Speed Protection Module

Nominal Operating Voltage: 125 VDC
Voltage Range: 85–250 VDC
Power Consumption: Typically <10W
Range: 0–100,000 RPM
Accuracy: ±0.1% of full scale
Operating Temperature:-40°C to +70°C (-40°F to +158°F)
Storage Temperature:-40°C to +85°C (-40°F to +185°F)

Speed Protection Module

Operating Voltage:125 VDC
Voltage Range: 85–250 VDC
Power Consumption: typically <10W
Range: 0–100,000 RPM

Embedded Controller Module

Product Type: PAMC Acoustic Monitor (Processor)
Software: ControlST V04.03.18C
Relative humidity: 5% to 95%, no-condensing
Power Requirements +32 V dc to 18 V dc
Microprocessor: Freescale Power PC (Power QUICC II PRO 667 MHz)
Memory: 256 MB DDR SDRAMs

Power Supply Module

Product Type: Power Supply Module
Nominal Rated Voltage: 24 volts DC
Input Voltage Range: 18 to 32 VDC
Input Power: 160 watts at full load
Output power: 90 watts
Location on Baseplates: Leftmost slot
DC Output: +5VDC, +12 VDC, -12 VDC

PROTECTION RELAY

369 Motor Management Relay
369 - Basic unit (no RTD)
HI-50-300 VDC / 60-265 VAC control power
R-Optional 12 RTD inputs (built-in)
M-Optional metering package
0-No optional Fiber Optic Port
E-Optional Modbus/TCP protocol interface
0-No Harsh environment option

CENTRAL PROCESSING UNIT

CENTRAL PROCESSING UNIT
64MHZ
32-BIT FLOATING
1MBYTE MEMORY
SERIES 90-70

Analog Input Terminal Board

4-20 mA current loops
0-5 V or 0-10 V DC voltage signals
Operating Temperature Range: -30°C to +65°C
Storage Temperature Range: -40°C to +85°C
Humidity: 5% to 95% RH, non-condensing

Turbine Protection Input Terminal Board

Series: Mark VIe
Simplex Primary Turbine Protection Input Terminal Board
Number of inputs: 4
Number of outputs: 2
MPU pulse rate range: 2 Hz to 20 kHz
Contact voltage sensing: 20 V dc
Technology: Surface mount
Temperature: -30 to +65C

CPU module

Series:RX3i PacSystem
Part Number:IC695CPE305CA IC695CPE305CA-BCAD
Compatibility:PACSystems RX3i
Clock Speed:1.1 GHz
RAM:5MB
NVRAM:10MB
Serial Ports:2
Communication standards:RS232; RS485
Ethernet Port:One (1)
Maximum Program Blocks:512
Maximum Block Size:128 kilobytes
Number of Slots:1
Number of Local Racks:8
Program Storage:5 MB of User Memory
Type of Memory Storage:SRAM, Flash
Processor Speed:1.1G Hertz
Floating Point:Yes
Serial Communication:RS-232
Ethernet Port:Yes

Turbine Emergency Trip Terminal Board

Mark VI
Triple Modular Redundancy (TMR)
Input Voltage Range: 24 VDC to 125 VDC
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Humidity: Up to 95% non-condensing
