Bently Nevada

Proximity ProbeHousing Assemblies

28 3300 XL 8mm probe
selectablehazardous area approvals
05 0.5 m (20 in)
 4.1 in (94 mm) = 041
03One 3/4-14 NPT plug
One 3/4-14 to 1/2-14 NPT reducer
One cable seal grip with grommets for
the following cable sizes:
• 1/8 to 3/16 inches
• 1/4 to 5/16 inches
• 5/16 to 3/8 inches
023/4-14 NPT

3300 XL 50 mm Proximity Probe

0 1 ½-20 Thread
9 09.0 meters (29.5 feet)
0 0High Temperature FluidLocCable
0 0 No Approvals

3300 XL 11 mm Proximity Probes

330703  3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length:100 mm
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable

PROXPAC XL Proximity TransducerAssembly

Operating Voltage:-18 to -26V DC
Current Consumption:2-12mA
Output Signal:-1 to -20V DC
Sensitivity:200mV/mil (7.87V/mm) ±5%
Frequency Response:0 to 10kHz (-3dB)
Measurement Range:0.25 to 2.5mm
Linear Range :0.5 to 2.0mm
Resolution:1μm (0.04 mils)
Temperature Drift:±0.1%/°C

PROXPAC XL Proximity Transducer

2 8  3300 XL 8 mm probe with MultipleApprovals
1 5 1.5 in (38 mm)
0 3 5 3.5 in (96 mm)
0 0No fittings; two plugs and twowashers
0 2 3/4-14 NPT
(Required if orderingStandoff Adapter Option.)

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
Minimum unthreaded length: 0.0 in
Minimum case length:  1.9 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cabe
00 Not required

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 160 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 XL 11 mm Proximity Probes

330703  3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length:100 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 Multiple Approvals

3300 XL 11 mm Proximity Probes

330703  3300 XL 11 mm Probe
M14 x 1.5 thread,without armor
Minimum unthreaded length:0 mm
Minimum length:100 mm
10 1.0 meter (3.3 feet)
11Miniature coaxial ClickLocconnector
with connector
00 Not required

3300 XL 8 mm Proximity Probes

330101 3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum unthreaded length: 0.4 in
Minimum case length: 1.6 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 70 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL Standard Extension Cable

3300 XL Standard Extension Cable
040 4.0 meters (11.5 feet)
12 FluidLoc cable with connectorprotector
00 Not required

3300 XL 11 mm Proximity Probes

330710 3300 XL 11 mm Probe
M16 x 1.5 thread,with armor
Minimum unthreaded length:0 mm
Minimum length:50 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
Minimum unthreaded length: 0.0 in
Minimum case length:  7.0 in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Reverse Mount Probes

3300 XL 8 mm Reverse Mount Probes
330106-05-30-CC-DD-EE M10 x 1 threads
10 1.0 meter (3.3 feet)
00 Not required

3300 NSv Proximity Probes

330901 3300 NSv Probe
1/4-28 UNF thread,without armor
Minimum unthreaded length: 1.6 in
Minimum case length:2.4in
10 1.0 meter (39 in)
02 Miniature coaxial ClickLoc connector
standard cable
05 Multiple Approvals

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 1.5 in
20 2.0 meters (6.6 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 2.5 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330101  3300 XL 8 mm Probe
3/8-24 UNFthread, without armor
Minimum unthreaded length: 0.0 in
Minimum case length: 1.1 in
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

3300 XL 11 mm Proximity Probes

330704  3300 XL 11 mm Probe
M14 x 1.5 thread,with armor
Minimum length:100 mm
10 1.0 meter (3.3 feet)
01Miniature coaxial ClickLocconnector
with connectorprotector, standard cable
05 Multiple Approvals

Interconnect Cable

Conductors: 20 AWG shielded twisted pairs
Voltage Rating: 60V DC max
Current Capacity: 2A per conductor
Impedance: 100Ω ±15%
Shielding: Foil + braid
Bend Radius: ≥5x cable diameter
Jacket Material: PVC (oil-resistant)

3300 XL 8 mm Proximity Probes

330103 3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 150 mm
50 5.0 meters (16.4 feet)
02 Miniature coaxial ClickLocconnector
standard cable
00 Not required

3300 NSv Proximity Probe

Chemical-Resistant: Outperforms 3300 RAM probes
Thread: M10x1
Linear Range: 1.5mm (60 mils)
Gap Setting: 1.0mm (40 mils)
Torque: 7.5 N·m max
Multiple Global Approvals
MIL-C-5015 connector standard

Velomitor Piezo‑Velocity Sensor

03 1/4-28 UNF
04 Multiple approvals (CSA, ATEX)
Sensitivity:3.94 mV/mm/s (100mV/in/s) ±5%.
Velocity:Range 1270 mm/s (50 in/s) peak
Output BiasVoltage-12 ±3.0 VDC
overtemperature referenced toPin A
DynamicOutputImpedanceLess than 2400 Ω
