Measurement Principle: Guided Wave Radar
Measurement Range: Up to 30 meters (98.4 feet)
Accuracy: ±3 mm (±0.12 inches)
Resolution: 1 mm (0.04 inches)
Process Temperature Range: -196°C to 450°C (-320°F to 842°F)
Process Pressure Range: Up to 100 bar
Power Supply: 12-28 VDC
Current Consumption: Typically 20 mA
VOLTAGE DIVIDER MODULE
VDU
PRODUCT MIGRATION LV SINAMICS
Input Voltage Range:Up to 1000 V DC
Output Signal:±10 V
Power Supply: 24 V DC
Accuracy:±1% of input voltage
Ethernet-6 Ports:10/100 Mbps
Protocol :TCP/IP
Input Range:18-36 Vdc Voltage
Power Consumption:24 W Typical/35 W Maximum
Closed StateImpedance:57 KΩ Maximum
Open StateImpedance:187 KΩ Minimum
Internal WettingVoltage:10-15 Vdc
Input Resistance:150 KΩ Typical
Faulted InputTolerance:±40 V
Input Channels:16x
Input Voltage:24/48/110/125V DC
Input Threshold (ON);>60% of rated voltage
Input Current :3–8 mA
Response Time:<5 ms
Isolation:2.5 kV AC
Power Consumption:≤ 4 W
Input Channels:16 (Grouped as 8+8)
Input Voltage:24 V DC (Nominal)
Voltage Range:19–30 V DC (Logic "1": ≥15 V)
Logic "0" Threshold:≤5 V DC
Input Current:6 mA per channel (typical)
Isolation:500 V AC (channel-to-channel)
Backplane Power:5 V DC (via P4 baseplate)
Function:8-channel analog input (4-20mA)
Input Channels:8 (isolated)
Signal Range:4-20mA
Input Impedance:250 Ω
Accuracy:±0.1% FS (at 25°C)
HART Support:FSK modulation (1200/2200Hz) via same wires
Power Supply:24 V DC loop power
Isolation:500 V AC
Functions:4x 4-20mA Input
Signal Range :4-20mA
Accuracy:±0.05% FS (23°C)
Loop Power:24 V DC
Isolation:500 V AC (channel-to-bus)
Max Devices:16 per segment
Power:9–32 V DC
Hardware Generation:G4 (4th Gen)
Status:Discontinued (since ~2003)
Replacement:AC 800M Controller Series
Memory:4 MB DRAM + 2 MB Flash
Backup Battery:3.6 V Li (BR2325) for RAM retention
Cycle Time:≤100 ms
I/O Capacity:Up to 1024 I/O points
Supply Voltage:24 V DC ±10%
Power Consumption:15 W (max)
Memory:2 MB SRAM
Profibus DP Ports:2x RS-485
Baud Rate:9.6 kbps – 12 Mbps
Max Devices:124 slaves per segment
Supply Voltage:5 V DC ±5% (via backplane)
Power Consumption:8 W max
Isolation:500 V AC (field-to-logic)
Output Channels 32
Output Type Source
Load Voltage 15 30 VDC Maximum
On-State Voltage 24 V (typ), load current @ 0.5A
Off-State Leak Current 5.0 µA (max)
Turn-On/Turn-Off Time 10 ms (max)
Inputs per module:32 (sinking)
Input Voltage Range:10 VDC to 32 VDC
Peak Voltage:32 VDC
AC Frequency: N/A
ON Voltage Level:9.5 VDC minimum
OFF Voltage Level:3.5 VDC maximum
Input Impedance:6.9 K ohms nominal
Minimum ON Current:1.0 mA
Maximum OFF Current:0.7 mA
Ports 5 Ethernet ports
(RJ45 connectors)
Port Speed 10/100/1000 Mbps
Switching Capacity 10 Gbps
Input Voltage 12-48 VDC
Power Consumption <5 W
Operating Temperature Range -40°C to +75°C
Storage Temperature Range -40°C to +85°C
Humidity 5% to 95% non-condensing
Mounting Options DIN rail or wall-mountable
Approvals: UL, CSA; FM pending
Type: CC 600 World 4 × 2.5 mm2
Bus bar side: 2 pole Squeeze To
Release type: D-TAB-200-STR
IO chassis side: FM5W5 S (female)
housing: low profile, 90°
The red wire represents the +24Vdc
The black wire represents the 0Vdc
Approvals: UL, CSA; FM pending
Housing type: 2 pole socket block
Weidmuller BLZ 5.08/2F
Crimp pin type: Weidmuller
DFFC 1.5-2.5 SN E
POWER BUSBAR MAX.200A 24/48/110VDC,150CM
Nominal Voltage:24 Vdc, 48 Vdc, 110 Vdc
Max Current:200 A continuous
Length:1,500 mm (150 cm)
Bus Sections 10 sections 152.4 mm each
Approvals:UL, CSA, FM‑pending
Power Supply Inputs:Dual 5V DC (5V-1 and 5V-2)
Power Consumption:0.05 A per 5V input rail
Chassis Width:482.6 mm (19 inches)
Operating Temperature:0°C to +50°C
Storage Temperature:-40°C to +70°C
Relative Humidity:5% to 95% non-condensing
Form Factor: 19-inch standard rack width
Slot Capacity: 21 slots for I/O module
Voltage: 24 V DC (±10%)
Humidity: 5–95% RH (non-condensing).
Vibration: 5–500 Hz, 2 g RMS (IEC 60068-2-6).
Shock: 30 g peak, 11 ms
1-channel isolated barrier
24 V DC supply (Power Rail)
Input 2-wire and 3-wire
SMART transmitters and
2-wire SMART current sources
Output 0/4 mA ... 20 mA
Terminals with test points
Up to SIL 2 acc. to IEC/EN 61508
Supply Voltage:24 V DC ±10%
Power Consumption:≤5 W
Isolation :500 V AC
I/O Channels:Likely 8–16
Function:Fieldbus interface or signal conditioning
Status:Discontinued
Voltage: Typically 24 VDC (±10%)
Power Consumption: <5–10 W
Digital Inputs: 8–16 channels
Analog Inputs: 4-20 mA/0-10 V
Temperature Range: -20°C to +70°C
Data Rate:31.25 kbit/s
Power Supply:24 V DC (via controller backplane)
Power Consumption:Typically 0.8 W per channel
Isolation:500 V AC
RUN (Green): Module operation
COM (Green/Yellow): Communication status
ERR (Red): Fault indication
