1793OB16P
DISCONTINUED BY MANUFACTURER
DIGITAL OUTPUT MODULE
FLEX INTEGRA
16 POINT
24 VDC DIGITAL OUTPUTS
SOURCE
PROTECTED
SPRING-CLAMP TERMINALS
DIN RAIL MOUNT
Tariff Code: 8538907080
Country of Origin: Malaysia
1788ENBT
DISCONTINUED BY MANUFACTURER
DISCONTINUED DATE: 12/31/2016
ETHERNET/IP DAUGHTER CARD
UNSHIELDED
TWIST PAIR RJ45
FOR FLEXLOGIX/DRIVELOGIX
Tariff Code: 8517620050
Country of Origin: United States
Product Family:PLC5
Power Dissipation:17.3W
Backplane current load:3.3A
Memory:100 KWords
Battery:1770-XYC
Maximum Number of I/O Racks:93
Maximum number of I/O per link:32
Max User Memory Words:48 Kilowords
1785L80B
DISCONTINUED BY MANUFACTURER
CPU MODULE
100K WORD SRAM
PLC-5/80
TOTAL I/O 3072/ ANALOG
4 DH+/REMOTE I/O CHANNELS
Tariff Code: 8537109060
Country of Origin: United States
1785L40B
DISCONTINUED BY MANUFACTURER
PLC CPU MODULE
48K WORD SRAM
PLC-5/40
2048 ANALOG I/O
4 DH+/REMOTE I/O CHANNELS
EEPROM PROGRAM BACKUP
Country of Origin: United States
1785L20E
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
16K WORD SRAM
EMBEDDED TCP/IP COMMUNICATION
ETHERNET/IP
PLC-5
PLC-5/20
Country of Origin: United States
1784PCMK
DISCONTINUED BY MANUFACTURER
DEVICENET COMMUNICATION CARD
68 PIN CONNECTOR
PCMIA TYPE II
5 VDC AT 160 MA
***MUST SELECT SERIES***
Country of Origin: United States
1784PCC
DISCONTINUED BY MANUFACTURER
CONTROLNET COMMUNICATION CARD
68 PIN CONNECTOR
PCMIA TYPE II
5 VDC AT 225 MA
Tariff Code: 8517620050
Country of Origin: United States
1784KTXD
DISCONTINUED BY MANUFACTURER
COMMUNICATION INTERFACE CARD
REMOTE SCANNER
DH+ AND/OR DH-485
2 CHANNEL
ISA HALF SIZED CARD
INSERTED INTO 16 BIT ISA/EISA EXPANSION SLOT
600 MA AT 5 VDC
1784KTX
DISCONTINUED BY MANUFACTURER
COMMUNICATION INTERFACE CARD
REMOTE SCANNER
DH+ OR DH-485
PLC-2 / PLC-3 DIRECT CONNECT
1 CHANNEL
ISA HALF SIZED CARD
INSERTED INTO 16 BIT ISA/EISA EXPANSION SLOT
600 MA AT 5 VDC
Tariff Code: 8517620050
Country of Origin: United States
1775S4B
DISCONTINUED BY MANUFACTURER
I/O SCANNER-MESSAGE HANDLING MODULE
PLC-3
2048 INPUTS AND 2048 OUTPUTS
4 I/O COMMUNICATION
1 RS-232-C COMMUNICATION
57.6 BAUD OR 115.2 KBAUD (I/O)
110-19.2 KBAUD (RS-232-C)
5.5-6.5 MS SCAN TIME
2.7 AMPS AT 5 VDC
1775S4A
DISCONTINUED BY MANUFACTURER 2014-04-29
I/O SCANNER PROGRAMMER INTERFACE
DIMENSIONS: 2.0" X 11.0" X 12.0"
MODULE
4 INPUT/OUTPUT COMMUNICATION
RA-232 C COMMUNICATION
INPUT/OUTPUT SCAN PRIORITY
Tariff Code: 8517620050
Country of Origin: United States
1772LS
DISCONTINUED BY MANUFACTURER
DISCOUNTINUED BY MANUFACTURER
PROCESSOR MODULE
MINI-PLC-2/05
3KWORD
CMOS RAM
.42AMP
120VAC
50/60HZ
Country of Origin: United States
1771P4R
DISCONTINUED BY MANUFACTURER
POWER SUPPLY
REDUNDANT
1 SLOT
8 AMP
120 VAC
50/60 HZ
5 VDC
Tariff Code: 8504409520
Country of Origin: United States
1771IL
DISCONTINUED BY MANUFACTURER
INPUT MODULE
ANALOG
8 POINT
ISOLATED
10 VDC INPUT
20 MA
1.4 AMP AT 5 VDC BACKPLANE
Tariff Code: 8538903000
Country of Origin: United States
1771HS3A
DISCONTINUED BY MANUFACTURER IMC-123 3
MODULE
SERVO CONTROL
AXIS SERVO CONTROLLER
3 AXIS
Tariff Code: 8504909550
Country of Origin: United States
Product Line:CompactLogix
Product Type:Compact I/O
Module Type:Output Module
Input Type:Analog Output
Compatible Controllers:MicroLogix 1500; 1769 CompactLogix
No. of Groups: 2 groups (4 inputs each)
Shipping Weight:2 lbs.
Voltage Category:120-240 VAC
Shipping Dimensions:8x8x5 in.
Series:A and B
Operating Voltage range:85V ac to 265VAC
Operating frequency:47 to 63 H
Product Type:CompactLogix Controller
Module TypeProcessor Module
Part Number:1769-L35E
User Memory:1.5MB
Memory1.5 MB
Non-Volatile memory:1784-CF128
Shipping Dimensions8 x 8 x 5 inches
Communication ports:1 RS232; 1 Ethernet
Series:A and B
Supported Protocols:DH485; DF1; ASCII; EtherNet
Wire Type:Copper - 90 degrees Celsius
Maximum number of I/O modules supported: 30 Modules
Wire Size (Solid):22 to 14 AWG
1769L31
CPU MODULE
DUAL SERIAL 512K
COMPACT LOGIX
COMPACTLOGIX DUAL SERIAL PORT CONTROLLER
512 KB MEMORY
COMMUNICATION PORTS: 2 X RS-232 PORTS (ISOLATED DF1 OR ASCII & NON-ISOLATED DF1 ONLY)
Tariff Code: 8537109060
Country of Origin: United States
1769L20
DISCONTINUED BY MANUFACTURER
PROCESSOR MODULE
COMPACTLOGIX 5320
64K MEMORY
RS-232 COMMUNICATION
Tariff Code: 8537109060
Country of Origin: United States
Backplane current:0.160 A at 24V DC
Series:ControlLogix; ProcessLogix
Weight, approx.:0.452 kg (14.53 oz)
Module Type:System Redundancy Module
Connector:SC Type
Mounting:ControlLogix chassis
Enclosure type rating:None (open-style)
Power dissipation, max:11.28 W
Supported Controllers:Logix 5560
Thermal dissipation, max:38.49 BTU/hr
1756SYNCH
COMMUNICATIONS MODULE
CONTROLLOGIX
SYNCHLINK BRIDGE
TIME SYNCHRONIZATION
COORDINATED MOTION AND DRIVE CONTROL
5MBPS
1 FIBER OPTICCHANNEL
1 TX FIBER OPTIC PORT
1 RX FIBER OPTIC PORT
Country of Origin: United Kingdom
1756OF4
I/O MODULE
CONTROLLOGIX
ANALOG OUTPUT
4 VOLTAGE OR CURRENT OUTPUTS
+/-10 VDC
0-20 MA
15 BITS
Tariff Code: 8538907080
Country of Origin: United States
1756M03SE
SERCOS INTERFACE MODULE
CONTROLLOGIX
3 DRIVES/AXIS
4-8 MBPS DATA RATE
2.5 MA AT 24 VDC
BACKPLANE: 760 MA AT 5.1 VDC
0 TO 60 DEGREE C OPERATING TEMPERATURE
1756L75
CONTROLLER
CONTROLLOGIX
32 MB USER MEMORY
0.98MKB I/O MEMORY
USB PORT
500 CONTROLLER CONNECTIONS
4 CHARACTER ALPHA/NUMERIC DISPLAY
5MA @ 1.2VDC
800MA @ 5.1VDC
Tariff Code: 8537109060
Country of Origin: United States
Series:ControlLogix
Module Type:Analog Input
Inputs:6-Points, Isolated
Conversion Method:Sigma-Delta
Backplane Current (5Volts):250 mA
Backplane Current (24Volts):100 milliamps
Power Dissipation (Max)Voltage: 3.7 W Current: 4.3 W
Series:ControlLogix
Inputs:6-Point Isolated, Current Sourcing
Conversion Method Sigma-Delta
Input Resolution:0-21 milliamps Range
Backplane Current (5Volts):250 milliamps
Backplane Current (24Volts):275 mA
Power Dissipation (Max):5.1 Watts at 60 Celsius
1756IB16ISOE
OUTPUT MODULE
CONTROLLOGIX
DC DIGITAL
16 POINT
10-55 VDC
INDIVIDUALLY ISOLATED
SEQUENCE OF EVENTS RECORDING
INPUT AND COMMUNICATION STATUS AND MODULE HEALTH DISPLAY
1756IB16D
INPUT MODULE
12-24 V DC SINK
10-30 V DC
MIN OPERATING CURRENT: 2 MILLIAMPS 10 V DC
MAXIMUM 13 MILLIAMPS 30 V DC
1.5 MILLAMPS PER POINT
5.8 WATTS AT 60 DEGREES C
Country of Origin: Malaysia
