Velomitor Interconnect Cable
Stainless steel armor
over shielded 0.382 mm2 (22AWG) cable
with a moisture resistant femaleconnector
at the HTVS end and ring lugs at themonitor end
Temperature range -29 to121°C (-20 to 250°F)
Pulse Transformation Board
Power Supply:24 V DC
Differential: ±12 V.
Power consumption: < 5 W
Single-ended: 0–24 V
Output Voltage:
TTL: 0–5 V.
HTL: 0–24 V
Seismic Transmitter
01 0 – 25.4 mm/s (0 – 1.0 in/s)
02 3 Hz to 1 kHz (180 to 60 kcps) peak
05 Multiple Approvals
Seismic Transmitter
Drive power board
Input Voltage:3-phase 380-480V AC (±10%)
Output Voltages:+24V DC (control)
Power Capacity:500W (continuous)
Switching Frequency:20kHz (PWM)
Efficiency:>92% (at full load)
