Amikon Limited carry a substantial inventory of Allen Bradley PLC spares, HMI, DC Drives, Servo & Inverter Drive. We majory in supplying ControlLogix, CompactLogix, SLC, PLC-5, PanelView, PanelView Plus ,Rockwell ICS Triplex Regentand Powerflex.
Amikon Limited carry a substantial inventory of Allen Bradley PLC spares, HMI, DC Drives, Servo & Inverter Drive. We majory in supplying ControlLogix, CompactLogix, SLC, PLC-5, PanelView, PanelView Plus ,Rockwell ICS Triplex Regentand Powerflex.
Module Width:Single Slot
Compatible controllers:SLC 5/02 or later
Pass through:Supported
Communication Port:One (1) DeviceNet
Data Transfer speed:125Kbps
Storage Temperature:-40 to 85 C (-40 to 185 F)
Vibration:Tested 5 g @ 10-500Hz per IEC 68-2-6
Operating Shock:30 g peak acceleration, 11(+1)ms pulse width
Series:SLC 500
Module Type:DeviceNet Scanner Module
Scan I/O:Yes
Backplane Current (5 Volts):500 milliamps
PROCESS MODULE
XM-360
6-CHANNEL INPUT
0-10 VDC/0-20 MA INPUT RANGE
4-20 MA OUTPUT
600 OHM MAX LOAD
STATUS INDICATORS
RS-02232 VIA MINI-CONNECTOR
COMM RATE FIXED @ 19.2 KBPS
STANDARD DEVICENET NETWORK
Module Type:Digital DC Output Module
Number of Outputs:32 (4 sets of 8) Outputs
Voltage Category:10-32 Volts DC, Sink
DC Operating Voltage:10-30 Volts
Backplane Current:330 Miliamperes
Max Continuous Current Per Output:0.5 Amperes
Max Continuous Current Per Module:8 Amperes
Wiring Arm:1771-WH
Coating:Conformal Coat
Typical AC Signal Delay (Off):45 (+/- 15) ms
Input Types:4 V, C, or 3 TC, or 2 RTD, Resistance
Resolution:18 bits
Input Overvoltage Protection:+24 VDC continuous
Input Overcurrent Protection:32 mA continuous
Backplane Current Required:15 mA at 5 V maximum 20 mA at 24 V maximum
Common Mode Rejection:<96 dB at 50/60 Hz
Normal Mode Rejection:65 dB to 74 dB at 50/60 Hz
Thermal Dissipation:1.00 Watt, maximum
Input Types:4 V, C, or 3 TC, or 2 RTD, Resistance
Resolution:18 bits
Input Overvoltage Protection:+24 VDC continuous
Input Overcurrent Protection:32 mA continuous
Backplane Current Required:15 mA at 5 V maximum 20 mA at 24 V maximum
Common Mode Rejection:<96 dB at 50/60 Hz
Normal Mode Rejection:65 dB to 74 dB at 50/60 Hz
Thermal Dissipation:1.00 Watt, maximum
I/O Capacity:8
Communication Rate:5 Mbps
Output Power:5.4 Volts DC
Power Supply:9.5 Volts DC
Power Consumption:8.5 W
Power Dissipation:8.5 W
Thermal Dissipation:29 BTU/hour
Product Type:FLEX Ex RTD Thermocouple I/O Module
Inputs:8
Input Type:Internal Bus Configurable
Signal Input Range:40 to 100 millivolts
Lead Resistance Compensation:15 Watts maximum
Settling Time:8 milliseconds
Module Field-side Power Consumption:1.6 Watts
Power Dissipation:1.6 Watts
Thermal Dissipation:5.46 BTU/hour maximum
Power Supply:9.5 Volts DC
ON state Voltage, min:6VDC
ON state Voltage, max.26.4VDC
ON state Voltage, nom:24VDC
Enclosure:Open-type
Operating Temperature:0 to 55 C (32 to 131 F)
Storage Temperature:-40 to 85 C (-40 to 185 F)
Vibration: 5g @ 10 to 500 Hz
Operating Shock:30 g
Product Type:Flex I/O 4 Channel Pulse Counter Module
Inputs:2 per Interface
Pulse Counter Interfaces:4
Part Number:1794-IF8IH
Outputs:None
Inputs:8
Input type:single-ended, non-isolated
Operating temperature:32 to 131 degrees Fahrenheit
Enclosure:Open
Conversion:Sigma Delta
Dimensions:3.7 x 3.7 x 2.6 inches
External DC voltage rating:19.2 to 31.2 Volts DC
Series:Compact 5000 I/O
No. of Outputs Eight (8) DC output channels
Output Voltage signal, nominal:24VDC
Output Voltage Signal range:10-32VDC
Pulse width, min:200 µs @ 0.5 A @ 25 °C (77 °F)
No. of output groups:Two (2)
Number of Outputs:8 (2 Groups of 4) Channels
Voltage Category:24 Volts DC
Input Voltage Range:N/A
Output Voltage Range:10-32 Volts DC
Power Dissipation:3.2 Watts
Product Type:Programmable Automation Controller
Module Type:Processor Module
Communication:Ethernet
Communication ports:(1) USB; (2) Ethernet I/P; 1 RS232
Supported Protocols:ASCII; DH485; DF1; Ethernet
No. Of Axes over Ethernet:2 axes
Shipping Weight:3 pounds
No. of Task:32 Task
Shipping Dimensions:11X8X6 inches
No. of Program per Task:100
Series:A and B
Product Line:CompactLogix
Product Type:Programmable Automation Controller
Module Type:Processor Module
Communication:Ethernet
Communication ports:2 Ethernet I/P; 1 USB
Motion Control over Ethernet I/P:Included
Integrated Motion:4 Axes
Memory:1MB
Shipping Weight:3 lbs.
Maximum number of I/O modules supported:8 Modules
Series:ControlLogix
Module Type:Isoloated Analog Output Module with current loop
Outputs:6-Point Isolated
Backplane Current (5Volts):250 milliamps
Backplane Current (24 Volts):300 milliamps
Power Dissipation (Max):4.9 Watts at 60 Celsius
Number or ports:2; 1 (RS232); 1 Ethernet I/P
Ports:RS-232
Protocol:DF1 Full-Duplex; Ethernet
Ethernet Transmission speed:Series A and B: 10 mbps Series C and D: 10/100 mbps
Safety Feature:Master Control Relay
Mounting:DIN Rail or Panel
Power Supply: 20.4 to 26.4V dc
24 Volts DC Current Draw:50 mA typical, 100 mA maximum
Item weight:1 pound
Product Type:Isolated Serial Port
Mounting Torque:0.2 Nm
Terminal Screw Torque:0.22-0.25 Nm
Isolated Voltage:500V AC
Surrounding Air Temperature max:65* C
DeviceNet Voltage Range:11 to 25 Volts DC
Current Consumption:230 milliamps at 24 Volts DC
Voltage, On-State Input max.:11 Volts DC
Voltage, Off-State Input max.:5 Volts DC
Input Current:4.5 milliamps
Test Output Type:Current Sourcing
Pulse Test Output Current:0.7 Amps
Output Current:0.5 Amps
Output Surge Current:0.5 Amps
User memory:10 megabytes
Safety memory:5 megabytes
Digital I/O / Analog I/O:128,000 / 4000 max
Ethernet performance:10/100/1000 megabits per second
Current draw at 1.2 Volts DC:5.0 milli Amps
Current draw at 5.1 Volts DC:1.2 Amps
Part Number/Catalog No.:2080-IF2
Product Type:Analog Plug-in Module
Module Type:Analog
Number of Single-Ended Inputs:2
Data Range:0-65535
Repeatability:+/- 0.1%
Update Time:180ms per Enabled Channel
Operating Altitude:2000m
Part Number/Catalog No.:2080-IF4
Product Type:Analog Plug-in Module
Module Type:Analog
Number of Single-Ended Inputs:4
Analog Normal Operating Voltage Range:0-10V DC
Analog Normal Operating Current Range:0-20mA
Data Range:0-65535
Repeatability:+/- 0.1%
