PanelView Plus Graphic Terminal

NCU 572.5 Processor Module

AOP30 Operator Panel

5.7-inch color TFT LCD
320 x 240 pixels
Input Voltage:24 V DC ±15%
Power Consumption:≤15 W (typical)
Operating Temperature:0°C to +50°C
Storage Temperature:-40°C to +70°C
Humidity:≤95% RH (non-condensing)

3300 XL Proximitor Sensor

3300 XL Proximitor Sensor
11 1.0 meter (3.3 feet) system length
51 5.0 meters (16.4 feet) system length
91 9.0 meters (29.5 feet) system length
05 CSA, ATEX, IECEx  Approvals

3300 XL 8 mm Proximity Probes

330103  3300 XL 8 mm Probe
M10 x 1 thread,without armor
Minimum unthreaded length: 0 mm
Minimum case length: 120 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable

LAN Communication Card

Data Transfer Rate: Up to 2.5 Mbps
Dimensions: Standard 6U card size for easy installation
in GE control system racks.
Power Requirements:
Logic Power: +5V DC.
Auxiliary Power: 3.3V DC or as specified by the system.
Power Consumption: <10W (typical).
Connector: Multi-pin slot connectors compatible

PC BOARD

Processor:32-bit RISC
Clock Speed:100 MHz
RAM:128 MB
Flash Memory:64 MB
Operating Voltage:24-250V DC/AC
Power Consumption:5-10W
Isolation Voltage:2kV AC

IGBT module

Collector-Emitter Voltage:1200 V
Gate-Emitter Voltage±20 V (max)
Turn-On Delay Time:80 ns (typical)
IGBT Junction-to-Case:0.08 K/W
Diode Junction-to-Case:0.10 K/W
Operating Junction Temperature:-40°C to +150°C
Storage Temperature:-40°C to +125°C

GATEWAY I/O PACK

INTERFACE COMMUNICATIONS MODULE
PROFIBUS MASTER GATEWAY I/O PACK
TURBINE I/O

3300 XL 25 mm Extension Cable

3300 XL 25 mm Extension Cable
0 8 0 8.0 metres (26.2 feet)
2 4 High Temperature FluidLoccable

Motor incl pinion

Rated Power:7.5kW
Rated Torque:48Nm
Rated Speed:1500 rpm
Max Speed:3000 rpm
Rated Current:18A
Voltage:400V AC (3-phase)
Frequency:0-300Hz
Resolution:20-bit

Control Module

Supply Voltage:24V DC (±10%)
Power Consumption:20W (max)
Isolation:1500V AC
Digital Inputs:24V DC
Analog Inputs:0-10V/4-20mA,
Processor:Dual-core 32-bit DSP
Control Cycle:25µs (torque control)
Memory:128MB Flash

MicroLogix 1100 Small Logic Controller

Control Module

Processor:Dual 32-bit PowerPC @ 400MHz
Control Cycle:50ms (typical)
Memory:256MB DDR3 RAM
Supply Voltage:24V DC (±10%)
Power Consumption:25W (typical)
Isolation:1500V AC

Circuit Board

Processor:Dual-core 32-bit DSP
Clock Speed:300 MHz
RAM:256 MB
Flash Memory:128 MB
Operating Voltage:24-250V DC/AC
Power Consumption:12W (typical)
Isolation Voltage:2.5kV AC

DC Governor Module

Supply Voltage:24V DC (±10%)
Power Consumption:18W (typical)
Isolation:1500V AC
Analog Inputs:4-20mA
Digital Inputs:24V DC
Control Accuracy:±0.1% of span
Response Time:<50ms (10-90% step change)
Control Modes:Speed, Load, Pressure

CONTROL UNIT

Control Resolution:24-bit
Loop Update Time:250µs
Speed Control Accuracy:±0.01% of setpoint
Torque Control Accuracy:±0.5% of rated torque
Analog Inputs:±10V/4-20mA
Digital Inputs:24V DC
Input Voltage:24V DC (±15%)
Power Consumption:25W (typical)

Excitation board

Processor:Triple 32-bit
Memory:512MB DDR3 RAM
Control Loops:Up to 128 PID loops
Input Voltage:24V DC (±15%) or 120V AC
Power Consumption:35W (typical)
Isolation:2.5kV AC

INTERFACE CARD

Power Supply:24V DC (±10%)
Power Consumption:8W (typical), 12W (max)
Isolation:1.5kV AC
ESD Protection:±8kV
Port Configuration:4x RJ45
Data Rate:10/100/1000Mbps
Latency:<50µs per hop
Jitter:<10µs
