SIMATIC DP
INTERFACE MODULE
IM151-1 STANDARD FOR ET200S
TRANSMISS. RATE UP TO 12MBIT/S
DATA VOLUME 128BYTE FOR EACH INPUT AND OUTPUT
MAX. OF 63 POWER, ELECTR.
OR MOTOR STARTER MODULES UP
TO 2M WIDTH CONNECTABLE
BUS INTERFACING VIA 9-WAY SUB-D INCL.
TERMINATING MODULE
BDPS-11C
3AXD50000042965
Braking Chopper System
Input Voltage (DC):1000–1200 V DC link
Max. Braking Power:250–1000 kW
Certifications"CE, UL, and IEC 61800-5-1
Operating Temperature: -15°C to +45°C
Product:IGBT Silicon Module
Configuration: 6-Pack
Collector- Emitter Voltage VCEO Max:1.7 kV
Continuous Collector Current at 25 C:740 A
Gate-Emitter Leakage Current:400 nA
Pd - Power Dissipation:3 kW
Minimum Operating Temperature:- 40 C
Maximum Operating Temperature:+ 150 C
Packaging:Tray
Product Type:IGBT Modules
PanelView Plus 7 Performance terminals
Operator Input:Touch
Touch screen: Analog resistive touchscreen
Actuation rating:1 million presses
Operating force:100 grams
Display Type:Color active-matrix TFT
Input Voltage range:18-30 VDC
Power Consumption:50 W max (2.1 A at 24V DC)
Points:32, commoned
Nominal input current:4–20 mA DC
Operational current range:2–22 mA DC
Absolute maximum field voltage:33 V DC
Absolute maximum input current:50 mA DC
Input bandwidth (3dB):16 Hz
Source impedance:180 Ω
Resolution:12 bits
Absolute error:0.15% of full scale (20 mA)
Diagnostic:Force-to-value diagnostic (FVD)
Scan time:<1 ms for all 32 points
Power Supply Input110/220V AC, 24V DC
Output Power 24V DC, 5V DC
Operating Temperature -20°C to 60°C
Storage Temperature -40°C to 85°C
Humidity5% to 95% (non-condensing)
Series: XV Series
Voltage Rating: 380V to 690V AC
Operating Temperature Range: -20°C to +60°C
Storage Temperature Range:-40°C to +85°C
Humidity Range: Generally supports 5% to 95%
330103-00-07-05-02-CN
DISCONTINUED BY MANUFACTURER
PROXIMITY PROBE
3300 XL 8 MM
5.0 INCH OVERALL CASE LENGTH
1.0 M (3.3 FT) TOTAL LENGTH
3/8-24 UNF THREAD
WITH ARMOR
0 5 0-5 mils pp (0-125 μm pp)
0 1 35 mm DIN rail clips
C N CSA Division 2, ATEX Zone 0,
ATEXZone 2 and includes ABS maritimeapproval
Power : Requires +12 to +35 Vdc
input at the transmitter terminal.
Maximum Loop Resistance :
1,000 Ω including cable at 35 Vdc.
Current Limiting : 23 mA typical.
Part Number/Catalog No:15-OB8DE
Product Line:Bulletin 1715 Redundant I/O module
Module Type:-Point Digital Output Module
I/O Module:8-Point Digital Output Module
Power Dissipation:3 Watts Maximum
Wire Size:18 to 16 AWG
Dimensions:166 x 42 x 118 millimeters
Weight:290 grams
Shock Rating:25 g when installed and operation
Mounting:DIN Rail
Output Signal:18 to 32 Volts DC
Product Line:Panelview Plus 7
Product Type:Human-Module Interface
Input Type:Touchscreen
Memory:512 Mb
Input Voltage:24 Volts DC
Backlight:LED
Input Voltage range:18-30 VDC
Power Consumption:50 W max (2.1 A at 24V DC)
Display Type:Color active-matrix TFT
Display Size:12.1 in. ; wide screen
