitor ET BlockEuro Style Connectors
Signal :Accepts from 1 to 4 proximitytransducer signals
Power consumption :7.7 Watts, typical
Standard I/O: 10 kΩ
Output Impedance:550 Ω
Transducer Power Supply:-24 Vdc
Gap filter:-3 dB at 0.09 Hz
Smax : 0.125 to 15.8 times runningspeed

RACK

01 19-inch Rack (14 module slots)
01 Panel Mount Option, Full-Size Rack
01 CSA/NRTL/C (Class 1, Division 2)
00 None
01 CE

Universal AC Power SupplyModule

350015
DISCONTINUED BY MANUFACTURER
POWER SUPPLY MODULE
1.9/7.5 AMP
95-125 VAC
190-250 VAC
47/63 HZ

Enhanced Keyphasor Module

3.2 Watts typical
21.8 kΩ minimum
Specified at +25°C (+77°F).
Proximity: -2V to -18V
MPU: 5 mV to 50 V peak
Range: 1 RPM to 99,999 RPM
Accuracy: ±0.1% of reading

OVERSPEED DETECTION SYSTEM

OVERSPEED DETECTION SYSTEM
FOR THE 3500 SERIES MACHINERY DETECTION SYSTEM
ELECTRONIC
INPUT IMPEDANCE: 20 K
8.0 WATTS
OUTPUT IMPEDANCE: 550
24VDC
40MA MAX.

Tachometer Module

350050M
TACHOMETER MODULE
5.8 WATT
3 LED
550 OHM
2 INPUT

I/O MODULE

I/O MODULE
COMMUNICATION GATEWAY MODULE
Modbus RS232/RS422 I/OModule

Isolated Tip TC I/O Module

3500/65 RTD/ Isolated Tip TC I/OModule
External Terminations
Channel-to-Channel:1500V AC
Analog Output:4-20mA
Supply Voltage: 24V DC ±10%
Resolution:0.1°C
Input Impedance:>1MΩ

Modbus RS485 I/O Module

Ethernet TCP/IP Capabilities
Serial (RS232/RS422/RS485)
Communications Capabilities
RJ45 Ethernet Connection
Configurable Modbus Register Utility

AC POWER INPUT MODULE

106M108101
AC POWER INPUT MODULE
85-264 VAC
2.8 AMP
47-63 HZ

Power Supply Module

Product No. : 3500/15-05-05-00
Product type : 3500/15 AC and DC Power Supplies
Model : 3500/15 = Power supply
Power supply type : 05 = Universal AC voltage (85 to 264 Vac rms)
Power supply type : 05 = Universal AC voltage (85 to 264 Vac rms)
Agency approval option : 00 = None

Transient Data Interface

Channels Supported: Up to 16 channels
Sampling Rate:Up to 100 kHz
Adjustable resolution:12-bit to 16-bit ADC
Power Supply: 24 VDC
Standards: API 670

Tachometer Module

InputImpedance:20 k Ω (standard)
MPU: 1 VAC to 50 VAC
Proximity Probe: -2 VDC to -18 VDC
Range: 0.1 RPM to 99,999 RPM
Accuracy: ±0.1% of reading
Power Supply: 15–30 VDC

Vibration Monitor

Radial Vibration
Thrust Position
Differential Expansion
Shaft Absolute
Eccentricity
Acceleration
Velocity

16-Channel Relay Output Module

14999201
RELAY OUTPUT MODULE
16-CHANNEL
SPARE

Proximitor Seismic Monitor I/O Module

Series: 3500
Input Signal: -10 Vdc to +10 Vdc
Power Consumption: 10.5 watts
Front Panel: USB-B
Product Type: Proximity Seismic Monitor I/O Module
Ethernet: 100Base-FX Fiber-Optic
Operating Temperature: -30°C to +65°C

Recip Cylinder Pressure Monitor

Series: 3500 Series
Standard: 0-5,000 psi (0-345 bar)
Sampling Rate: Up to 100 kHz per channel
ADC Resolution: 16-bit
Power Supply: 24 VDC (±10%)

Display Interface Module

350093
DISCONTINUED BY MANUFACTURER
DISPLAY INTERFACE I/O MODULE
15.5 W MAX
-20C TO 65 DEGREE C W/ DISPLAY COMMUNICATIONS PORT
PWA 135799-01
Tariff Code: 8517620050
Country of Origin: United States

Overspeed Detection Module

Input Impedance:20 kΩ
OutputImpedance:550 Ω
TransducerPower Supply:-24 Vdc, 40 mA maximum.
EnvironmentalSealing:Epoxy sealed
ArcSuppressers:250 Vrms
Min switchedcurrent:100 mA @ 5 Vdc
Contact Life:100,000 @ 5 A, 24 Vdc or 120 Vac.

Proximitor I/O Module

12568001
Proximitor I/O Module
3500 SYSTEM
3500/40M
PWA 140734 01H
PROXIMITOR

Transient Data Interface I/O Module

14603101
GENERAL ELECTRIC
BENTLY NEVADA
I/O MODULE
TRANSIENT DATA INTERFACE

Shaft Absolute I/O Module

(4) Channel Monitor
Accepts Input from Proximity and Seismic Transducers
Machinery Protection
Provides Essential Machine Information
 3500/42M Series Proximitor / Seismic Monitors

Ethernet/RS232 Modbus I/O Module

Accepts from 1 to 16 signals
Input impedance: Greater than 1 MΩ
Power consumption: 3 watts
Front panel LEDs: OK, TX/RX, Bypass
Type E, J, K, T thermocouples
100 Ω 3-wire and 4-wire platinum RTD

Position I/O Module

PLC TERMINAL MODULE
I/O MODULE POSITIONER
SCREW TERMINALS
