3300 XL 8 mm Proximity Probes

330104  3300 XL 8 mm Probe
M10 x 1 thread,with armor
Minimum unthreaded length: 0 mm
Minimum case length: 20 mm
10 1.0 meter (3.3 feet)
02 Miniature coaxial ClickLocconnector
standard cable
05 CSA, ATEX, IECEx  Approvals

Velomitor XA Piezo-velocity Sensor

Sensitivity:3.94mV/mm/s (100 mV/in/s)±5%
Velocity Range:1270 mm/s (50 in/s) peak
Transverse Sensitivity:Less than 5% of sensitivity
Amplitude Linearity:±2% to 152 mm/s (6 in/s) peak
BroadbandNoise Floor:0.004 mm/s (160 min/s) rms,nominal.
PowerRequirements:
DC Voltage: -22 to -30 VDC
Bias Current: 2.5 to 6.0 mA
Output BiasVoltage:-12 ± 3.0 VDC,
Over Temperature Referenced toPin A

Upgrade Kit

178850-00Upgrade Kit
Non-approved
Voltage:±12V to ±24V DC
Signal Integrity: Maintains API 670
Operating Temp: –30°C to +65°C (–22°F to +149°F)
Humidity: 0–95% non-condensing

Dual Probe Transducer

Standard Range: 0–500 mils
Extended Options: Up to 1000 mils
Sensitivity:200 mV/mil (7.87 V/mm) ±5% per channel
Voltage Output: –2 V to –18 V DC
Current Output (Optional): 4–20 mA
Linearity:±1% of full scale
Power Supply:–18 V to –24 V DC

VELOMITOR CABLE

VELOMITOR CABLE
4METER
XA INTERCONNECT VARIETY

Guardmaster 440C-CR30 safety relay

Guardmaster MSR126.1T Safety Relay

Control Board

PC BOARD
RESISTIVE NETWORK
STATUS LED INDICATORS
6 TRANSFORMERS
YXU-170E

MEMORY BOARD

MEMORY BOARD
CIRCUIT BOARD
RESISTIVE NETWORK
YPR-104B

PC BOARD

PC BOARD
PULSE TRANSFORMER UNIT
CONTROL UNIT
YXU-173E

CIRCUIT BOARD

Memory 512MB DDR3
PWM Resolution 15-bit
Analog Inputs:8x (16-bit SAR ADC)
Digital I/O:16x (24V DC opto)
Encoder Interfaces:1x (A/B/Z + SSI)
Isolation Voltage:2500Vrms
Fieldbus:PROFIBUS DP-V1 (12Mbps)
Ethernet:10/100BASE-TX

Control Board

Memory:1GB DDR3
Digital Inputs:32x (24V DC, opto-isolated)
Analog Inputs:8x (16-bit, ±10V/4-20mA)
Communication:Ports 2x RS-485, 1x Ethernet (10/100/1000)
Redundant Power Inputs :24V DC ±20%

Control Board

Memory:256MB Flash
Control Loop Speed:<50μs
Analog Inputs:8x (16-bit, ±10V/4-20mA)
Digital I/O:16x (24V DC, opto-isolated)
Encoder Interfaces:2x (A/B/Z + SSI)
Isolation Voltage:2500V AC (field to logic)

Relay Assembly

RELAY ASSEMBLY
DIRECT AND DOUBLE ACTING
DVC

KJ3002X1-BA1 Analog Input Module

ControlNet adapter module

Supply Voltage:24V DC (±10%)
Power Consumption:5W (typical)
Isolation:1500V AC
Protocol :ControlNet
Data Rate:5Mbps
Max Nodes:99 per network
Max Cable Length:1000m

PROFIBUS Redundancy Link Module

Supply Voltage:24V DC (±10%)
Power Consumption:3W (typical)
Isolation :1500V AC
Protocol:PROFIBUS DP-V1
Data Rate:9.6kbps
Max Nodes:32 per segment
