Design of display TFT
Screen diagonal 7.5 in
Number of grayscales 0
Number of colors 65 536
Color type Colors
Horizontal image resolution 640 Pixel
Vertical image resolution 480 Pixel
MTBF backlighting (at 25 °C) 50 000 h
Brand:GE Fanuc
Series:Series 90-30
Part Number:IC693CBL316
Description:Serial Cable
Cable Length:3.0 Feet
Connector Type:9-pin D-shell connector and 6-pin RJ-11 Connector
Application:90-30 Series CPU and Digital Servo Modules
Wire Shield:Yes
Average Weight:2.0 Pounds
Number of channels 8
Channel Update Rate 24 mS
Output Range 4 to 20 mA
D/A Resolution 14 bits
Accuracy over Temperature Range 0.25% of Span
Output Loading 4-20mA into 700 ohm load Maximum
Number of Digital Inputs: 6 discrete digital inputs.
Configurable for 24 VDC, 48 VDC, or 125 VDC
Logic 0 (Low): 0-3 V.
Logic 1 (High): 15-250 V
Continuous Current Rating: 10 A at 250 VAC or 30 VDC
Operating Temperature: -40°C to +70°C.
Storage Temperature: -40°C to +85°C.
Humidity: 5% to 95% non-condensing
