Channels: 20 single-ended channels
Voltage: ±10 V DC
Current: 0–20 mA, 4–20 mA
Voltage Inputs: >1 MΩ.
Current Inputs: 250 Ω
Noise Rejection: >80 dB (50/60 Hz)
Channel-to-Backplane: 1,500 V AC RMS
Data Throughput: Up to 10,000
RAM: 512 KB
Voltage: +5V DC
Consumption: 10 W (typical)
Isolation:1500V AC
Fiber optic: Up to 4 km
Max Nodes: Up to 250 devices per loop
Detection Range:Up to 40 meters
Response Time:< 3 seconds
Supply Voltage:24 V DC
Power Consumption:4–8 W (DC)
Relay Contacts: 2× SPDT
Analog Output: 4–20 mA
Optional redundancy
Normal (20ms PV scan)
Direct / Reverse Input Indication
Low Latency (5ms PV scan)
Internal or external field power selection
Extensive internal diagnostics for data integrity
On board excitation power (no need formarshalling power)
Sequence of Events (1ms resolution SOE,20ms PV scan)
Series 8 C300 Controller, Coated 1
Power requirement:24 V
Program Memory:16MB
Processor:core Single
Third party devices:Modbus Master
Modbus TCP:devices PCDI function block
Expansion End Plate, Left
Rated input voltage:24 VDC ± 25%
Input voltage range :18 to 30 VDC
Maximum ripple voltage :120 mVpp
Maximum rated inputcurrent:1.02 A at 30 VDC
Analog Input (HART): 28 channels
Digital Input: 10 channels
Analog Output (HART): 2 channels。
Digital Output: 6 channels
Operating Voltage: 24 V DC ±25%。
Operating Temperature: -40°C to 75°C
Humidity: 5% to 95% RH (non-condensing)
