Relay Output module

Series:Series 90-70
Manufacturer:GE Fanuc
Part number:IC697MDL940
Current draw:750 mA
Switching frequency:20 Cycles per minute
Response time:10 ms
Number of outputs:16
No. of groups:Two (2) Groups of Form A
No of Channels:Sixteen (16) Relay outputs
Required current:750 milliAmps
Minimum load:10 mA
Isolation voltage:1500 Volts

FEEDBACK I/O PACK

POWER DISTRIBUTION SYSTEM
FEEDBACK I/O PACK
PDM DIAGNOSTICS TYPE
FOR MARK VIE
TURBINE CONTROL SYSTEMS
AMBIENT TEMPERATURE:
-30 TO 65 DEGREES C

Profinet network interface unit

Series:Versamax
Manufacturer:Emerson Automation / GE Fanuc (former)
Part Number:IC200PNS001
Series:VersaMax
Part Number:IC200PNS001
Power Consumption:0.60 Amperes at 5 Volts DC
Product type:Remote I/O Profinet Network Interface Unit
Supported protocol:PROFINET version Version 2.2 Class A IO-Device
Proficy Machine Edition Version Required:Version 7.0 or later
Supported topologies:Linear, Star, Ring (redundant)
No. of Ports:Two (2) RJ45ports
Mounting:DIN Rail

Profibus DP Slave Module

PROFIBUS DP SLAVE MODULE
SERIES 90-30
2 COMMUNICATION PORTS

Serial Communications Module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695CMM004
Product Type:Communications module
No of ports:Two (2) RS232 / RS422 / RS485
Serial Ports:4
Physical Interface:RJ-45
Connectors:RJ45
Supported Configurations:RS-232, RS-422/485
No. of installations per rack:Up to Six (6) modules
Baud Rates:1200 baud to 115.2 kilobaud
Status LED indicators:Module OK, Port Fault, Port Status
Current rating:0.7 mA at 3.3 VDC, 0.150 mA at 5 VDC
Operating Temperature:0 to 60 degrees Celsius
Parity:Even, odd, none
Data bits:7, 8
Stop bits:1, 2

Accessory module

Brand:GE Fanuc
Series:RX3i PacSystem
Part Number:IC695ACC412
Description:Cap Pack
Compatibility:RX3i

CABLE

Series:RX3i PacSystem
Part Number:IC695CBL001
Compatibility:PACSystems RX3i
Cable Type:Energy pack cable
Type of Input/Output:Analog
Termination Resistor:Yes

Output Module

Brand:GE Intelligent Platforms/GE Fanuc
Series:Series 90-70
Part Number:IC697MDL340
Product Type:Output Module
Rated Voltage:120 V AC
Outputs:16
DC Power:No
AC Power:Yes
LED Indicators:Yes

Universal analog input module

Series:PACSystem RX3i
Manufacturer:Emerson Automation
Part Number:IC695ALG600
Module Type:Universal Analog
No of Channels:Eight (8)
Number of Inputs:8 general purpose
No. of groups:Two (2)
Cold Junction Compensation:2 channels
No. of channels per group:Four (4)
Power Dissapation:5.4W max
Humidity:5 to 95%, non-condensing
Module conversion method:Sigma-delta
Module resolution:11-16 Bits
Internal Power:3.3V: 350mA; 5V: 400 mA

printed circuit board

Input Voltage: 24V DC
Operating Temperature: Typically between -30°C to +65°C
Humidity: Typically 0-95% (non-condensing)

PACSystems RX3i Power Supply module

Part Number:IC695PSD140
Product Description:Power Supply module
Input voltage range:85 to 264 VAC 100 to 300 VDC
Power Supply:40 Watts
Nominal Rated Voltage:120/240 VAC or 125 VDC
Input Voltage Range:18 to 30 VDC
Input Power:60 Watts maximum at full load
Ripple:150 mV
Output Current:5.1 VDC
Noise:150 mV
Isolation:None
Number of Daisy-Chained PSD140:Up to 4
Terminal Current:6 Amps

NETWORK INTERFACE MODULE

Brand:GE Fanuc
Series:Versamax
Part Number:IC200BEM003
Description:VersaMax master module
Data:3854 input/output
Data Rate:9.6 k baud to 12 M baud
Connector:9 Pin D-sub
Bus Voltage:5 Volts
Slave Devices:125

RX3i 24VDC power supply, 40 watts.

▪+5.1 VDC output
▪ +24 VDC relay output that can be used to power circuitson Output Relay modules
▪ +3.3 VDC. This output is used internally by RX3i moduleswith IC695 catalog numbers
▪Isolation NONE
▪Ripple (all outputs) 50 mV
▪Noise (all outputs) 50 mV

I/O MODULE

Brand:GE Fanuc
Series:Genius I-O
Part number:IC660BRD020
Output circuits:16
Circuit type:Source
Weight:1.8 kilograms
Maximum ripple:10%

9905968
DISCONTINUED BY MANUFACTURER
LINKNET NODES AND I/O CONTROLLER MODULE
6-CH ANALOG INPUT
4-20 MA
WITHOUT 24 V LOOP

DS200GDPAG1AEB
DISCONTINUED BY MANUFACTURER
POWER SUPPLY BOARD
HIGH FREQUNCY
25 KHZ
MARK V

5501376
ANALOG MODULE

5466031
LINKNET CONTROLLER MODULE
4-CHANNEL
NETCON I/O

9905760
DISCONTINUED BY MANUFACTURER
LINKNET
TERMINATION RESISTOR MODULE

9905971
DISCONTINUED BY MANUFACTURER
INPUT MODULE
16 CHANNEL DISCRETE INPUT
24 VDC
