Logic Side: 24 V DC (±10%)
High-Side Gate Drive: 15 V
Negative Turn-Off Voltage: -8 V
Isolation Voltage: 2500 V AC
Output Current (Gate Drive): 2-5 A
Rise/Fall Time: <100 ns
Operating Temperature: -20°C to +70°C
Power Supply Input:24 VDC ±10%
Logic Voltage Levels:5 VDC (TTL)
Communication Interface:Fiber-optic, RS-485
Input Voltage (Power Cell):230–690 VAC
Max Cells per Drive:10–28 cells
Operating Temperature:–20°C to +55°C (0–45°C ideal)
Relative Humidity:≤95% (non-condensing)
Altitude:Up to 1000 m (no derating)
Robicon NXG Power Supply
High Voltage Inverter DCR Power Supply
AC Input: 480V–600V AC
Input Current: Typ. 10–20 A
DC Output Voltage: 24V–48V DC (±1%)
Efficiency: >90%
Power Factor: ≥0.95
Isolation Voltage: ≥2500 VAC
Standard: –20°C to +55°C
Low-voltage control signals:5V, 24V DC
Medium-voltage isolation:up to 4160V
Control signals: ≤ 5A
Gate driver power: ≤ 10A
PWM signals to IGBT gate drivers
DC bus voltage sensing
SIPLUS NET
OLM/P11 V4.0
based on 6GK1503-2CA01
with conformal coating
-25…+60 °C
optical link module with 1 RS485 and 1 plastic FOC interface
(2 BFOCsockets)
with signaling contact and test port
Input Voltage:24V DC
Current Rating: ≤10A
Isolation:2500V AC
Reinforced insulation per IEC 61800-5-1
DC bus voltage:0–10V analog
Overvoltage (OV)/Undervoltage (UV)
