IGCT Module

Blocking Voltage : 4500V
Maximum Repetitive Off-State Voltage:4500V
Gate Trigger Voltage (VGT): 1.5V–2.5V
Peak Surge Current (ITSM): 25–30kA
Critical Rate of Current Rise (di/dt): 1kA/µs
Turn-On Time (ton): <5µs
Turn-Off Time (toff): <10µs
Switching Frequency: Up to 500Hz

Touch Panel TP 170B Color

1715 16 Point Digital Input Module

High-speed Analog I/O Module

Inputs:4 high speed sub-millisecond differential
Module Type:High Speed Analog Input / Ouptut Module
Outputs:2 high speed current-voltage
Input signals ranges:± 10V
0…10V; 0…5V; 0…20 mA
Input Resolution:14 bits across ±10.5V DC
12 bits across 21 mA
No. of Outputs 2 high speed current/ voltage
Output Resolution:13 bits across 21 mA = 2.8 µA/bit;
14 bits across 21.8V = 1.3 mV/bit
Output Signal Ranges:± 10V; 0…20 mA

SITOP REDUNDANCY MODULE 10A

SITOP PSE202U 10A
Redundancy module
Input/output:
24 V DC suitable for
decoupling two SITOP
power supplies with
maximal per 5 A output current

Bus Interface Module

Simatic S7-300 Rail

SIMATIC S7-300
mounting rail
length: 530 mm

PSU200M Power Supply - 5A

SITOP PSU200M 5 A
stabilized power supply
input: 120/230-500 V
AC output: 24V DC/5 A
1-phase and 2-phase AC or DC
supply voltage at DC 110 ... 220 V
input voltage at DC 88 ... 350 V

ControlLogix Power Supply Bundle

Input Voltage:120/240VAC
Input Voltage Range:85-264VAC
Max Inrush Current:20 Amperes
Output Power:75 W @ 0…60 °C (32…140 °F)
Annunciator Power:240V AC 50/60 Hz, 240V DC, 50 mA, resistive only
Hold Up time:2 cycles @ 60 Hz; 2 cycles @ 50 Hz
Input Voltage:85-265 VAC

RING REPEATER

RING REPEATER
CONTROLNET
FIBER
DUAL FIBER OPTIC CHANNEL
DIN RAIL MOUNTING
FOR 62.5/125 UM MULTI-MODE
USE TO 10000 M

Auxiliary Smart Battery Module for PACSystems. Provides low battery signal to the CPU. Module mounts external to the controller.

Frequency Converter Rectifier Module

Industrial Control Module

PMP10.24SIC
Programmable Safety Controller Module
Power Supply:24V DC
Power Consumption:8W typical
Input Channels:16
Output Channels:8
Processing Speed;100ms safety cycle time

DeviceNet Master Module for RX3i. Module can only be located in the CPUbase. The module is on the high speed serial bus.
