POWER SECTION BOARD
SIMOVERT MD
PEU4 POWER SECTION BOARD
Compatible Drive Rating: 75kW
DC Link Voltage Range: 510V - 650V DC
Output Current: 165A
Switching Frequency: 2kHz - 8kHz
ACTIVE LINE MODULE
ACTIVE LINE MODULE
SINAMIC S120
3 PHASE
INPUT 380-480 VAC
50/60 HZ
OUTPUT 16 KW
27 AMP
600 VDC
INT COOL
NORMALISING MODULE
NORMALISING MODULE
ABOFOR DEVICES
186 AMP
3 PHASE
380-460 VAC AND 510-620 VDC
AC DRIVE
AC DRIVE
SIMOVERT MASTERDRIVE
VECTOR CONTROL
COMPACT PLUS
17.5 A
7.5 KW
3-PHASE
380-480 V AC
50/60 HZ
BASIC LINE MODULE
SINAMICS S120 BASIC LINE MODULE
INPUT: 3 PHASE
380-480 VAC
50/60HZ
OUTPUT: DC 600 V
34 AMP
20 KW
FRAME SIZE: BOOKSIZE
INTERNAL AIR COOLING
INCL. DRIVE-CLIQ CABLE
CONTROL INTERFACE BOARD
CONTROL INTERFACE BOARD
SINAMICS S
FOR 3PH
380-480 VAC
50/60 HZ
380 A MOTOR MODULE
Control Module
Voltage: 24V DC (±15%)
Power Consumption: ≤10W
Isolation: 1500V AC
Analog Inputs:0-10V/4-20mA
Processor: 32-bit ARM
Memory:128MB Flash
Programmable Motion control
SIMOTION C240 PN
Programmable Motion control system
for PROFINET and PROFIBUS Drives
OnboardI/O 18 DI/8 DO (requires V4.1 SP2 HF3/4)
SENSOR BOARD
SINAMICS S120
SENSOR MODULE SMC10
SENSOR BOARD FOR EVALUATION
OF A RESOLVER
WITHOUT DRIVE-CLIQ CABLE
